Magic Leap Patent | Methods And Systems For Providing Wavefront Corrections For Treating Conditions Including Myopia, Hyperopia, And/Or Astigmatism
Publication Number: 10466477
Publication Date: 20191105
Applicants: Magic Leap
Abstract
Configurations are disclosed for a health system to be used in various healthcare applications, e.g., for patient diagnostics, monitoring, and/or therapy. The health system may comprise a light generation module to transmit light or an image to a user, one or more sensors to detect a physiological parameter of the user’s body, including their eyes, and processing circuitry to analyze an input received in response to the presented images to determine one or more health conditions or defects.
FIELD
The present disclosure relates to various methods and systems for diagnosing, monitoring, and treating health conditions and ailments, including ophthalmic as well as other conditions and ailments.
BACKGROUND
Ophthalmic instruments and techniques are routinely used by clinicians to diagnose and treat eye-related ailments. An example of a traditional ophthalmic device is shown in FIG. 1. As illustrated, the patient may be positioned in a specific, seated position for the entire duration of the procedure, which may last anywhere between a few seconds to a few minutes. This positioning has been considered necessary to properly align the patient’s eye with the ophthalmic device, to perform measurements and/or therapeutic procedures on the patient’s eyes.
Undesirably, ophthalmic devices tend to be large, bulky and expensive devices, and are typically used exclusively in doctor’s offices. Thus, patients may be required to make an appointment with an optometrist and visit the doctor for any diagnoses or treatment to take place. This can be a deterring factor for many patients, who may delay the trip to the doctor’s office for long periods of time, possibly until a condition has worsened. The worsened condition may require even more drastic therapies or procedures to address, when it could have been more easily alleviated had the patient been timely diagnosed or treated. Furthermore, the large and bulky nature of most ophthalmic devices forces patients to be placed in an uncomfortable position for a large amount of time, which in turn may actually increase risks of mis-diagnoses and patient error.
Accordingly, there is a need for health systems that address one or more of the difficulties above.
SUMMARY
Example embodiments described herein have innovative features, no single one of which is indispensable or solely responsible for their desirable attributes. Without limiting the scope of the claims, some of the advantageous features will now be summarized.
An innovative aspect of the subject matter described herein can be implemented in a user-wearable diagnostic health system comprising a frame, an augmented reality display attached to the frame, a light detector attached to the frame and a processor configured to conduct a health analysis of the user based on light detected by the light detector. The frame is configured to mount on the user. The augmented reality display is configured to direct images to an eye of the user. The light detector is configured to detect light reflected from an eye of the user.
Another innovative aspect of the subject matter described herein can be implemented in a user-wearable diagnostic health system comprising a frame, an augmented reality display attached to the frame, a sound emitter configured to emit sound waves toward the user, a sound detector attached to the frame and configured to detect sound waves reflected from the user, and a processor configured to conduct a health analysis of the user based on information detected by the sound detector. The frame is configured to mount on the user. The augmented reality display is configured to direct images to an eye of the user.
Yet another innovative aspect of the subject matter described herein can be implemented in a user-wearable therapeutic health system comprising a frame configured to mount on the user, an augmented reality display attached to the frame and a processor configured to direct the augmented reality display to conduct a health therapy protocol on the user. The augmented reality display is further configured to direct images to an eye of the user.
An innovative aspect of the subject matter described herein can be implemented in a wearable diagnostic health system comprising a frame configured to mount on a clinician, an augmented reality display attached to the frame and configured to direct images to an eye of the clinician, an outward-facing image capture device configured to image an eye of a patient and a processor configured to conduct a health analysis of the patient based on the image of the eye captured by the image capture device.
Additional example embodiments are provided below. Note that structures for various health analyses and/or therapies may coexist in the same health system. Moreover, as disclosed herein, the same feature may be applied to facilitate multiple health analyses and/or therapies. For example, structures used for delivering medication may also be utilized for various diagnostics, as disclosed herein. Consequently, health systems according to some embodiments may include various combinations of the structural features disclosed herein, including combinations of features disclosed under different headings. In addition, the health system may be configured to perform various combinations of the health analyses and therapies disclosed herein, including those disclosed under different headings. Accordingly, a variety of example embodiments are set for below.
Myopia/Hyperopia/Astigmatism
-
A wearable ophthalmic device, comprising: a head-mounted display system; and a light source configured to direct light into an eye of a person to form an image in the eye; and a waveguide stack comprising one or more waveguides, wherein each of the one or more waveguides is configured to project the light at one of the one or more focal planes, wherein the image is modified by a wavefront correction based on an optical prescription for the eye.
-
The device of embodiment 1, wherein the waveguide stack further comprises one or more lenses.
-
The device of embodiment 1, wherein the head-mounted display system comprises an augmented reality head-mounted ophthalmic system configured to pass light from the world into the eye of the person wearing the head-mounted system.
-
The device of embodiment 1, wherein the optical prescription comprises a prescription for myopia.
-
The device of embodiment 1, wherein the optical prescription comprises a prescription for hyperopia.
-
The device of embodiment 1, wherein the optical prescription comprises a prescription for astigmatism.
-
A wearable ophthalmic device, comprising: an augmented reality head-mounted display system configured to pass light from the world into an eye of a person wearing the head-mounted system; a light source configured to direct light into an eye of the person to form an image in the eye; and an adaptable optics element configured to apply a wavefront correction to the image based on an optical prescription for the eye.
-
The device of embodiment 7, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 8, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 9, further comprising: one or more electrodes coupled to the membrane mirror; and a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror based on a corneal shape of the eye.
-
The device of embodiment 7, wherein the optical prescription comprises a prescription for myopia.
-
The device of embodiment 7, wherein the optical prescription comprises a prescription for hyperopia.
-
The device of embodiment 7, wherein the optical prescription comprises a prescription for astigmatism.
-
A wearable ophthalmic device, comprising: a head-mounted ophthalmic system; a light source configured to direct light into an eye of a person to form an image in the eye; and an adaptable optics element configured to apply a wavefront correction to the image based on an optical prescription for the eye, wherein the adaptable optics comprises a membrane mirror.
-
The device of embodiment 14, further comprising: one or more electrodes coupled to the membrane mirror; and a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror based on a corneal shape of the eye.
-
The device of embodiment 14, wherein the optical prescription comprises a prescription for myopia.
-
The device of embodiment 14, wherein the optical prescription comprises a prescription for hyperopia.
-
The device of embodiment 14, wherein the optical prescription comprises a prescription for astigmatism.
-
A wearable ophthalmic device, comprising: a head-mounted display system; and a light source configured to direct light into an eye of a person to form an image in the eye, the light source comprising a fiber scanning projector, wherein the image is modified by a wavefront correction based on an optical prescription for the eye.
-
The device of embodiment 19, wherein the optical prescription comprises a prescription for myopia.
-
The device of embodiment 19, wherein the optical prescription comprises a prescription for hyperopia.
-
The device of embodiment 19, wherein the optical prescription comprises a prescription for astigmatism.
-
A wearable augmented reality ophthalmic device, comprising: an augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a person wearing the head-mounted system; and a light source configured to project light into the eye of the person to form an image in the eye, the image being modified by a wavefront correction based on an optical prescription for the eye.
-
The device of embodiment 23, wherein the optical prescription comprises a prescription for myopia.
-
The device of embodiment 23, wherein the optical prescription comprises a prescription for hyperopia.
-
The device of embodiment 23, wherein the optical prescription comprises a prescription for astigmatism.
-
A method for addressing vision defects of a person wearing a head mounted display system, comprising: identifying an optical prescription of said person; producing an image using a display in the head mounted display system; applying wavefront correction to said image based on said prescription to yield a corrected image; and displaying the corrected image to the person wearing the head mounted display.
-
The method of embodiment 27, wherein identifying an optical prescription of the person comprises receiving input from the person specifying the prescription.
-
The method of embodiment 27, wherein identifying an optical prescription of the person comprises presenting the person with different wavefront corrections.
-
The method of embodiment 29, further comprising receiving input from the person specifying the preferred correction.
-
The method of embodiment 27, wherein the wavefront correction is implemented by adjusting adaptive optics in the head mounted display.
-
The method of embodiment 31, wherein the adaptive optics comprises a variable focus element.
-
The method of embodiment 31, wherein the adaptive optics comprises a deformable optical element.
-
The method of embodiment 38, wherein the deformable optical element comprises a deformable mirror.
-
The method of embodiment 27, wherein the wavefront correction is implemented by using a waveguide stack comprising a plurality of waveguides configured to provide different focal planes.
-
The method of embodiment 35, wherein the wavefront correction is implemented by directing said image through the combination of waveguides that provide the desired optical power to provide the wavefront correction.
-
The method of embodiment 27, further comprising providing different image content at different depth planes.
-
The method of embodiment 37, wherein said providing different image content at different depth planes comprising providing different image content through different waveguides in a waveguide stack thereby providing different optical power to different image content.
-
The method of embodiment 38, wherein different image content propagates through a different number of waveguides thereby providing different optical power to different image content.
-
The method of embodiment 39, wherein said waveguides include static optical elements having optical power.
-
The method of embodiment 27, wherein the wavefront correction is implemented by directing said image through at least one waveguide.
-
The method of embodiment 41, wherein said at least one waveguide includes a dynamic optical element having variable optical power.
-
The method of embodiment 27, wherein said optical correction is configured to correct for myopia.
-
The method of embodiment 27, wherein said optical correction is configured to correct for hyperopia.
-
The method of embodiment 27, wherein said optical correction is configured to correct for astigmatism.
-
The method of embodiment 27, wherein applying the wavefront correction comprises accessing processing electronics.
-
The method of embodiment 27, wherein said wavefront correction is applied to a virtual reality image.
-
The method of embodiment 27, wherein said wavefront correction is applied to an augmented reality image.
-
The method of embodiment 27, wherein said wavefront correction is applied to said image from said display and in imaging objects in front of said head mounted display and said person wearing said head mounted display.
-
A wearable ophthalmic device, comprising: a light source and wearable optics configured to direct light into the eye of the person wearing said wearable optics to form an image in said eye, said wearable optics configured to provide prescription refractive correction to said image based on an optical prescription for said person’s eye.
-
The device of embodiment 50, further comprising user interface controls configured to receive input from the person specifying the person’s optical prescription.
-
The device of embodiment 50, configured to present the person with different wavefront corrections to identify an optical prescription of the person.
-
The device of embodiment 52, further comprising a user interface configured to receive input from the person specifying the preferred correction.
-
The device of embodiment 50, wherein said wearable optics comprise adaptive optics in the wearable optics configured to be adjusted to implement the correction.
-
The device of embodiment 54, wherein the adaptive optics comprises a variable focus element.
-
The device of embodiment 54, wherein the adaptive optics comprises a deformable optical element.
-
The device of embodiment 56, wherein the deformable optical element comprises a deformable mirror.
-
The device of embodiment 50, wherein said wearable optics comprise a waveguide stack comprising a plurality of waveguides configured to provide different focal planes, said waveguide stack configured to provide the prescription correction.
-
The device of embodiment 58, wherein the waveguide stack comprises a combination of waveguides that provide the desired optical power to provide the prescription correction, said prescription correction being implemented by directing said light through the combination of waveguides.
-
The device of embodiment 50, wherein the wearable optic comprise different depth planes, said wearable optics configured to provide different image content at said different depth planes.
-
The device of embodiment 60, wherein said wearable optics comprise a waveguide stack comprising a plurality of waveguides, said providing different image content at different depth planes comprising providing different image content through different waveguides in a waveguide stack thereby providing different optical power to different image content.
-
The device of embodiment 61, wherein different image content propagates through a different number of waveguides thereby providing different optical power to different image content.
-
The device of embodiment 58, wherein said waveguides include static optical elements having optical power.
-
The device of embodiment 50, wherein said wearable optics comprises at least one waveguide, wherein the prescription correction is implemented by directing said light through at least one waveguide.
-
The device of embodiment 64, wherein said at least one waveguide includes a dynamic optical element having variable optical power.
-
The device of embodiment 50, wherein said prescription correction is configured to correct for myopia.
-
The device of embodiment 50, wherein said prescription correction is configured to correct for hyperopia.
-
The method of embodiment 50, wherein said prescription correction is configured to correct for astigmatism.
-
The method of embodiment 50, further comprising processing electronics configured to be accessed to provide the prescription correction.
-
The device of embodiment 69, further comprising a sensor to determine orientation of said person’s head.
-
The device of embodiment 70, wherein said sensor comprises a gyroscopic sensor.
-
The device of embodiment 70, wherein said wearable optics is configured to alter the focus of said image based on said head position.
-
The device of embodiment 69, wherein said wearable optics comprises a variable focus element configured to vary a focus of said image to provide said correction.
-
The device of embodiment 69, further comprising an eye tracking system configured to determine a person’s convergence point.
-
The device of embodiment 74, wherein said wearable optics is configured to alter the focus of said image based on said determined convergence point.
-
The device of any of embodiments 50, wherein said device comprises a virtual reality device configured to provide said prescription correction to virtual reality image content.
-
The device of any of embodiments 50, wherein said device comprises an augmented reality system configured to provide said prescription correction to augmented reality image content.
-
The device of embodiment 77, wherein said wearable optics are configured such that said prescription correction is applied to an image formed from light from said light source and to images formed from objects in front of said device and said person wearing said wearable optics.
-
The method of embodiment 27, wherein identifying the optical prescription of the person comprises identifying a plurality of optical prescriptions at a plurality of intervals, wherein each optical prescription corresponds to an interval.
-
The method of embodiment 79, wherein the wavefront correction is dynamically adjusted based on the each optical prescription.
-
The device of embodiment 52, configured to identify a plurality of optical prescriptions at plurality of intervals, wherein each optical prescription corresponds to an interval, wherein the refractive correction is dynamically adjusted based on each optical prescription.
-
The device of embodiment 7, wherein the augmented reality head-mounted display system comprises a display lens configured to pass light from the world into an eye of a person wearing the head-mounted system, and wherein the adaptable optics element is positioned between the display lens and a source of the light from the world.
-
The device of embodiment 7, wherein the augmented reality head-mounted display system comprises a display lens configured to pass light from the world into an eye of a person wearing the head-mounted system, and wherein the adaptable optics element is positioned between the display lens and the eye of the user.
-
The device of embodiment 7, wherein the adaptable optics element are positioned between the light source and the eye of the user.
-
The device of embodiment 7, wherein the adaptable optics element are integrated into the light source.
-
The device of any of embodiments 50, wherein said device comprises an augmented reality system configured pass ambient light from in front of the person to the eye of the person to provide, wherein said device is further configured to provide said prescription correction to the ambient light.
-
The device of embodiment 58, wherein said wearable optics comprise adaptive optics in the wearable optics configured to be adjusted to implement the correction.
-
The device of embodiment 87, wherein the adaptive optics is positioned in at least one of:
between the light source and the waveguide stack;
between at least one of the plurality of waveguides and another one of the plurality of waveguides;
between the waveguide stack and the eye of the person;* and*
between the waveguide stack and an ambient light source from in front of said device.
-
The device of embodiment 87, wherein the adaptive optics is integrated in at least one of the waveguide stack and the light source.
-
The method of embodiment 27, further comprising: passing ambient light from the world in front of the person and in front of the head mounted display device; applying wavefront correction to said ambient light based on said prescription; displaying the corrected ambient light to the person, wherein the corrected ambient light is displayed with the corrected image.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Presbyopia*
-
A wearable ophthalmic device for addressing presbyopia, comprising: a head-mounted ophthalmic system; a sensor configured to determine an orientation of a gaze of a person; a light source configured to direct a light form into an eye of the person to form an image in the eye; and an adaptive optics element through which the light form is projected, wherein the adaptive optics element is configured to modify a focus of the image based on the orientation of the gaze of the person.
-
The device of embodiment 1, wherein the orientation of the gaze of the person is based on a position of a head of the person.
-
The device of embodiment 1, further comprising gyroscopic sensors to determine a position of a head of the person.
-
The device of embodiment 1, wherein the orientation of the gaze of the person is determined by tracking a position of the eye.
-
A wearable ophthalmic device, comprising: a light source and wearable optics configured to direct light into the eye of the person wearing said wearable optics to form an image in said eye, said wearable optics configured to correct for presbyopia based on an optical prescription for said person’s eye.
-
The device of embodiment 5, further comprising user interface controls configured to receive input from the person specifying the person’s optical prescription.
-
The device of embodiment 5, configured to present the person with different wavefront corrections to identify an optical prescription of the person.
-
The device of embodiment 7, further comprising a user interface configured to receive input from the person specifying the preferred correction.
-
The device of embodiment 5, wherein said wearable optics comprise adaptive optics in the wearable optics configured to be adjusted to implement the correction.
-
The device of embodiment 9, wherein the adaptive optics comprises a variable focus element.
-
The device of embodiment 9, wherein the adaptive optics comprises a deformable optical element.
-
The device of embodiment 11, wherein the deformable optical element comprises a deformable mirror.
-
The device of embodiment 5, wherein said wearable optics comprise a waveguide stack comprising a plurality of waveguides configured to provide different focal planes, said waveguide stack configured to provide the prescription correction.
-
The device of embodiment 13, wherein the waveguide stack comprises a combination of waveguides that provide the desired optical power to provide the prescription correction, said prescription correction being implemented by directing said light through the combination of waveguides.
-
The device of embodiment 5, wherein the wearable optics provide different depth planes, said wearable optics configured to provide different image content at said different depth planes.
-
The device of embodiment 15, wherein said wearable optics comprise a waveguide stack comprising a plurality of waveguides, said providing different image content at different depth planes comprising providing different image content through different waveguides in a waveguide stack thereby providing different optical power to different image content.
-
The device of embodiment 16, wherein different image content propagates through a different number of waveguides thereby providing different optical power to different image content.
-
The device of embodiment 13, wherein said waveguides include static optical elements having optical power.
-
The device of embodiment 5, wherein said wearable optics comprises at least one waveguide, wherein the prescription correction is implemented by directing said light through at least one waveguide.
-
The device of embodiment 19, wherein said at least one waveguide includes a dynamic optical element having variable optical power.
-
The device of embodiment 5, further comprising processing electronics configured to be accessed to provide the prescription correction.
-
The device of embodiment 21, further comprising a sensor to determine orientation of said person’s head.
-
The device of embodiment 22, wherein said sensor comprises a gyroscopic sensor.
-
The device of embodiment 22, wherein said wearable optics is configured to alter the focus of said image based on said head position.
-
The device of embodiment 21, wherein said wearable optics comprises a variable focus element configured to vary a focus of said image to provide said correction.
-
The device of embodiment 21, further comprising an eye tracking system configured to determine a person’s convergence point.
-
The device of embodiment 26, wherein said wearable optics is configured to alter the focus of said image based on said determined convergence point.
-
The device of embodiment 5, wherein said device comprises a virtual reality device configured to provide said prescription correction to virtual reality image content.
-
The device of embodiment 5, wherein said device comprises an augmented reality system configured to provide said prescription correction to augmented reality image content.
-
The device of embodiment 29, wherein said wearable optics are configured such that said prescription correction is applied to an image formed from light from said light source and to images formed from objects in front of said device and said person wearing said wearable optics.
-
The device of embodiment 5, further comprising electronics configured to determine the person’s gaze based on movement of one or more of the person’s eyes.
-
The device of embodiment 31, wherein the said wearable optics is configured to alter the focus of said image based on said determined gaze.
-
The device of embodiment 31, wherein a downward movement of one or more of the person’s eyes is indicative of the person focusing at a near-field focal depth.
-
The device of embodiment 33, wherein the said wearable optics is configured to increase the optical power of a portion of the said wearable optics based on the optical prescription for said person’s eye.
-
The device of embodiment 16, further comprising an electronics configured to determine the person’s gaze based on movement of one or more of the person’s eyes.
-
The device of embodiment 1, wherein the sensor comprises an eye-tracking system configured to determine the convergence point of the eye of the person.
-
The device of embodiment 4, wherein an angle of convergence is determined based on the position of the eye, wherein the focus is modified based on the angle of convergence.
-
The device of embodiment 31, wherein a downward movement of one or more of the person’s eyes is indicative of an increase in an angle of the convergence of the eyes, wherein an increase in the angle of the convergence of the eye is indicative of the person focusing at a near-field focal depth.
-
The device of embodiment 5, further comprising a biofeedback system configured to determine the wavefront correction based on monitoring one or more properties of the eye while viewing the image.
-
The device of embodiment 40, wherein the biofeedback system receives inputs from at least one of a phoropter, an autorefractor, and an eye tracking system.
-
The device of embodiment 40, wherein the properties of the eye is at least one of: changes in a convergence point of the eye, changes in a position of a head of the person, change in a size of a pupil of the eye.
-
The device of embodiment 5, further comprising electronics configured to determine the person’s gaze based on glint detection.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
Strabismus/Amblyopia
-
A wearable augmented reality device configured to be used by a wearer having eyes having an inability to align at a single convergence point, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; a light source configured to project light into the eye of the wearer to form an image in the eye; and an eye tracking system configured to determine gaze of said eye, wherein the image is modified to add compensating prism correction to bring the convergence point of both eyes together.
-
A wearable virtual reality device configured to be used by a wearer having eyes having an inability to align at a single convergence point, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform comprising a display for providing images to an eye of the wearer; a light source configured to project light into the eye of the wearer to form an image in the eye; and an eye tracking system configured to determine gaze of said eye, wherein the image is modified to add compensating prism correction to bring the convergence point of both eyes together.
-
A wearable augmented reality device configured to be used by a wearer having eyes having an inability to align at a single convergence point, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; a light source configured to project light into the eye of the wearer to form an image in the eye; an eye tracking system configured to determine gaze of said eye; and an adaptable optics element configured to add compensating prism correction to bring the convergence point of both eyes together.
-
The device of embodiment 3, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 4, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 5, further comprising: one or more electrodes coupled to the membrane mirror; and a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror based on a corneal shape of the eye.
-
A wearable virtual reality device configured to be used by a wearer having eyes having an inability to align at a single convergence point, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform comprising a display for providing images to an eye of the wearer; a light source configured to project light into the eye of the wearer to form an image in the eye; an eye tracking system configured to determine gaze of said eye; and an adaptable optics element configured to add compensating prism correction to bring the convergence point of both eyes together.
-
The device of embodiment 7, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 8, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 9, further comprising: one or more electrodes coupled to the membrane mirror; and a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror based on a corneal shape of the eye.
-
A wearable display device configured to be used by a wearer having eyes having an inability to align at a single convergence point, said display device comprising: a wearable head-mounted ophthalmic system; a light source configured to direct light into an eye of said wearer to form an image in the eye, the light source comprising a fiber scanning projector; and an eye tracking system configured to determine gaze of said eye, wherein the light source is configured to add compensating prism correction to bring the convergence point of both eyes together.
-
A wearable display device configured to be used by a wearer having eyes having an inability to align at a single convergence point, said display device comprising: a wearable head-mounted ophthalmic system; a light source configured to direct light into an eye of said wearer to form an image in the eye; a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes; and an eye tracking system configured to determine gaze of said eye, wherein the image is modified to add compensating prism correction to bring the convergence point of both eyes together.
-
The device of embodiment 12, wherein the waveguide stack further comprises one or more lenses.
-
The device of embodiment 12, wherein the head-mounted ophthalmic system comprises an augmented reality display platform, said head-mounted ophthalmic system configured to pass light from the world into the eye of the wearer wearing the head-mounted display system.
-
A wearable augmented reality device configured to be used by a wearer having eyes having an inability to align at a single convergence point, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; a light source configured to direct light into the eye of the wearer to form an image in the eye; and an eye tracking system configured to determine gaze of said eye, wherein the wearable augmented reality device is configured to re-train to gradually align the convergence point of both eyes.
-
The device of embodiment 15, wherein the wearable augmented reality device is configured to re-train by occluding one eye.
-
The device of embodiment 15, wherein the wearable augmented reality device is configured to re-train by reducing intensity of light into one eye.
-
The device of embodiment 15, wherein the wearable augmented reality device is configured to re-train by defocusing the light directed into one eye.
-
A wearable virtual reality device configured to be used by a wearer having eyes having an inability to align at a single convergence point, said device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform comprising a display for providing images to an eye of the wearer; a light source configured to direct light into the eye of the wearer to form an image in the eye; and an eye tracking system configured to determine gaze of said eye, wherein the wearable virtual reality device is configured to re-train to gradually align the convergence point of both eyes.
-
The device of embodiment 19, wherein the wearable virtual reality device is configured to re-train by occluding one eye.
-
The device of embodiment 19, wherein the wearable virtual reality device is configured to re-train by reducing intensity of light into one eye.
-
The device of embodiment 19, wherein the wearable virtual reality device is configured to re-train by defocusing the light directed into one eye.
-
A wearable display device configured to be used by a wearer having eyes having an inability to align at a single convergence point, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted ophthalmic system; a light source configured to direct light into the eye of the wearer to form an image in the eye; an adaptable optics element configured to modify said image; and an eye tracking system configured to determine gaze of said eye, wherein the wearable display device is configured to re-train to gradually align the convergence point of both eyes.
-
The device of embodiment 23, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 24, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 25, further comprising: one or more electrodes coupled to the membrane mirror; and a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror based on a corneal shape of the eye.
-
A wearable display device configured to be used by a wearer having eyes having an inability to align at a single convergence point, said device comprising: a head-mounted ophthalmic system; a light source configured to direct light into an eye of the wearer to form an image in the eye; an adaptable optics element configured to modify said image; and an eye tracking system configured to determine gaze of said eye, wherein the wearable display device is configured to re-train to gradually align the convergence point of both eyes.
-
The device of embodiment 27, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 28, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 29, further comprising: one or more electrodes coupled to the membrane mirror; and a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror based on a corneal shape of the eye.
-
A wearable display device configured to be used by a wearer having eyes having an inability to align at a single convergence point, said device comprising: a head-mounted ophthalmic system; a light source configured to direct light into an eye of the wearer to form an image in the eye, the light source comprising a fiber scanning projector; and an eye tracking system configured to determine gaze of said eye, wherein the wearable display device is configured to re-train to gradually align the convergence point of both eyes.
-
A wearable display device configured to be used by a wearer having eyes having an inability to align at a single convergence point, said device comprising: a head-mounted ophthalmic system; a light source configured to direct light into an eye of the wearer to form an image in the eye; a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes; and an eye tracking system configured to determine gaze of said eye, wherein the wearable display device is configured to re-train to gradually align the convergence point of both eyes.
-
The device of embodiment 32, wherein the waveguide stack further comprises one or more lenses.
-
The device of embodiment 32, wherein the head-mounted ophthalmic system comprises an augmented reality display platform, said head-mounted ophthalmic system configured to pass light from the world into the eye of the wearer wearing the head-mounted display system.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Higher Order Aberrations*
-
A wearable augmented reality device configured to be used by a person, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of the person wearing the head-mounted system; and at least one light source and wearable optics configured to project light into the eye of the person to form an image in the eye, said at least one light source and wearable optics configured to provide refractive correction for higher order refractive errors.
-
The device of embodiment 1, wherein said at least one light source comprises a fiber scanning display.
-
The device of embodiment 1, further comprising user interface controls configured to receive an input specifying the person’s optical prescription.
-
The device of embodiment 1, wherein said wearable optics comprise adaptive optics in the wearable optics configured to be adjusted to implement the refractive correction.
-
The device of embodiment 4, wherein the adaptive optics comprises a variable focus element.
-
The device of embodiment 4, wherein the adaptive optics comprises a deformable optical element.
-
The device of embodiment 6, wherein the deformable optical element comprises a deformable mirror.
-
The device of embodiment 1, wherein said wearable optics comprise a waveguide stack comprising a plurality of waveguides configured to provide different focal planes.
-
The device of embodiment 1, wherein the wearable optics comprise different depth planes, said wearable optics configured to provide different image content at said different depth planes.
-
The device of embodiment 9, wherein said wearable optics comprise a waveguide stack comprising a plurality of waveguides, said providing different image content at different depth planes comprising providing different image content through different waveguides in a waveguide stack thereby providing different optical power to different image content.
-
The device of embodiment 10, wherein different image content propagates through a different number of waveguides thereby providing different optical power to different image content.
-
The device of embodiment 8, wherein said waveguides include static optical elements having optical power.
-
The device of embodiment 1, wherein said wearable optics comprises at least one waveguide.
-
The device of embodiment 13, wherein said at least one waveguide includes a dynamic optical element having variable optical power.
-
The device of embodiment 1, further comprising processing electronics configured to be accessed to provide the refractive correction.
-
The device of embodiment 1, wherein said wearable optics are configured such that said refractive correction is applied to an image formed from light from said light source and to images formed from objects in front of said device and said person wearing said wearable optics.
-
A wearable virtual reality device configured to be used by a person, said device comprising: a virtual reality head-mounted ophthalmic system comprising an virtual reality display platform comprising a display for providing images to the eye of the person; and at least one light source and wearable optics configured to project light into the eye of the person to form an image in the eye, said at least one light source and wearable optics configured to provide refractive correction for higher order refractive errors.
-
The device of embodiment 1, further comprising a receiver circuit configured to receive input from a remote source specifying the person’s optical prescription.
-
The device of embodiment 1, further comprising a receiver configured to receive, from a memory circuit external to the wearable augmented reality device, an optical prescription stored on the memory circuit, wherein the wearable augmented reality device provides refractive correction based on the received optical prescription.
-
The device of embodiment 17, further comprising an outward facing camera configured to obtain images of light formed from objects in front of said device, wherein the image provided to the eye of the person comprises the obtained images.
-
The device of embodiment 3, wherein the user interface controls are configured to receive the input from at least one of the person, a third party, and a doctor.
-
The device of embodiment 15, wherein the wearable optics are configured to provide refractive correction in real-time as the light forming the image is projected into the eye of the person.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Chromatic Aberrations*
-
A wearable augmented reality device configured to be used by a person, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a person wearing the head-mounted system, said augmented reality display platform comprising optics configured to project an image in said eye, wherein said augmented reality display is configured to project a first color component of the image at a first depth plane and a second color component of the image at a second depth plane different than the first depth plane to compensate for longitudinal chromatic aberration of the person’s eye.
-
The device of embodiment 1, wherein said augmented reality display is configured to output a third color component of the image at a third depth plane different than the first and second depth planes to compensate for longitudinal chromatic aberration of the person’s eye.
-
The device of embodiment 1, wherein said first color component is red.
-
The device of embodiment 1, wherein said second color component is green.
-
The device of embodiment 2, wherein said third color component is blue.
-
The device of embodiment 1, further comprising a user interface for receiving a prescription for said longitudinal chromatic aberration.
-
The device of embodiment 1, wherein said augmented reality head-mounted ophthalmic system is configured to vary the focus of the image automatically to provide incremental change in optical prescription thereby conducting eye exams.
-
The device of embodiment 7, wherein said augmented reality head-mounted ophthalmic system is configured to vary the focus of the first color component of the image automatically to provide incremental change in optical prescription thereby conducting eye exams.
-
The device of embodiment 8, wherein said augmented reality head-mounted ophthalmic system is configured to vary the focus of a monochromatic image of said second color component automatically to provide incremental change in optical prescription thereby conducting eye exams.
-
The device of embodiment 9, wherein said augmented reality head-mounted ophthalmic system is configured to vary the focus of a monochromatic image of a third color component of the image automatically to provide incremental change in optical prescription thereby conducting eye exams.
-
The device of embodiment 10, wherein said images comprise letters.
-
The device of embodiment 10, wherein said images comprise graphic symbols, pictures, or drawings.
-
The device of embodiment 7, further comprising a user interface configured to receive input from the wear regarding the image.
-
The device of embodiment 7, wherein said augmented reality head-mounted ophthalmic system is configured to assess whether the person can view the image comfortably and incrementally increase the prescription, positive or negative, by changing focus if not.
-
The device of any of embodiments any of embodiment 7, wherein said augmented reality head-mounted ophthalmic system is configured to assess whether the person can view the image comfortably and determine the prescription of the person if so.
-
The device of embodiment 1, wherein said wearable augmented reality display platform comprises a fiber scanning device.
-
The device of embodiment 1, wherein said wearable augmented reality device system is configured such that the angle at which light of different color is projected may be varied based lateral chromatic aberration.
-
The device of embodiment 1, wherein said optics comprises an adaptable optics element configured to project the light.
-
The device of embodiment 18, wherein the adaptable optics element comprises a variable focus element.
-
The device of any of embodiments any of embodiment 1, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes.
-
The device of embodiment 20, wherein the waveguide stack further comprises one or more lenses.
-
A wearable augmented reality device configured to be used by a person, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a person wearing the head-mounted system, said augmented reality display platform comprising optics configured to project an image in said eye, wherein said augmented reality display is configured to project a first color component of the image at a first angle and a second color component of the image at a second angle different than the first angle to compensate for lateral chromatic aberration of the person’s eye.
-
The device of embodiment 22, further comprising a user interface for receiving a prescription for said lateral chromatic aberration.
-
The device of any of embodiments 22, wherein said augmented reality head-mounted ophthalmic system is configured to vary the angle of the image automatically to provide incremental change in optical prescription thereby conducting eye exams.
-
A wearable virtual reality device configured to be used by a person, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform, said virtual reality display platform comprising optics configured to project an image in an eye of the person, wherein said virtual reality display is configured to project a first color image at a first depth plane and a second color image at a second depth plane different than the first depth plane to compensate for longitudinal chromatic aberration of the person’s eye.
-
A wearable virtual reality device configured to be used by a person, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform, said virtual reality platform comprising optics configured to project an image in an eye of the person, wherein said virtual reality display is configured to project a first color image at a first angle and a second color image at a second angle different than the first angle to compensate for lateral chromatic aberration of the person’s eye.
-
The device of any of embodiments 1, further comprising one or more outwardly facing cameras configured to obtain an image, wherein said image projected into said eye comprises the obtained image.
-
The device of embodiment 17, wherein varying said angle at which light of different color is projected displaces an image formed by said light of different color along the focal plane of said optics.
-
The device of embodiment 17, wherein said optics comprises an adaptable optics configured to receive an input and vary the angle at which light of the first color component is projected based on lateral chromatic aberration.
-
A wearable device configured to be used by a person, said device comprising: a head-mounted ophthalmic system comprising: a display platform comprising optics configured to project an image in said eye, and a processor circuit configured to drive the optics based on an image modification program, wherein said image modification program is configured to compensate for chromatic aberration imparted on to said image by an optical surface.
-
The device of embodiment 30, wherein said head-mounted ophthalmic system further comprises a memory circuit operatively connected to the processor circuit and configured to store said image modification program.
-
The device of embodiment 30, wherein said image modification program is based on an optical prescription of the person, wherein said optical surface comprises a surface of said eye.
-
The device of embodiment 30, wherein said image modification program is based on chromatic aberrations imparted on to said image by said optics, wherein said optical surface comprises a surface of said optics.
-
The device of embodiment 30, wherein said optics comprises a variable focus element, wherein the image modification program is configured to drive the variable focus element by selectively projecting a first color component of the image at a first depth plane and a second color component of the image at a second depth plane different than the first depth plane to compensate for longitudinal chromatic aberrations.
-
A wearable device configured to be used by a person, said device comprising: a head-mounted ophthalmic system comprising: a memory circuit configured to store an image, a display platform comprising optics configured to project said image in an eye of the person, and a processor circuit operatively coupled to the memory circuit and configured to modify said image to compensate for chromatic aberration in the person’s eye.
-
The device of embodiment 35, wherein the processor is configured to apply an image modification program based on an optical prescription of the person.
-
A wearable device configured to be used by a person, said device comprising: a head-mounted ophthalmic system comprising a display platform, said display platform comprising optics configured to project an image in an eye of the person, wherein said display platform is configured to project a first color component of the image at a first intensity and a second color component of the image at a second intensity different than the first intensity to compensate for chromatic aberration of the person’s eye.
-
The device of embodiment 37, wherein said chromatic aberrations of the person’s eye causes said first color component to focus before a retina of said eye, wherein said first intensity is greater than said second intensity.
-
The device of embodiment 37, wherein said chromatic aberrations of the person’s eye causes said first color component to focus after a retina of said eye, wherein said first intensity is less than said second intensity.
-
The device of embodiment 7, further comprising a biofeedback system configured to provide an input to the augmented reality head-mounted ophthalmic system, wherein the incremental change in the optical prescription is based on the input.
-
The device of embodiment 7, further comprising a biofeedback system configured to objectively monitor one or more properties of said eye, wherein the optical prescription is based on the monitored one or more properties.
-
The device of embodiment 41, wherein the biofeedback system receives inputs from at least one of a phoropter, an auto-refractor, and an eye tracking system.
-
The device of embodiment 41, wherein the one or more properties of said eye is at least one of: changes in a convergence point of the eye, changes in a position of a head of the person, change in a size of a pupil of the eye.
-
The device of embodiment 24, further comprising a biofeedback system configured to objectively monitor one or more properties of said eye, wherein the prescription is based on the monitored one or more properties of the eye.
-
The device of embodiment 32, further comprising a biofeedback system configured to objectively monitor one or more properties of said eye, wherein the optical prescription is based on the monitored one or more properties of the eye.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Phoropter*
-
A wearable augmented reality device configured to be used by a wearer having left and right eyes, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system, said augmented reality display platform optics configured to project an image in said eye, wherein said augmented reality head-mounted ophthalmic system is configured to vary the focus of the image automatically to provide incremental changes in optical prescription thereby conducting eye exams.
-
The device of embodiment 1, wherein said wearable augmented reality display platform comprises a fiber scanning display.
-
The device of any of embodiments 1-2, wherein said optics comprises an adaptable optics element configured to project the light.
-
The device of embodiment 3, wherein the adaptable optics element comprises a variable focus element.
-
The device of any of embodiments any of embodiments 1-4, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes.
-
The device of embodiment 5, wherein the waveguide stack further comprises one or more lenses.
-
The device of any of embodiments any of embodiments 1-6, wherein said augmented reality head-mounted ophthalmic system is configured to project a variety of images of varying sizes and/or intensity.
-
The device of embodiments 7, wherein said images comprise letters.
-
The device of any of embodiments any of embodiments 1-8, further comprising a user interface configured to receive input from the wear regarding the image.
-
The device of any of embodiments any of embodiments 1-9, wherein said augmented reality head-mounted ophthalmic system is configured to assess whether the patient can view the image with normal visual acuity and to incrementally change the prescription, positive or negative, by changing focus based on the assessment.
-
The device of any of embodiments any of embodiments 1-10, wherein said augmented reality head-mounted ophthalmic system is configured to assess whether the patient can view the image with normal visual acuity and to determine the prescription of the wearer based on the assessment.
-
The device of any of embodiments any of embodiments 1-11, wherein said augmented reality head-mounted ophthalmic system is configured to automatically perform adjustments to the prescription based on physical changes of the eye.
-
The device of embodiment 12, wherein said augmented reality head-mounted ophthalmic system is configured to track eye behavior such that adjustments may be automatically made by the ophthalmic system.
-
The device of any of embodiments 1-12, further comprising a fiber light source, wherein said augmented reality head-mounted ophthalmic system varies the focus of the image by varying fiber length or position.
-
The device of any of embodiments 1-12, further comprising a microelectromechanical systems (MEMS) device, wherein said augmented reality head-mounted ophthalmic system varies the focus of the image by varying said MEMS device.
-
The device of any of embodiments 1-15, wherein the eye exams include visual acuity exams, brightness tests, and/or glare tests.
-
The device of any of embodiments 1-16, wherein said augmented reality head-mounted ophthalmic system is configured to automatically determine a focus quality of the projected image.
-
The device of embodiment 17, wherein the focus quality of the projected image is determined through analysis of accommodation, vergence, and/or pupil size of the eye of the wearer.
-
The device of any of embodiments any of embodiments 1-18, wherein said augmented reality head-mounted ophthalmic system is configured to measure accommodation reflex by measuring accommodation, vergence, and/or pupil size.
-
A wearable virtual reality device configured to be used by a wearer having left and right eyes, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform, said virtual reality display platform optics configured to project an image in said eye, wearable augmented reality display platform comprises a fiber scanning display, wherein said virtual reality head-mounted ophthalmic system is configured to vary the focus of the image automatically to provide incremental change in optical prescription thereby conducting eye exams.
-
A wearable virtual reality device configured to be used by a wearer having left and right eyes, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform, said virtual reality display platform optics configured to project an image in said eye, wearable augmented reality display platform comprises a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes, wherein said virtual reality head-mounted ophthalmic system is configured to vary the focus of the image automatically to provide incremental change in optical prescription thereby conducting eye exams.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Red Reflex*
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system, said eye comprising a retina and a cornea; a light source configured to project light into the eye of the wearer, at least a portion of said light reflecting from at least a portion of said eye so as to produce a reflection; and a camera configured to capture an image of the reflection, said device being configured to perform a diagnostic test of the wearer’s eye to detect abnormalities of the eye.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform comprising a display for providing images to the eye of the wearer, said eye comprising a retina and a cornea; a light source configured to project light into the eye of the wearer, at least a portion of said light reflecting from at least a portion of said eye so as to produce a reflection; and a camera configured to capture an image of the reflection, said device being configured to perform a diagnostic test of the wearer’s eye to detect abnormalities of the eye.
-
The device of embodiment 1 or 2, wherein said light source is configured to direct said light into said eye along the normal line of sight of said eye.
-
The device of embodiment 1 or 2, wherein said light source is configured to direct said light into said eye at a first angle at a first time and at a second different angle at a second time.
-
The device of embodiment 1 or 2, wherein said light source is configured to project said light to a first portion of the wearer’s eye at a first time and to project said light to a second different portion of the wearer’s eye at a second time.
-
The device of embodiment 1 or 2, wherein the light source is configured to project light into two eyes of the wearer, each of the two eyes comprising a retina and a cornea.
-
The device of embodiment 1 or 2, further comprising a second light source configured to project light into a second eye of the wearer, said second eye comprising a second retina and a second cornea, at least a portion of said light reflecting from at least a portion of said second eye so as to produce a reflection.
-
The device of any of embodiments 1-6, wherein said light source comprises a display.
-
The device of embodiment 8, wherein said display comprises a fiber scanning display.
-
The device of embodiment 1 or 2, wherein said camera comprises an eye tracking camera.
-
The device of embodiment 1 or 2, further comprising an eye tracking camera.
-
The device of embodiment 1 or 2, wherein said abnormality of the eye comprises glaucoma, a cataract, cancer of the eye, retinoblastoma, a detached retina, aberrations of the eye, or corneal scarring.
-
The device of any of embodiments 1-12, wherein said light source is configured to project light into wearer’s left and right eye.
-
The device of any of embodiments 1-13, wherein said camera is configured to capture an image of the reflection and to perform a red reflex test of the wearer’s left and right eye.
-
The device of embodiment 13 or 14, wherein said abnormality of the eye comprises eye misalignment, strabismus, or asymmetry.
-
The device of embodiment 1 or 2, further comprising an adaptable optics element.
-
The device of embodiment 16, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 16 or 17, wherein said adaptable optics element is configured to direct said light into said eye at a first angle at a first time and at a second different angle at a second time.
-
The device of embodiment 16 or 17, wherein said adaptable optics element is configured to project said light to a first portion of the wearer’s eye at a first time and to project said light to a second different portion of the wearer’s eye at a second time.
-
The device of any of embodiments 1-19, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light as if from different depth planes.
-
The device of embodiment 20, wherein the waveguide stack further comprises one or more lenses.
-
The device of embodiment 20 or 21, wherein the waveguide stack is configured to provide a fixation target for the wearer at different depth planes.
-
The device of any of embodiments 19-21, wherein the waveguide stack is configured to vary the depth plane of said fixation target thereby causing the wearer’s eye to accommodate.
-
The device of any of embodiments 19-23, wherein said fixation target is located away from the center of the wearer’s field of view.
-
The device of embodiment 1 or 2, wherein at least one of said waveguides is configured to capture said image of the reflection.
-
The device of embodiment 25, wherein a plurality of said waveguides are configured to capture a plurality of images of the reflection at different depth planes.
-
The device of embodiment 26, wherein said at least one of said waveguides includes an optical element having optical power, said optical power corresponding to a depth plane of between 8 inches to 4 feet from said eye.
-
The device of embodiment 1 or 2, wherein said display platform is configured to provide a first fixation target at a first location at a first time and a second fixation target at a second different location at a second time that causes the eye to move.
-
The device of any of embodiments 1-28, wherein said camera comprises a light pipe.
-
The device of any of embodiments 1-29, wherein said light source comprises a light pipe.
-
The device of any of embodiments 1-30, wherein said light comprises visible light.
-
The device of embodiment 31, wherein said light comprises white light.
-
The device of embodiment 32, further comprising at least one mechanical filter configured to limit the spectrum of reflected light detected at the camera.
-
The device of embodiment 32, wherein the device is configured to digitally filter images captured by the camera to remove light of at least one wavelength range from the images.
-
The device of any of embodiments 1-32, wherein said light comprises infrared light.
-
The device of any of embodiments 1-33, wherein said at least a portion of said light reflects from said retina, and wherein said diagnostic test comprises a red reflex test.
-
The device of any of embodiments 1-313 wherein said at least a portion of said light reflects from said cornea, and wherein said diagnostic test comprises a Hirschberg corneal reflex test.
-
The device of any of embodiments 1-35, wherein said device is further configured to compare the results of said diagnostic test with a database of normal or abnormal results.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Intraocular Pressure*
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system, said eye comprising a cornea, said augmented reality head-mounted ophthalmic system configured to apply a force to the cornea of said eye; and a sensor configured to determine applanation of said cornea to determine intraocular pressure of the eye.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform comprising a display for providing images to the eye of the wearer, said eye comprising a cornea, said virtual reality head-mounted ophthalmic system configured to apply a force to the cornea of said eye; and a sensor configured to determine applanation of said cornea to determine intraocular pressure of the eye.
-
The device of embodiment 1 or 2, wherein said head-mounted ophthalmic system is configured to apply a pulse of air to flatten the cornea.
-
The device of embodiment 1 or 2, wherein said head-mounted ophthalmic system is configured to apply mechanical force to the cornea of said eye through an eyelid of the wearer.
-
The device of embodiment 4, wherein said head-mounted ophthalmic system comprises a transducer.
-
The device of any of embodiments 1-4, wherein said sensor utilizes ultrasonic range imaging.
-
The device of any of embodiments 1-4, wherein said sensor utilizes photoacoustic imaging.
-
The device of any of embodiments 1-4, wherein said sensor comprises an imaging head.
-
The device of embodiment 8, wherein said imaging head comprises an interferometry 3D imaging head.
-
The device of any of embodiments 1-9, further comprising a light source configured to project beams of light into the wearer’s eyes.
-
The device of any of embodiments 1-9, further comprising a fiber scanning display configured to project beams of light into the wearer’s eyes.
-
The device of embodiment 10, further comprising an adaptable optics element.
-
The device of embodiment 12, wherein the adaptable optics element is configured to project the light.
-
The device of embodiment 13, wherein the adaptable optics element comprises a variable focus element.
-
The device of any of embodiments 1-14, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes.
-
The device of embodiment 15, wherein the waveguide stack further comprises one or more lenses.
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; a light source configured to project light into the eye of the wearer; and a light-monitoring device configured to measure reflected light, wherein said augmented reality head-mounted ophthalmic system is configured to determine intraocular pressure from said measured reflected light.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform comprising a display for providing images to the eye of the wearer, a light source configured to project light into the eye of the wearer; and a light-monitoring device configured to measure reflected light, wherein said virtual reality head-mounted ophthalmic system is configured to determine intraocular pressure from said measured reflected light.
-
The device of embodiment 17 or 18, wherein said light source comprises a fiber scanning display configured to project beams of light into the wearer’s eyes.
-
The device of embodiment 19, wherein the fiber length of the fiber scanning display can be varied.
-
The device of embodiment 19, wherein said light-monitoring device comprises said fiber scanning display.
-
The device of embodiment 17 or 17, wherein said light-monitoring device comprises a fiber scanning display or photo-detectors.
-
The device of embodiment 17 or 18, wherein the wavelength of said light projected into said eye can be changed.
-
The device of embodiment 17 or 18, further comprising an adaptable optics element configured to project the light into the wearer’s eye.
-
The device of embodiment 24, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 17 or 18, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes.
-
The device of embodiment 26, wherein the waveguide stack further comprises one or more lenses.
-
The device of any of embodiments 17-27, wherein the light-monitoring device is configured to measure backscattered light.
-
The device of any of embodiments 17-27, wherein the light-monitoring device is configured to detect on or more Purkinje images of the wearer’s eye.
-
The device of embodiment 29, wherein the head-mounted ophthalmic system is configured to determine intraocular pressure at least in part based on the shape or location of said one or more Purkinje images.
-
The device of embodiment 29 or 30, wherein said one or more Purkinje images comprises a glint.
-
The device of any of embodiments 1-31, wherein said ophthalmic system is further configured to detect the presence of ocular hypertension at least in part based on said determined intraocular pressure.
-
The device of any of embodiments 1-31, wherein said ophthalmic system is further configured to determine an ocular pulse rate at least in part based on comparing a plurality of intraocular pressures determined from measurements taken at a regular time interval.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Pinhole Occluder*
-
A wearable augmented reality device configured to be used by a person, said display device comprising: an augmented reality head-mounted ophthalmic system comprising a augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into at least one eye of a person wearing the head-mounted system; a light source configured to project light into the eye of the person to form an image in the eye; and a user interface configured to receive input from a person, wherein the wearable augmented reality device is configured to occlude a particular portion of the person’s eye and to receive input from the person regarding the wear’s vision through the user interface.
-
The device of embodiment 1, wherein the wearable augmented reality device is configured to occlude a central region.
-
The device of embodiment 1, wherein the wearable augmented reality device is configured to occlude a peripheral region.
-
The device of embodiment 1, wherein the wearable augmented reality device is configured to occlude the particular portion of the person’s eye digitally.
-
The device of embodiment 1, wherein the wearable augmented reality device is configured to occlude the particular portion of the person’s eye manually.
-
A wearable virtual reality device configured to be used by a person, said display device comprising: a head-mounted display comprising a virtual reality display platform; and a light source configured to project light into the eye of the person to form an image in the eye, and a user interface configured to receive input from a person, wherein the wearable virtual reality device is configured to occlude a particular portion of the person’s eye and to receive input from the person regarding the wear’s vision through the user interface.
-
The device of embodiment 6 wherein the wearable augmented reality device is configured to occlude a central region.
-
The device of embodiment 6, wherein the wearable augmented reality device is configured to occlude a peripheral region.
-
The device of embodiment 6, wherein an image is presented to the person and the wearable virtual reality device is configured to receive input from the person regarding the image through the user interface.
-
A wearable display device configured to be used by a person, said display device comprising: a head-mounted ophthalmic system; a light source configured to direct light into an eye of said person to form an image in the eye; a user interface configured to receive input from a person, and an adaptable optics element configured to project the image to a particular portion of the person’s eye, wherein the wearable display device is configured to occlude a particular portion of the person’s eye and to receive input from the person regarding the wear’s vision through the user interface.
-
The device of embodiment 10, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 11, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 12, further comprising: one or more electrodes coupled to the membrane mirror; and a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror based on a corneal shape of the eye.
-
A wearable display device configured to be used by a person, said display device comprising: a head-mounted display system; and a light source configured to direct light into an eye of a person to form an image in the eye, the light source comprising a fiber scanning projector; and a user interface configured to receive input from a person, wherein the wearable display device is configured to occlude a particular portion of the person’s eye and to receive input from the person regarding the wear’s vision through the user interface.
-
A wearable display device configured to be used by a person, said display device comprising: a head-mounted display system; and a light source configured to direct light into one eye of said person to form an image in the eye; a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project the light at different focal planes; and a user interface configured to receive input from a person, wherein the wearable display device is configured to occlude a particular portion of the person’s eye and to receive input from the person regarding the wear’s vision through the user interface.
-
The device of embodiment 15, wherein the waveguide stack further comprises one or more lenses.
-
The device of embodiment 15, wherein the head-mounted display system comprises an augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a person wearing the head-mounted system.
-
A wearable augmented reality device configured to be used by a person, said display device comprising: an augmented reality head-mounted ophthalmic system comprising a augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a person wearing the head-mounted system; and a light source configured to project light into the eye of the person to form an image in the eye, wherein the wearable augmented reality device is configured to occlude a particular portion of the person’s eye.
-
The device of embodiment 18, wherein the wearable augmented reality device is configured to occlude a central region.
-
The device of embodiment 18, wherein the wearable augmented reality device is configured to occlude a peripheral region.
-
The device of embodiment 18, wherein the wearable augmented reality device is configured to occlude the particular portion of the person’s eye digitally.
-
The device of embodiment 18, wherein the wearable augmented reality device is configured to occlude the particular portion of the person’s eye manually.
-
The device of embodiment 1, wherein the augmented reality device is configured to obstruct a portion of the light corresponding to the particular portion of the person’s eye.
-
The device of embodiment 2, wherein occluding the central region improves the person’s vision of the image, being indicative of a visual defect in the eye of the person.
-
The device of embodiment 18, wherein the wearable augmented reality device is configured to occlude a particular portion of the person’s eye based on an optical prescription of the person.
-
The device of embodiment 18, wherein the wearable augmented reality device is configured to occlude a particular portion of the person’s eye by stopping down a peripheral portion of the light forming the image
-
The device of embodiment 18, wherein the wearable augmented reality device is configured to adjust intensity of ambient light from the world surrounding the person.
-
The device of embodiment 18, wherein the wearable augmented reality device is configured to occlude the particular portion of the eye based on inputs from the world surrounding of the person.
-
The device of embodiment 28, wherein inputs from surroundings includes at least one of changes in gaze orientation, ambient light from the surroundings, and accommodation.
-
The device of embodiment 21, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project the light at different focal plane, wherein digitally occluding the particular portion of the eye comprises selectively projecting light at different focal planes, wherein the particular portion of the eye corresponds to a selected focal plane.
-
The device of embodiment 18, wherein the wearable augmented reality device is configured to modify a color of a portion of the image corresponding to the particular portion of the eye.
-
The device of embodiment 18, wherein the wearable augmented reality device is configured to modify an intensity of a portion of the image corresponding to the particular portion of the eye.
-
The device of embodiment 9, further comprising a camera configured to receive a reflected image based on the image presented to the person having passed through the particular portion of the person’s eye and reflected by the retina of said eye, wherein the received input is based on a comparison of the reflected image and an expected reflected image, the expected reflected image being based on a healthy eye.
-
The device of embodiment 14, wherein an image is presented to the person and the wearable virtual reality device is configured to receive input from the person regarding the image through the user interface.
-
The device of embodiment 34, further comprising a camera configured to receive a reflected image based on the image presented to the person having passed through the particular portion of the person’s eye and reflected by the retina of said eye, wherein the received input is based on a comparison of the reflected image and an expected reflected image, the expected reflected image being based on a healthy eye.
-
The device of embodiment 21, wherein the wearable augmented reality device is configured to modify a focus of a portion of the image corresponding to the particular portion of the eye.
-
The device of embodiment 21, wherein the wearable augmented reality device is configured to modify a contrast of a portion of the image corresponding to the particular portion of the eye relative to another portion of the image that does not correspond to the particular portion of the eye.
-
A wearable virtual reality device configured to be used by a person, said display device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform; and a light source configured to project light into the eye of the person to form an image in the eye, wherein the wearable virtual reality device is configured to occlude a particular portion of the person’s eye.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
Initial W4LT Test
-
A wearable augmented reality device configured to be used by a wearer having left and right eyes, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; and first and second displays included in said augmented reality display platform for said left and right eyes respectively, wherein said augmented reality head-mounted ophthalmic system is configured to project independent first and second images into said left and right eyes respectively and to identify a vision defect.
-
The device of embodiment 1, wherein said augmented reality head-mounted ophthalmic system is configured to assess the wearer’s degree of binocular vision and binocular single vision.
-
The device of embodiment 1, wherein said augmented reality head-mounted ophthalmic system is configured to administer a Worth Four Light Test or a Worth Four Dot Test.
-
The device of embodiment 1, wherein said images comprise colored dots.
-
The device of embodiment 1, wherein said augmented reality head-mounted ophthalmic system is configured to detect suppression of either the right eye or the left eye.
-
The device of embodiment 1, wherein said augmented reality head-mounted ophthalmic system is configured to receive input from the wearer, to analyze the received input, and to identify said vision defect of the wearer.
-
The device of embodiment 1, wherein said augmented reality head-mounted ophthalmic system is configured to project said independent first and second images from different depth planes.
-
The device of any of embodiments 1-7, further comprising a fiber scanning display configured to project light into the wearers eyes.
-
The device of any of embodiments 1-8, further comprising an adaptable optics element configured to project the independent first and second images.
-
The device of embodiment 9, wherein the adaptable optics element comprises a variable focus element.
-
The device of any of embodiments 1-10, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes.
-
The device of embodiment 11, wherein the waveguide stack further comprises one or more lenses.
-
The device of any of embodiments 1-12, wherein said augmented reality head-mounted ophthalmic system is configured to automatically determine said vision defect of the wearer through analysis of the independent first and second images as imaged on corresponding retinas of the wearer.
-
A wearable virtual reality device configured to be used by a wearer having left and right eyes, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform comprising a display for providing images to an eye of the wearer; and first and second displays included in said virtual reality display platform for said left and right eyes respectively, wherein said virtual reality head-mounted ophthalmic system is configured to project independent first and second images into said left and right eyes respectively and to identify a vision defect.
-
The device of embodiment 14, wherein said virtual reality head-mounted ophthalmic system is configured to assess the wearers degree of binocular vision and binocular single vision.
-
The device of embodiment 14, wherein said virtual reality head-mounted ophthalmic system is configured to administer a Worth Four Light Test or a Worth Four Dot Test.
-
The device of embodiment 14, wherein said images comprise colored dots.
-
The device of embodiment 14, wherein said virtual reality head-mounted ophthalmic system is configured to detect suppression of either the right eye or the left eye.
-
The device of embodiment 14, wherein said virtual reality head-mounted ophthalmic system is configured to receive input from the wearer, to analyze the received input, and to identify said vision defect of the wearer.
-
The device of embodiment 14, wherein said virtual reality head-mounted ophthalmic system is configured to project said independent first and second images from different depth planes.
-
The device of any of embodiments 14-20, further comprising a fiber scanning display configured to project light into the wearer’s eyes.
-
The device of any of embodiments 14-21, further comprising an adaptable optics element configured to project the independent first and second images.
-
The device of embodiment 22, wherein the adaptable optics element comprises a variable focus element.
-
The device of any of embodiments 14-23, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes.
-
The device of embodiment 24, wherein the waveguide stack further comprises one or more lenses.
-
The device of any of embodiments 14-25, wherein said augmented reality head-mounted ophthalmic system is configured to automatically determine said vision defect of the wearer through analysis of the independent first and second images as imaged on corresponding retinas of the wearer.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Retinoscopy*
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system, said eye having a retina; at least one light source configured to project light into the eye of the wearer to form an image in the eye, said at least one light source configured to sweep light across the retina of the eye of the wearer producing a reflex of the retina; and a sensor configured to measure a response of the retina to the swept light such that said augmented reality head-mounted ophthalmic system can perform retinoscopy to measure refractive error of said eye.
-
The device of embodiment 1, wherein said image can be dynamically modified to provide dynamic retinoscopy.
-
The device of any of embodiments 1-2, wherein said at least one light source comprises a fiber scanning display.
-
The device of any of embodiments 1-3, wherein said at least one light source comprises a fiber scanning display and a light generating source.
-
The device of any of embodiments 1-4, further comprising an adaptable optics element configured to project the image to a targeted portion of the wearer’s eye.
-
The device of embodiment 5, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 6, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 7 further comprising: one or more electrodes coupled to the membrane mirror; and a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror based on a corneal shape of the eye.
-
The device of any of embodiments any of embodiments 1-8, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes.
-
The device of embodiment 9, wherein the waveguide stack further comprises one or more lenses.
-
The device of any of embodiments any of embodiments 1-10, wherein the wearable augmented reality device is configured to determine whether the measured refractive error has improved in response to a change in optical power.
-
The device of embodiment any of embodiments 11, wherein the wearable augmented reality device is configured to modify an applied optical power to reduce the measured refractive error.
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system, wherein said augmented reality head-mounted ophthalmic system is configured to perform retinoscopy to measure refractive error of said eye.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform comprising a display for providing images to an eye of the wearer, said eye having a retina; at least one light source configured to project light into the eye of the wearer to form an image in the eye, said at least one light source configured to sweep light across the retina of the eye of the wearer producing a reflex of the retina; and a sensor configured to measure a response of the retina to the swept light such that said virtual reality head-mounted ophthalmic system can perform retinoscopy to measure refractive error of said eye.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform comprising a display for providing images to an eye of the wearer, said eye having a retina; wherein said virtual reality head-mounted ophthalmic system is configured to perform retinoscopy to measure refractive error of said eye.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Slit Lamp*
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; an optical source configured to project an illumination beam of light into the eye of the wearer to illuminate an anterior or posterior portion of the eye, a cross-sectional beam shape of the illumination beam configured such that a dimension of the cross-sectional beam shape along a superior-inferior direction of the eye is greater than a dimension of the cross-sectional beam shape along a nasal-temporal direction of the eye; and an imaging system configured to capture an image of the illuminated portion of the wearer’s eye so as to perform a slit lamp examination to determine health of said eye.
-
The device of embodiment 1, wherein the illumination beam from said optical source is incident on a location on the surface of the eye at an angle with respect to a normal to the surface of the eye at the location.
-
The device of embodiment 2, wherein the illumination beam from said optical source is incident on the location on the surface of the eye at an angle between about .+-.10-degrees and about .+-.90-degrees with respect to the normal to the surface of the eye at the location.
-
The device of embodiment 2, wherein the illumination beam from said optical source is incident along an axis intersecting the eye and passing through the pupil.
-
The device of embodiment 1, wherein the illumination beam from said optical source has a width along a temporal-nasal axis of the wearer’s eye, wherein the width is between about 25 microns and about 1.0** mm**
-
The device of embodiment 1, wherein the imaging system comprises a camera configured to track the wearer’s eye.
-
The device of embodiment 1, wherein said device is further configured to determine the health of the eye by matching a known pattern with the image captured by the imaging system.
-
The device of embodiment 1, wherein said device is further configured to compare the image captured by the imaging system with a previously obtained image of the eye.
-
The device of embodiment 1, wherein said light source comprises a fiber scanning device.
-
The device of embodiment 1, further comprising an adaptable optics element configured to project the illumination beam to a particular portion of the wearer’s eye.
-
The device of embodiment 10, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 11, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 12, further comprising: one or more electrodes coupled to the membrane mirror; and a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror.
-
The device of embodiment 10, wherein the adaptable optics element is configured to change the angle of incidence of the illumination beam at the particular portion of the wearer’s eye.
-
The device of embodiment 10, wherein the adaptable optics element is configured to change the width of the illumination beam.
-
The device of embodiment 10, wherein the adaptable optics element is configured to change the depth in the wearer’s eye at which the illumination beam is focused.
-
The device of any of embodiments 1 to 17, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different focal planes.
-
The device of embodiment 17, wherein the waveguide stack further comprises one or more lenses.
-
The device of embodiment 1, wherein the illumination beam comprises a thin sheet of light.
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; a scanning fiber device configured to project light into the eye of the wearer to illuminate the eye to perform a slit lamp examination of the eye; and a camera configured to capture an image of the illuminated portion of the wearer’s eye so as to determine health of said eye.
-
The device of embodiment 20, wherein said fiber scanning device is configured to project an illumination beam into the eye of the wearer.
-
The device of embodiment 20, wherein the illumination beam has a width along a nasal-temporal direction of the eye of the wearer, wherein the width is between about 25 microns and about 1.0** mm**
-
The device of embodiment 20, wherein the illumination beam has a rectangular cross-sectional shape.
-
The device of embodiment 23, wherein a dimension of the rectangular cross-sectional shape along a superior-inferior direction of the eye is greater than a dimension of the rectangular cross-sectional beam shape along a nasal-temporal direction of the eye.
-
The device of embodiment 20, wherein said scanning fiber device is configured to project light into the eye of the wearer at a non-normal angle to the surface of the eye at the incidence location.
-
The device of embodiment 20, wherein said device is further configured to determine the health of the eye by matching a known pattern with the image captured by the camera.
-
The device of embodiment 20, wherein said device is further configured to compare the image captured by the imaging system with a previously obtained image of the eye.
-
The device of any of the embodiments, wherein said device is configured to detect changes in the wearer’s eye at least twice a year.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform comprising a display for providing images to the eye of the wearer; an optical source configured to project an illumination beam of light into the eye of the wearer to illuminate an anterior or posterior portion of the eye, a cross-sectional beam shape of the illumination beam configured such that a dimension of the cross-sectional beam shape along a superior-inferior direction of the eye is greater than a dimension of the cross-sectional beam shape along a nasal-temporal direction of the eye; and an imaging system configured to capture an image of the illuminated portion of the wearer’s eye so as to perform a slit lamp examination to determine health of said eye.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising an virtual reality display platform comprising a display for providing images to the eye of the wearer; at scanning fiber device configured to project light into the eye of the wearer to illuminate the eye to perform a slit lamp examination of the eye; and a camera configured to obtain an image of the illuminated portion of the wearer’s eye so as to determine health of said eye.
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; a light source configured to project a thin sheet of light into the eye of the wearer to illuminate an anterior or posterior portion of the eye; and a camera configured to capture an image of the illuminated portion of the wearer’s eye so as to perform a slit lamp examination to determine health of said eye.
-
The device of embodiment 21, wherein the sheet of light from said optical source is incident on a location on the surface of the eye at an angle with respect to a normal to the surface of the eye at the location.
-
The device of embodiment 21, wherein the sheet of light from said optical source has a width along a temporal-nasal axis of the wearer’s eye, wherein the width is between about 25 microns and about 1.0** mm**
-
The device of embodiment 21, wherein the camera is further configured to track the wearer’s eye.
-
The device of embodiment 31, wherein said device is further configured to determine the health of the eye by matching a known pattern with the image captured by the imaging system.
-
The device of embodiment 31, wherein said device is further configured to compare the image captured by the imaging system with a previously obtained image of the eye.
-
The device of embodiment 31, wherein said light source comprises a fiber scanning device.
-
The device of embodiment 31, further comprising an adaptable optics element configured to project the thin sheet of light to a particular portion of the wearer’s eye.
-
The device of embodiment 38, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 39, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 31, further comprising: one or more electrodes coupled to the membrane mirror; and a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror.
-
The device of any of the embodiments above, wherein said camera comprises a visible camera.
-
The device of any of the embodiments above, wherein said camera comprises an infrared camera.
-
The device of any of the embodiments above, wherein said device is configured to detect changes in the wearer’s eye at least twice a year.
-
The device any of the embodiments above, further comprising a frame, said display supported by said frame.
-
The device of Embodiment 45, wherein the optical source is disposed on the frame.
-
The device of Embodiments 45-46, wherein the imaging system is disposed on the frame.
-
The device of Embodiments 45-47, wherein the frame includes one or more ear stems.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Color Blindness*
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform comprising a display, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system, said wearable augmented reality display platform comprising a display comprising at least one light source, wherein said wearable augmented reality device is configured to administer a color test to test for deficiencies of the wearer in detecting specific colors.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform comprising a display, said wearable virtual reality display platform comprising a display comprising at least one light source, wherein said wearable virtual reality device is configured to administer a color test to test for deficiencies of the wearer in detecting specific colors.
-
The device of embodiment 1 or 2, wherein said head-mounted ophthalmic system is configured such that said display provides images of Ishihara color plates.
-
The device of embodiment 1 or 2, wherein said head-mounted ophthalmic system is configured such that said display provides virtual images of Ishihara color plates.
-
The device of any of embodiments 1-4, wherein said head-mounted ophthalmic system is configured to receive user input regarding said color plates or color image.
-
The device of any of embodiments 1-5, wherein said head-mounted ophthalmic system is configured to determine whether the wearer has defects based on the color test.
-
The device of embodiment 1 or 2, wherein said head-mounted ophthalmic system is configured to administer an anomaloscope test, said head-mounted ophthalmic system being configured to project light of a control color onto a first portion of said retina, and to project light of variable color onto a second portion of said retina, said variable color being controllable by the wearer.
-
The device of any of embodiments 1-7, where said at least one light source comprises a fiber scanning display configured to project light into the wearer’s eyes.
-
The device of any of embodiments 1-7, where said at least one light source comprises multiple fiber scanning displays configured to project different color light into the wearer’s eyes.
-
The device of any of the above embodiments, where said head-mounted ophthalmic system is configured to provide a background to enhance the visibility of said color test.
-
The device of embodiment 10, wherein said background is provided using one or more spatial light modulators configured to selectively attenuate light.
-
The device of any of the above embodiments, further comprising an adaptable optics element.
-
The device of embodiment 12, wherein the adaptable optics element comprises a variable focus element.
-
The device of any of the above embodiments, wherein said display comprises a waveguide stack comprising a plurality of waveguides, wherein the waveguide stack is configured to project light from different depth planes.
-
The device of embodiment 14, wherein said display is configured to project Ishihara color plates at a plurality of depth planes.
-
The device of embodiment 14, wherein said display is configured to project anomaloscope images at a plurality of depth planes.
-
The device of embodiment 14, wherein the waveguide stack further comprises one or more lenses.
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform and at least one outward-facing camera configured to image light from the world, said augmented reality head-mounted ophthalmic system configured to pass said light from the world into an eye of a wearer wearing the head-mounted system, said wearable augmented reality display platform comprising a display comprising at least one light source, said eye comprising a retina, wherein said wearable augmented reality device is configured to selectively modify said light from the world based on a color detection deficiency of the wearer.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform and at least one outward-facing camera configured to image light from the world and project said light from the world into an eye of a wearer wearing the head-mounted system, said virtual reality head-mounted virtual reality display platform comprising a display comprising at least one light source, said eye comprising a retina, wherein said wearable virtual reality device is configured to selectively modify said light from the world projected to the eye based on a color detection deficiency of the wearer.
-
The device of embodiment 18 or 19, wherein said outward-facing camera is configured to detect the presence in said light from the world of a color for which the wearer has a detection deficiency.
-
The device of embodiment 20, wherein said selective modification comprises projecting light from the light source to increase the amplitude of said light in a region of the display comprising a color for which the wearer has a detection deficiency.
-
The device of embodiment 20, wherein said selective modification comprises changing the color of light in a region of the display.
-
The device of embodiment 22, wherein changing the color of light in a region of the display comprises using an optical filter to remove spectral overlap between a plurality of photopigments.
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass said light from the world into an eye of a wearer wearing the head-mounted system, said wearable augmented reality display platform comprising a display comprising at least one light source, wherein said wearable augmented reality device is configured to selectively modify said light projected from the display based on a color detection deficiency of the wearer.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform system, said virtual reality head-mounted virtual reality display platform comprising a display comprising at least one light source, wherein said wearable virtual reality device is configured to selectively modify said light projected from the display to the eye based on a color detection deficiency of the wearer.
-
The device of embodiment 24 or 25, wherein said selective modification comprises projecting light from the light source to increase the amplitude of said light in a region of the display comprising a color for which the wearer has a detection deficiency.
-
The device of embodiment 24 or 25, wherein said selective modification comprises changing the color of light in a region of the display.
-
The device of embodiment 24 or 25, wherein said selective modification comprises enhancing the color of light projected from at least a portion of the display.
-
The device of embodiment 24, wherein said selective modification comprises decreasing the visibility of at least a portion of said light from the world through destructive interference.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
Ophthalmoscope/Funduscope
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system, wherein said augmented reality head-mounted ophthalmic system is configured to capture an image of an illuminated portion of the wearer’s eye for analysis to monitor health of the wearer’s eye, detect abnormalities of the eye or other health problems.
-
The device of embodiment 1, further comprising a fiber scanning display configured to project a beam of light of a particular focus to at least one portion of the wearer’s eye.
-
The device of embodiment 1, further comprising an eye tracking cameras for capturing said image of the illuminated portion of the wearer’s eye.
-
The device of embodiment 2, wherein said fiber scanning display is configured to capture said image of the illuminated portion of the wearer’s eye.
-
The device of embodiment 1, further comprising a specialized camera for capturing said image of the illuminated portion of the wearer’s eye.
-
The device of any one of embodiments 1-5, further comprising an electronic hardware processor configured to analyze the captured image to detect abnormalities of the eye or health problems.
-
The device of embodiment 6 wherein the electronic processor is configured to detect the abnormality of the eye by matching a known pattern with the image.
-
The device of embodiment 6 wherein the electronic processor is pre-loaded with patterns indicative of health problems.
-
The device of any one of embodiments 1-8 wherein the electronic hardware processor is remote from the augmented reality head-mounted ophthalmic system.
-
The device of embodiment 1-10, further comprising an adaptable optics element.
-
The device of embodiment 11, wherein the adaptable optics element is configured to project the beam of light to a particular portion of the wearer’s eye.
-
The device of embodiment 11, wherein the adaptable optics element comprises a variable focus element.
-
The device of any of embodiments 1 to 13, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light as if originating from different focal planes.
-
The device of embodiment 13 wherein the waveguide stack further comprises one or more lenses.
-
The device of embodiment 1, wherein the fiber scanning is configured to project the beam of light on a fundus of the wearer’s eye.
-
The device of embodiment 1, wherein the projected beam of light comprises a white light.
-
The device of embodiment 1, wherein the projected beam of light comprises a colored light.
-
The device of embodiment 17, wherein the projected beam of light has a wavelength in red, green or blue spectral region of the visible spectrum of light.
-
The device of embodiment 1, wherein the projected beam of light is in a range of wavelengths in the infrared spectrum of light.
-
The device of embodiment 1, wherein the projected beam of light is configured to be focused at different depths in the wearer’s eye.
-
The device of embodiment 1, wherein said augmented reality head-mounted ophthalmic system is configured to capture an image of at least a portion of the fundus of the wearer’s eye.
-
The device of embodiment 21, wherein said augmented reality head-mounted ophthalmic system is configured to capture an image of at least a portion of the retina of the wearer’s eye.
-
The device of embodiment 1, wherein said augmented reality head-mounted ophthalmic system is configured to capture an image from different depths in the wearer’s eye.
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; a light source configured to project a beam of light to at least one portion of the wearer’s eye; and a camera configured to capture an image of an illuminated portion of the wearer’s eye for analysis to monitor health of the wearer’s eye, detect abnormalities of the eye or other health problems.
-
The device of embodiment 24, wherein said light source comprises a fiber scanning device.
-
The device of embodiment 24, wherein said camera comprises eye tracking cameras.
-
The device of embodiment 24, wherein said camera comprises said fiber scanning device.
-
The device of embodiment 24, further comprising an electronic hardware processor configured to analyze the captured image to monitor health of the wearer’s eye or detect the abnormality of the eye.
-
The device of embodiment 28, wherein the electronic hardware processor is configured to analyze the captured image by matching a known pattern, color, shape or size with the captured image.
-
The device of embodiment 29, wherein the electronic hardware processor is pre-loaded with patterns indicative of health problems.
-
The device of embodiment 28, wherein the electronic hardware processor is configured to compare the captured image with one or more images stored in an information store accessible by the electronic hardware processor.
-
The device of embodiment 24 further comprising an adaptable optics element.
-
The device of embodiment 32, wherein the adaptable optics element is configured to project the beam of light to a particular portion of the wearer’s eye.
-
The device of embodiment 32, wherein the adaptable optics element comprises a variable focus element.
-
The device of any of embodiments 24 to 34, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light as if originating from different focal planes.
-
The device of embodiment 35, wherein the waveguide stack further comprises one or more lenses.
-
The device of embodiment 24, wherein the light source is configured to project the beam of light on a fundus of the wearer’s eye.
-
The device of embodiment 24, wherein the projected beam of light comprises a white light.
-
The device of embodiment 24, wherein the projected beam of light comprises a colored light.
-
The device of embodiment 39, wherein the projected beam of light has a wavelength in red, green or blue spectral region of the visible spectrum of light.
-
The device of embodiment 24, wherein the projected beam of light includes a range of wavelengths in the infrared spectrum of light.
-
The device of embodiment 24, wherein the projected beam of light is configured to be focused at different depths in the wearer’s eye.
-
The device of embodiment 24, wherein said camera is configured to capture an image of at least a portion of the fundus of the wearer’s eye.
-
The device of embodiment 24, wherein said camera is configured to capture an image from different depths in the wearer’s eye.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform comprising a display for providing images to the eye of the wearer; and a fiber scanning display configured to project a beam of light of a particular focus to at least one portion of the wearer’s eye, wherein said virtual reality head-mounted ophthalmic system is configured to capture an image of an illuminated portion of the wearer’s eye for analysis to monitor health of the wearer’s eye, detect abnormalities of the eye or other health problems.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform comprising a display for providing images to the eye of the wearer; a light source configured to project a beam of light of a particular focus to at least one portion of the wearer’s eye; and an imaging system configured to capture an image of an illuminated portion of the wearer’s eye for analysis to monitor health of the wearer’s eye, detect abnormalities of the eye or other health problems.
-
The device of any of the embodiments above, wherein the portion of the eye for which an image is captured by the device comprises the fundus.
-
The device of any of the embodiments above, wherein the portion of the eye for which an image is captured by the device comprises the retina.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
Confocal Microscopy/SLO
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system, said augmented reality head-mounted ophthalmic system comprising a confocal microscope configured to image the eye.
-
The device of embodiment 1, wherein said confocal microscope comprises a light source.
-
The device of embodiment 2, wherein said light source comprises a point source.
-
The device of embodiment 3, wherein the light source further comprises an aperture to form a point source.
-
The device of any of embodiments 2-4, wherein said light source is configured to project light beams of different wavelengths at different times.
-
The device of embodiment 5, wherein said wavelengths include visible wavelengths.
-
The device of embodiment 5, wherein said wavelengths include infrared wavelengths.
-
The device of any of embodiments 1-7, where said confocal microscope is configured such that the angle at which light is projected by a light source onto the eye may be varied based on the portions of the eye space to be imaged.
-
The device of any of embodiments 1-8, wherein said confocal microscope comprises at least one pinhole aperture configured to pass light reflected from the eye.
-
The device of embodiment 9, wherein said confocal microscope comprises at least one imaging optical element with optical power to focus light reflected from said eye.
-
The device of embodiment 10, wherein said pinhole aperture is disposed in an optical path between said imaging optical element and said optical detector.
-
The device of any of embodiments 9-11, wherein said pinhole aperture is disposed at the focus of said light reflected from said eye.
-
The device of any of embodiments 9-11, wherein said pinhole aperture is disposed at the focus of said imaging optical element.
-
The device of any of embodiments 1-13, wherein said confocal microscope comprises an optical detector.
-
The device of any of embodiments 1-14, wherein said confocal microscope comprises a fiber scanning device.
-
The device of embodiment 15, wherein said fiber scanning device is configured to project a light beam.
-
The device of any of embodiments 15-16, wherein said fiber scanning device is configured to receive light reflected from said eye.
-
The device of embodiment 17, wherein said fiber scanning device include an optical detector.
-
The device of any of embodiments 1-18, wherein said optics comprises an adaptable optics element configured to project the light.
-
The device of embodiment 19, wherein the adaptable optics element comprises a variable focus element.
-
The device of any of embodiments any of embodiments 1-20, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes.
-
The device of embodiment 21, wherein the waveguide stack further comprises one or more lenses.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform, said virtual reality display platform configured to project an image into an eye of the wearer, said virtual reality head-mounted ophthalmic system comprising a confocal microscope configured to image the eye.
-
The device of any of embodiments 1 and 3-23, wherein said confocal microscope comprises a scanning laser ophthalmoscope comprising a light source comprising a laser.
-
The device of any of the embodiments above, further comprising a fluid delivery system configured to deliver a fluorescent dye.
-
The device of any of embodiments above, configured to visualize in real time an image projected onto retina of the eye.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Two-Photon Microscopy*
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system, said augmented reality head-mounted ophthalmic system comprising a two-photon absorption microscope configured to image the eye by producing two-photon absorption to generate fluorescence.
-
The device of embodiment 1, wherein said two-photon absorption microscope comprises a light source.
-
The device of embodiment 2, wherein said light source comprises a laser.
-
The device of embodiment 3, wherein said laser comprises a pico-second laser configured to output picosecond pulses.
-
The device of embodiment 3, wherein said laser comprises a femto-second laser configured to output femto-second pulses.
-
The device of embodiment 3, wherein said laser comprises a mode-locked laser.
-
The device of embodiment 3, wherein said laser comprises a fiber laser.
-
The device of embodiment 2, wherein light source is configured to output infrared wavelengths.
-
The device of embodiment 8, wherein light source is configured to output infrared light having a wavelength between 700-1000 nm.
-
The device of any of embodiments 1-9, further comprising an optical element with optical power configured to focus the light onto the eye.
-
The device of any of embodiments 1-10, where said two-photon absorption microscope is configured such that the angle at which light is projected by a light source onto the eye may be varied based on the portions of the eye to be imaged.
-
The device of any of embodiments 1-11, further comprising a scanner configured to scan a beam of light onto said eye.
-
The device of any of embodiments 1-12, wherein said two-photon absorption microscope comprises an optical detector.
-
The device of any of embodiments 1-13, wherein said two-photon absorption microscope comprises a fiber scanning device.
-
The device of embodiment 14, wherein said fiber scanning device is configured to project a light beam.
-
The device of any of embodiments 14-15, wherein said fiber scanning device is configured to receive light reflected from said eye.
-
The device of embodiment 16, wherein said fiber scanning device include an optical detector.
-
The device of any of embodiments 1-17, further comprising an adaptable optics element configured to project the light.
-
The device of embodiment 18, wherein the adaptable optics element comprises a variable focus element.
-
The device of any of embodiments any of embodiments 1-19, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes.
-
The device of embodiment 20, wherein the waveguide stack further comprises one or more lenses.
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system, said augmented reality head-mounted ophthalmic system comprising a multi-photon absorption microscope configured to image the eye by producing multi-photon absorption to generate fluorescence.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform, said virtual reality display platform configured to project an image into an eye of the wearer, said virtual reality head-mounted ophthalmic system comprising a two-photon absorption microscope configured to image the eye.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform, said virtual reality display platform configured to project an image into an eye of the wearer, said virtual reality head-mounted ophthalmic system comprising a multi-photon absorption microscope configured to image the eye.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Autorefractor*
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system, said eye having a retina, wherein said augmented reality head-mounted ophthalmic system is configured to capture images of the retina and determine when the one or more images formed by said fiber scanning display is on the retina to determine an optical prescription for the wearer.
-
The device of embodiment 1, further comprising a fiber scanning display configured to provide the one or more images at varying depth.
-
The device of embodiment 2, further comprising an adaptable optics element configured to provide the one or more images at varying depth.
-
The device of embodiment 3, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 4, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 5, further comprising: one or more electrodes coupled to the membrane mirror; and a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror.
-
The device of any of embodiments 1 to 6, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different focal planes.
-
The device of embodiment 7, wherein the waveguide stack further comprises one or more lenses.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform comprising a display for providing images to the eye of the wearer, said eye having a retina; and a fiber scanning display configured to provide one or more images at varying depth, wherein said virtual reality head-mounted ophthalmic system is configured to capture images of the retina and determine when the one or more images formed by said fiber scanning display is on the retina to determine an optical prescription for the wearer.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* OCT*
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system, said augmented reality display comprising an optical coherence tomography system configured to image the eye.
-
The device of embodiment 1, wherein said optical coherence tomography system is configured to project light beams of varying wavelengths.
-
The device of embodiment 2, wherein said wavelengths include visible wavelengths.
-
The device of embodiment 2, wherein said wavelengths include infrared wavelengths.
-
The device of any of embodiments 1-4, wherein said wearable augmented reality display platform comprises a 3D scanning head comprising a fiber scanning device.
-
The device of embodiment 5, wherein said fiber scanning device is configured to project light beams into the eye.
-
The device of embodiment 5, wherein said fiber scanning device is configured to receive light from the eye.
-
The device of any of embodiments 1-7, further comprising an eye tracking system configured to measure eye movement to de-noise the optical coherence tomography images.
-
The device of any of embodiments 1-7, further comprising ERG.
-
The device of any of embodiments 1-9, where said optical coherence tomography system is configured such that the angle at which light is projected by a light source may be varied based on the regions of the eye space to be imaged.
-
The device of any of embodiments 1-10, further comprising one or more inward facing cameras configured to receive light from the eye.
-
The device of embodiment 11, wherein the one or more inward facing cameras comprise at least one CMOS sensor.
-
The device of any of embodiments 1-10, further comprising a plurality of photodetectors positioned at different parts of the system.
-
The device of embodiment 12, wherein said photodetectors may be positioned around a rim of the head-mounted ophthalmic system.
-
The device of embodiment 12, wherein said photodetectors may be positioned around the periphery of a frame of the head-mounted ophthalmic system.
-
The device of any of embodiments 1-14, wherein said optics comprises an adaptable optics element configured to project light.
-
The device of embodiment 15, wherein the adaptable optics element comprises a variable focus element.
-
The device of any of embodiments any of embodiments 1-16, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes.
-
The device of embodiment 17, wherein the waveguide stack further comprises one or more lenses.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable virtual reality display platform, said virtual reality display platform configured to project an image into an eye of the wearer, said virtual reality display comprising a optical coherence tomography system configured to image the eye, wherein wearable virtual reality display platform comprises a fiber scanning device.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a wearable augmented reality display platform, said virtual reality display platform configured to project an image into an eye of the wearer, said virtual reality display comprising an optical coherence tomography system configured to image the eye, wherein said wearable virtual reality display platform comprises a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light from different depth planes.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Aberrometer*
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system, said eye having a cornea, lens, and retina; at least one light source and wearable optics configured to produce a wavefront and project the wavefront into the eye of the wearer so as to pass through the cornea and lens of the eye and be reflected back by the retina of the eye; and an aberrometer configured to measure the wavefront that passes through the eye to determine abnormalities of the eye.
-
The device of embodiment 1, wherein said at least one light source comprises a fiber scanning display.
-
The device of embodiment 1, wherein said at least one light source is configured to produce a desired wavefront.
-
The device of embodiment 1, wherein said at least one light source is configured to produce wavefronts of different wavelengths.
-
The device of embodiment 4, wherein said at least one light source is configured to produce visible wavefronts that are projected into the eye.
-
The device of embodiment 4, wherein said at least one light source is configured to produce invisible wavefronts that are projected into the eye.
-
The device of embodiment 1, wherein said wearable optics comprise adaptive optics configured to be adjusted to implement the correction.
-
The device of embodiment 7, wherein the adaptive optics comprises a variable focus element.
-
The device of embodiment 7, wherein the adaptive optics comprises a deformable optical element.
-
The device of embodiment 9, wherein the deformable optical element comprises a deformable mirror.
-
The device of embodiment 1, wherein said wearable optics comprise a waveguide stack comprising a plurality of waveguides configured to provide different focal planes.
-
The device of embodiment 11, wherein the waveguide stack is configured to configured to produce a desired wavefront.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform comprising a display for providing images to the eye of the wearer, said eye having a cornea, lens, and retina; at least one light source and wearable optics configured to produce a wavefront and project the wavefront into the eye of the wearer so as to pass through the cornea and lens of the eye and be reflected back by the retina of the eye; and an aberrometer configured to measure the wavefront that passes through the eye to determine abnormalities of the eye.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Ultrasound*
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform comprising a display configured for forming an image viewable by said wearer, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; and an ultrasound producing component comprising an ultrasound transducer included with said augmented reality head-mounted ophthalmic system so as to deliver ultrasound to the user’s eye so as to create an ultrasound image.
-
The device of embodiment 1, wherein said wearable augmented reality system is configured to detect eye abnormalities or monitor health of the user’s eye from the created ultrasound image.
-
The device of embodiment 2, further comprising a processor configured with a pattern match algorithm to detect eye abnormalities.
-
The device of embodiment 1, wherein said ultrasound producing component is configured to deliver ultrasound based on a protocol for said user.
-
The device of embodiment 1, further comprising an adaptable optics element configured to project the image to a particular portion of the wearer’s eye.
-
The device of embodiment 5, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 6, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 7, further comprising:
one or more electrodes coupled to the membrane mirror;* and*
a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror.
-
The device of embodiment 1, further comprising a light source for forming said images in said eye of the wearer, said light source comprising a fiber scanning projector.
-
The device of embodiment 1, wherein said display comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light at different focal planes.
-
The device of embodiment 10, wherein the waveguide stack further comprises one or more lenses.
-
The device of embodiments 1-11, wherein the ultrasound producing component comprises a probe configured to deliver ultrasound energy to the eye and receive ultrasound energy from the eye.
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform comprising a display configured for forming an image viewable by said wearer, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; and an ultrasound producing component comprising an ultrasound transducer coupled to said augmented reality head-mounted ophthalmic system so as to deliver ultrasound to the user’s eye so as to create an ultrasound image so that abnormalities of the eye can be detected, wherein said wearable augmented reality device is configured to measure a response of the user’s eye to said ultrasound to detect eye abnormalities.
-
The device of embodiment 13, wherein said abnormality includes a detached retina.
-
The device of embodiment 13, further comprising an adaptable optics element configured to project the image to a particular portion of the wearer’s eye.
-
The device of embodiment 13, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 16, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 17, further comprising:
one or more electrodes coupled to the membrane mirror;* and*
a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror.
-
The device of embodiment 13, further comprising a light source for forming said images in said eye of the wearer, said light source comprising a fiber scanning projector.
-
The device of embodiment 13, wherein said display comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light at different focal planes.
-
The device of embodiment 20, wherein the waveguide stack further comprises one or more lenses.
-
The device of embodiments 13-21, wherein the ultrasound producing component comprises a probe configured to deliver ultrasound energy to the eye and receive ultrasound energy from the eye.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform comprising a display for providing images to the eye of the wearer; and an ultrasound producing component comprising an ultrasound transducer coupled to said virtual reality head-mounted ophthalmic system so as to deliver ultrasound to the user’s eye so as to create an ultrasound image.
-
The device of Embodiments 21, configured to detect abnormalities of the eye from the created ultrasound image.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform comprising a display for providing images to the eye of the wearer; and an ultrasound producing component comprising an ultrasound transducer coupled to said virtual reality head-mounted ophthalmic system so as to deliver ultrasound to the user’s eye so as to create an ultrasound image so that abnormalities of the eye can be detected, wherein said wearable virtual reality device is configured measure a response of the user’s eye to said ultrasound.
-
The device of Embodiments 22, configured to detect abnormalities of the eye from the measured response.
-
The device of any of the embodiments above, wherein the device is configured to auscultation.
-
The device of any of the embodiments above, wherein the device is configured to transmit or receive ultrasound energy to or from the eye in audible frequency range.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
Electrooculography (EOG), Electroencephalography (EEG), and Electroretinography (ERG)
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform comprising a display, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; a plurality of electrodes configured to be placed around the eye, wherein said wearable augmented reality device is configured to measure and compare resting electrical potentials of the retina.
-
The device of embodiment 1, wherein the electrodes comprise electrooculography (EOG) sensors.
-
The device of embodiment 2, further comprising electroencephalography (EEG) sensors.
-
The device of embodiment 1, further comprising a camera configured to optically image the eye.
-
The device of embodiment 1, further comprising an adaptable optics element configured to project the image to a particular portion of the wearer’s eye.
-
The device of embodiment 6, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 7, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 8, further comprising:
one or more electrodes coupled to the membrane mirror;* and*
a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror based on a corneal shape of the eye.
-
The device of embodiment 1, wherein the light source comprising a fiber scanning projector.
-
The device of embodiment 1, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light at different focal planes.
-
The device of embodiment 11, wherein the waveguide stack further comprises one or more lenses.
-
A wearable augmented reality device configured to be used by a wearer, said device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform comprising a display, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; and a plurality of electroencephalography (EEG) sensors configured to map brain activity, wherein said wearable augmented reality device is configured detect abnormal activity or pattern in the brain of the wearer.
-
The device of embodiment 12, further comprising an adaptable optics element configured to project the image to a particular portion of the wearer’s eye.
-
The device of embodiment 13, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 14, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 15, further comprising:
one or more electrodes coupled to the membrane mirror;* and*
a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror based on a corneal shape of the eye.
-
The device of embodiment 12, wherein the light source comprising a fiber scanning projector.
-
The device of embodiment 12, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light at different focal planes.
-
The device of embodiment 18, wherein the waveguide stack further comprises one or more lenses.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising an virtual reality display platform comprising a display for providing images to the eye of the wearer; and a plurality of electrodes configured to be placed around the eye, wherein said wearable virtual reality device is configured to measure and compare resting electrical potentials of the retina.
-
A wearable virtual reality device configured to be used by a wearer, said device comprising: a virtual reality head-mounted ophthalmic system comprising an virtual reality display platform comprising a display for providing images to the eye of the wearer; and a plurality of electroencephalography (EEG) sensors configured to map brain activity, wherein said wearable virtual reality device is configured detect abnormal activity or pattern in the brain of the wearer.
-
The device of embodiment 1, wherein said electrodes are disposed on said augmented reality head-mounted ophthalmic system around the wear’s eye.
-
The device of embodiment 1 or 20, wherein the electrodes comprise electroretinography (ERG) sensors.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Light Therapy*
-
A wearable augmented reality device configured to be used by a wearer, the device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, the augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; and a light source configured to project light into the eye of the wearer to form an image in the eye, wherein the wearable augmented reality device is configured to detect an amount of one or more wavelengths of light directed towards the eye and to modify the amount of the one or wavelengths of light reaching the eye based on the detected amount.
-
The device of embodiment 1, wherein the head-mounted system is configured to actively reduce the amount of light of one or more wavelengths reaching the eye.
-
The device of embodiment 2, wherein the head-mounted system is configured to actively reduce the amount of light of one or more wavelengths by reducing the amount of light of one or more wavelengths projected by the light source to the eye.
-
The device of embodiment 3, wherein the head-mounted system is configured to: provide instructions for the amount of light of the one or more wavelengths to be outputted by the light source; and subsequently modify the instructions to reduce an output of the light of the one or more wavelengths by the light source.
-
The device of embodiment 2, wherein the head-mounted system is configured to: block at least a portion of the wearer’s view of the world, thereby reducing the amount of the one or more wavelengths of light reaching the eye from the world, wherein a size and location of the portion of the wearer’s view of the world that is blocked is determined based on the detected amount of the one or more wavelengths of the light.
-
The device of embodiment 1, further comprising one or more sensors configured to detect an amount of the one or more wavelengths of light incident on the head-mounted system.
-
The device of embodiment 6, wherein the one or more sensors is a camera attached to the head-mounted system.
-
The device of embodiment 6, wherein the one or more sensors is configured to detect an overexposure of light of a particular color, wherein the head-mounted system is configured to reduce an mount of the light of the particular color reaching the eye.
-
The device of embodiment 1, wherein the wearable augmented reality device is configured to selectively reduce blue light reaching the eye.
-
The device of embodiment 1, wherein the wearable augmented reality device is configured to modify the amount of the one or wavelengths of light reaching the eye based on the detected amount and based on a time of day.
-
The device of embodiment 1, wherein the wearable augmented reality device is configured to modify the amount of the one or wavelengths of light reaching the eye based on the detected amount and based on a calendar date.
-
The device of embodiment 1, wherein the wearable augmented reality device is configured to modify the amount of the one or wavelengths of light reaching the eye based on the detected amount and based on a current season and location of the wearer.
-
The device of embodiment 1, further comprising an adaptable optics element configured to project the image to a particular portion of the wearer’s eye.
-
The device of embodiment 13, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 14, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 15, further comprising:
one or more electrodes coupled to the membrane mirror;* and*
a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror.
-
The device of embodiment 14, wherein the light source comprising a fiber scanning projector.
-
The device of embodiment 1, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light at different focal planes.
-
The device of embodiment 18, wherein the waveguide stack further comprises one or more lenses.
-
A wearable augmented reality device configured to be used by a wearer, the device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, the augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; and a light source configured to project light into the eye of the wearer to form an image in the eye, wherein the wearable augmented reality device is configured to selectively administer light of a portion of a light spectrum into the wearer’s eyes.
-
The device of embodiment 20, further comprising one or more sensors configured to detect the under exposure of light of the portion of the light spectrum, wherein the wearable augmented reality device is configured to selectively augment the light based on the detected under exposure.
-
The device of embodiment 20, further comprising one or more sensors configured to detect an underexposure of blue light.
-
The device of embodiment 22, wherein the wearable augmented reality device is configured to selectively administer blue light.
-
The device of embodiment 20, wherein the light comprises a range of wavelengths corresponding to daylight.
-
The device of embodiment 20, wherein the light comprises a range of wavelengths corresponding to full spectrum light.
-
The device of embodiment 20, further comprising a second light source configured to provide the light to be selectively administered to the wearer’s eyes.
-
A wearable augmented reality device configured to be used by a wearer, the device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, the augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; and a light source configured to project light into the eye of the wearer to form an image in the eye, wherein the wearable augmented reality device is configured to selectively administer light of a predefined range of wavelengths into the wearer’s eyes based on a treatment protocol.
-
The device of embodiment 27, wherein the treatment protocol is to administer a prescribed amount of the light periodically.
-
The device of embodiment 27, wherein the treatment protocol is to administer a prescribed amount of the light continuously.
-
The device of embodiment 27, wherein the wearable augmented reality device is configured to modify the predefined range of wavelengths based on a time of day.
-
The device of embodiment 27, wherein the wearable augmented reality device is configured to modify the predefined range of wavelengths based on a calendar date.
-
The device of embodiment 27, wherein the wearable augmented reality device is configured to modify the predefined range of wavelengths based on a current season and/or location of the wearer.
-
The device of embodiment 27, wherein the wearable augmented reality device is configured to determine a treatment protocol for selectively administering the light of the certain portion of the spectrum into the wearer’s eyes.
-
The device of embodiment 33, wherein the wearable augmented reality device is configured to determine the treatment protocol based on one or more of the following: a physiological state of the wearer, a mood of the wearer, and an ambient environment around the wearer.
-
The device of embodiment 33, wherein the wearable augmented reality device is configured to determine the treatment protocol based on input from the wearer.
-
The device of embodiment 33, wherein the wearable augmented reality device is configured to determine the treatment protocol based on a sign of depression or other abnormality of the wearer.
-
A wearable virtual reality device configured to be used by a wearer, the device comprising: a reality head-mounted ophthalmic system comprising a virtual reality display platform; and a light source configured to project light into the eye of the wearer to form an image in the eye, wherein the wearable virtual reality device is configured to selectively remove light of a particular color.
-
A wearable virtual reality device configured to be used by a wearer, the device comprising: a virtual reality head-mounted ophthalmic system comprising an virtual reality display platform; and a light source configured to project light into the eye of the wearer to form an image in the eye, wherein the wearable virtual reality device is configured to detect an underexposure of light within a certain portion of the spectrum and to selectively administer light of the certain portion of the spectrum into the wearer’s eyes.
-
A wearable virtual reality device configured to be used by a wearer, the device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform; and a light source configured to project light into the eye of the wearer to form an image in the eye, wherein the wearable virtual reality device is configured to selectively administer light of the certain portion of the spectrum into the wearer’s eyes based on a treatment protocol.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Macular Degeneration*
-
A wearable augmented reality device configured to be used by a wearer, said display device comprising:
an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system;
a light source configured to project light into the eye of the wearer to form an image in the eye;* and*
a user interface configured to receive input from a user,
wherein the wearable augmented reality device is configured to project the image to a particular portion of the wearer’s eye and to detect a response regarding the image to determine the health of that portion of the eye.
-
A wearable virtual reality device configured to be used by a wearer, said display device comprising:
a head-mounted display comprising a virtual reality display platform;* and*
a light source configured to project light into the eye of the wearer to form an image in the eye,* and*
a user interface configured to receive input from a user, wherein the wearable virtual reality device is configured to project the image to a particular portion of the wearer’s eye and to detect a response regarding the image to determine the health of that portion of the eye.
-
A wearable display device configured to be used by a wearer, said display device comprising:
a head-mounted ophthalmic system;
a light source configured to direct light into an eye of said wearer to form an image in the eye;
a user interface configured to receive input from a user,* and*
an adaptable optics element configured to receive, from the light source, light that is directed to the eye;
wherein said wearable augmented reality device is configured to detect a response regarding the image to determine the health of that portion of the eye.
-
The device of embodiment 3, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 4, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 5, further comprising:
one or more electrodes coupled to the membrane mirror;* and*
a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror.
-
A wearable display device configured to be used by a wearer, said display device comprising:
a head-mounted display system;* and*
a light source configured to direct light into an eye of a wearer to form an image in the eye, the light source comprising a fiber scanning projector;* and*
a user interface configured to receive input from a user,
wherein the wearable display device is configured to project the image to a particular portion of the wearer’s eye and to detect a response regarding the image to determine the health of that portion of the eye.
-
A wearable display device configured to be used by a wearer, said display device comprising:
a head-mounted display system;* and*
a light source configured to direct light into one eye of said wearer to form an image in the eye;
a waveguide stack comprising a plurality of waveguides;* and*
a user interface configured to receive input from a user,
wherein the wearable display device is configured to project the image to a particular portion of the wearer’s eye and to detect a response regarding the image to determine the health of that portion of the eye.
-
The device of embodiment 8, wherein the waveguide stack further comprises one or more lenses.
-
The device of embodiment 8, wherein the head-mounted display system comprises an augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system.
-
The device of any of embodiments 1-10, wherein the wearable device is configured to project the image to another portion of the wearer’s eye and to detect a response regarding the image to determine the health of that portion of the eye.
-
The device of any of embodiments 1-10, wherein the wearable device is configured to project a first image and a second image to the same portion of the wearer’s eye, to detect a response regarding each image, and to compare the first response to the second response to determine the health of that portion of the eye.
-
The device of embodiment 12, wherein at least one hue present in the first image is different from at least one hue present in the second image.
-
The device of embodiment 13, wherein said wearable augmented reality device is configured to identify areas of reduced color sensitivity based on the portions of the eye tested.
-
The device of embodiment 11, wherein said wearable augmented reality device is configured to determine the location of macular degeneration based on the portions of the eye tested.
-
The device of embodiment 15, wherein determining the location of macular degeneration is further based on imaging of a retina of the eye of the wearer.
-
The device of embodiment 11, wherein said wearable augmented reality device is configured to identify anomalies in the wearer’s eye based on the portions of the eye tested.
-
The device of embodiment 11, wherein said determining the health of a portion of the eye is performed in real time.
-
The device of embodiment 11, wherein said wearable augmented reality device is further configured to store data regarding the projected images and the detected responses, and wherein said determining the health of a portion of the eye is performed at a later time based on the stored data.
-
The device of embodiment 19, wherein said wearable augmented reality device is further configured to transmit the stored data, and wherein said determining the health of a portion of the eye is performed remotely based on the transmitted data.
-
The device of any of embodiments 1-10, wherein detecting a response comprises receiving an input from the user through the user interface.
-
The device of any of embodiments 1-10, wherein detecting a response comprises detecting a movement of the eye of the wearer.
-
The device of embodiment 22, wherein said movement of the eye of the wearer is a voluntary response to the image.
-
The device of embodiment 23, wherein said movement of the eye of the wearer is an involuntary response to the image.
-
The device of any of embodiments 1-10, further comprising a display for forming the image in the eye of the wearer.
-
The device of embodiment 25, wherein the display comprises a fiber scanning display.
-
The device of any of embodiments 25 or 26, wherein the display further comprises a waveguide stack.
-
The device of any of embodiments 25, 26, or 27, wherein the display is configured to produce images at multiple depth planes.
-
A wearable augmented reality device configured to be used by a wearer, said display device comprising: an augmented reality head-mounted ophthalmic system comprising a augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system; and a light source configured to project light into the eye of the wearer to form an image in the eye, wherein the wearable device is configured to selectively project pixels of an image to healthy cells.
-
A wearable display device configured to be used by a wearer, said display device comprising: a head-mounted display system; and a light source configured to direct light into an eye of a wearer to form an image in the eye, the light source comprising a fiber scanning projector, wherein the light source is configured to selectively project pixels of an image to healthy cells.
-
A wearable display device configured to be used by a wearer, said display device comprising: a head-mounted display system; and a light source configured to direct light into one eye of said wearer to form an image in the eye; and a waveguide stack comprising a plurality of waveguides, wherein the wearable display device is configured to selectively project pixels of an image to healthy cells.
-
The device of embodiment 31, wherein the waveguide stack further comprises one or more lenses.
-
The device of embodiment 31, wherein the head-mounted display system comprises an augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system.
-
The device of any of Embodiments 29-33, wherein the wearable device is configured to selectively project pixels of an image to healthy cells at the periphery of the retina.
-
The device of any of Embodiments 29-33, wherein the wearable device is configured to selectively project a portion of the image to healthy cells.
-
The device of any of Embodiments 29-33, wherein the wearable device is configured to alter the light projected to the eye.
-
The device of Embodiment 36, wherein the wearable device is configured to magnify or brighten pixels of the image projected to damaged areas of the eye.
-
A wearable virtual reality device configured to be used by a wearer, said display device comprising: a head-mounted display comprising a virtual reality display platform; and a light source configured to project light into the eye of the wearer to form an image in the eye, wherein the wearable device is configured to selectively project pixels of an image to healthy cells.
-
The device of Embodiment 38, wherein the wearable device is configured to selectively project pixels of an image to healthy cells at the periphery of the periphery of the retina.
-
The device of Embodiment 38, wherein the wearable device is configured to selectively project a portion of the image to healthy cells.
-
A wearable virtual reality device configured to be used by a wearer, said display device comprising: a head-mounted display comprising a virtual reality display platform; and a light source configured to project light into the eye of the wearer to form an image in the eye; wherein the wearable device is configured to alter the light projected to damaged areas of the eye.
-
The device of embodiment 41, wherein the wearable device is configured to magnify pixels of the image projected to damaged areas of the eye.
-
The device of embodiment 41, wherein the wearable device is configured to increase or decrease the intensity of the pixels of the image projected to damaged areas of the eye.
-
The device of embodiment 41, wherein the wearable device is configured to increase or decrease the contrast of the pixels of the image projected to damaged areas of the eye.
-
The device of embodiment 41, wherein the wearable device is configured to alter the hue of the pixels of the image projected to damaged areas of the eye.
-
The device of embodiment 41, wherein the wearable device is configured to alter the light projected for specific wavelengths determined to have reduced sensitivity when projected on said damaged areas of the eye.
-
The device of embodiment 46, wherein the wearable device is configured to magnify pixels of the image projected to damaged areas of the eye.
-
The device of embodiment 46, wherein the wearable device is configured to increase the intensity of the pixels of the image projected to damaged areas of the eye.
-
The device of embodiment 46, wherein the wearable device is configured to increase the contrast of the pixels of the image projected to damaged areas of the eye.
-
A wearable display device configured to be used by a wearer, said display device comprising: a head-mounted ophthalmic system; a light source configured to direct light into an eye of said wearer to form an image in the eye; and an adaptable optics element configured to receive light from the light source, wherein the wearable device is configured to selectively project pixels of an image to healthy cells.
-
The device of embodiment 50, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 50, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 52, further comprising: one or more electrodes coupled to the membrane mirror; and a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror.
-
The device of any of Embodiments 1-28, wherein the wearable device is configured to selectively project pixels of an image to healthy cells.
-
The device of Embodiment 53, wherein the wearable device is configured to selectively project pixels of an image to healthy cells at the periphery of the retina.
-
The device of Embodiment 53, wherein the light source is configured to selectively project a portion of the image to healthy cells.
-
The device of any of Embodiment 1-23, wherein the wearable device is configured to alter the light projected to the eye.
-
The device of Embodiment 56, wherein the wearable device is configured to magnify pixels of the image projected to damaged areas of the eye.
-
The device of embodiment 56, wherein the wearable device is configured to increase the contrast of the pixels of the image projected to damaged areas of the eye.
-
The device of embodiment 56, wherein the wearable device is configured to alter the light projected for specific wavelengths determined to have reduced sensitivity when projected on said damaged areas of the eye.
-
The device of embodiment 59, wherein the wearable device is configured to magnify pixels of the image projected to damaged areas of the eye.
-
The device of embodiment 59, wherein the wearable device is configured to increase the intensity of the pixels of the image projected to damaged areas of the eye.
-
The device of embodiment 59, wherein the wearable device is configured to increase the contrast of the pixels of the image projected to damaged areas of the eye.
-
The device of embodiment 28, wherein the multiple depth planes are separated by at least 10 centimeters.
-
The device of any of embodiments 28 or 63, wherein the multiple depth planes comprises at least 3 depth planes.
-
The device of embodiment 37, wherein the wearable device is configured to increase or decrease the spatial frequency of a periodic image projected to damaged areas of the eye.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Contrast Testing*
-
A wearable augmented reality device configured to be used by a wearer, said display device comprising:
an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system;
a light source configured to project light into the eye of the wearer to form an image in the eye;* and*
a user interface configured to receive input from a user,
wherein the wearable augmented reality device is configured to project the image to the wearer and to detect a response regarding the image to determine a contrast sensitivity of the wearer.
-
A wearable virtual reality device configured to be used by a wearer, said display device comprising:
a head-mounted display comprising a virtual reality display platform;* and*
a light source configured to project light into the eye of the wearer to form an image in the eye,* and*
a user interface configured to receive input from a user, wherein the wearable virtual reality device is configured to project the image to the wearer and to detect a response regarding the image to determine a contrast sensitivity of the wearer.
-
The device of embodiment 1 or 2, wherein said image comprises a plurality of regions having different contrast levels.
-
The device of embodiment 3, wherein said image comprises a sine-wave grating.
-
The device of embodiment 3, wherein said image comprises a plurality of letters or numbers projected at different contrast levels.
-
The device of embodiment 5, wherein said image comprises a Pelli-Robson chart.
-
The device of embodiment 5, wherein the wearable device is configured to detect a response from the wearer indicating the letters, numbers, or shapes that are visible to the wearer.
-
The device of embodiment 1 or 2, wherein the light source is configured to consecutively project a plurality of images to the wearer.
-
The device of embodiment 8, wherein each of the plurality of images differs from at least one other of the plurality of images in contrast.
-
The device of embodiment 9, wherein the wearable device is configured to detect a response from the wearer indicating the wearer’s ability to detect a contrast feature within the image.
-
The device of embodiment 1 or 2, wherein the light source is configured to decrease the contrast of said image over time.
-
The device of embodiment 11, wherein the wearable device is configured to detect a response from the wearer indicating a time at which the wearer cannot discern contrasting features of the image.
-
The device of any of embodiments 1-12, further comprising a display for forming the image in the eye of the wearer.
-
The device of embodiment 13, wherein the display comprises a fiber scanning display.
-
The device of embodiment 13 or 14, wherein the display further comprises a waveguide stack.
-
The device of any of embodiments 10-12, wherein the display is configured to produce images at multiple depth planes.
-
The device of any of embodiments 1-16, wherein the wearable device is configured to perform a plurality of contrast sensitivity measurements and perform a comparative analysis of the results.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Visual Fields*
-
A wearable augmented reality device configured to be used by a wearer, said display device comprising:
an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, said augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted system;
a light source configured to project light into the eye of the wearer to form a moving image in the eye;* and*
a user interface configured to receive input from a user,
wherein the wearable augmented reality device is configured to project the image at a particular portion of the periphery of the wearer’s visual field and to detect a response regarding the image to determine the health of that portion of the visual field.
-
A wearable virtual reality device configured to be used by a wearer, said display device comprising:
a head-mounted display comprising a virtual reality display platform;* and*
a light source configured to project light into the eye of the wearer to form a moving image in the eye,* and*
a user interface configured to receive input from a user, wherein the wearable virtual reality device is configured to project the image at a particular portion of the periphery of the wearer’s visual and to detect a response regarding the image to determine the health of that portion of the visual field.
-
The device of embodiment 1 or 2, wherein said moving image moves inward from the periphery of the wearer’s visual field toward the center of the wearer’s visual field.
-
The device of embodiment 3, wherein the wearable device is configured to detect a response from the wearer indicating the time at which the image becomes visible to the wearer.
-
The device of embodiment 3, wherein the wearable device is configured to detect a response from the wearer regarding an observed characteristic of the image.
-
The device of embodiment 3, wherein the light source is further configured to project an image of an object approaching the eye of the wearer.
-
The device of any of embodiments 1-6, further comprising a display for forming the image in the eye of the wearer.
-
The device of embodiment 7, wherein the display comprises a fiber scanning display.
-
The device of embodiment 7 or 8, wherein the display further comprises a waveguide stack.
-
The device of any of embodiments 7-9, wherein the display is configured to produce images at multiple depth planes.
-
The device of any of embodiments 1-10, wherein the device is configured to provide a visual, audio, or tactile notification to the wearer based on detecting a hazard in an unhealthy portion of the wearer’s visual field.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
* Laser Therapy*
-
A wearable augmented reality device configured to be used by a wearer, the device comprising: an augmented reality head-mounted ophthalmic system comprising an augmented reality display platform, the augmented reality head-mounted ophthalmic system configured to pass light from the world into an eye of a wearer wearing the head-mounted ophthalmic system; and a laser configured to administer laser therapy to the eye of the wearer.
-
The device of embodiment 1, wherein the device is configured to direct laser light to the eye at an intensity, wavelength, and duration to alter eye tissue.
-
The device of embodiment 1, wherein the laser is configured to reduce a growth of abnormal blood vessels or to close abnormal blood vessels.
-
The device of embodiment 3, wherein the laser is configured to perform full laser photocoagulation.
-
The device of embodiment 3, wherein the laser is configured to treat wet age-related macular degeneration.
-
The device of embodiment 1, further comprising a module configured to inject a photosensitizer into the eye, the laser configured to activate the photosensitizer.
-
The device of embodiment 1, wherein the wearable augmented reality device is configured to determine an area for exposure to light from the laser.
-
The device of embodiment 7, wherein the wearable augmented reality device is configured to determine the area for exposure by imaging a retina and surrounding tissue of the eye and determining a presence of choroidal neurovascularization.
-
The device of embodiment 1, wherein the augmented reality head-mounted ophthalmic system is configured to provide instructions to the wearer before exposing the wearer to light from the laser.
-
The device of embodiment 9, wherein the augmented reality head-mounted ophthalmic system is configured to display images to the wearer as part of the laser therapy.
-
The device of embodiment 10, wherein the augmented reality head-mounted ophthalmic system is configured to display the instructions to the wearer before exposing the wearer to light from the laser.
-
The device of embodiment 9, wherein the augmented reality head-mounted ophthalmic system is configured to orient the eye of the wearer in a desired direction during exposing the wearer to light from the laser, wherein the augmented reality head-mounted ophthalmic system is configured to orient the eye by displaying an object for the eye of the wearer to focus on.
-
The device of embodiment 9, wherein the augmented reality head-mounted ophthalmic system is configured to display a moving object as part of the laser therapy.
-
The device of embodiment 9, wherein the augmented reality head-mounted ophthalmic system is configured to provide instructions to the wearer after exposing the wearer to light from the laser.
-
The device of embodiment 14, wherein the instructions comprise one or more of shutting the eyelids for a set duration and blinking a set number of times.
-
The device of embodiment 1, wherein the laser is mounted to a frame of the ophthalmic system.
-
The device of embodiment 1, further comprising an adaptable optics element configured to project an image to a particular portion of the wearer’s eye.
-
The device of embodiment 17, wherein the adaptable optics element comprises a variable focus element.
-
The device of embodiment 18, wherein the variable focus element comprises a membrane mirror.
-
The device of embodiment 19, further comprising:
one or more electrodes coupled to the membrane mirror;* and*
a control system configured to selectively control the one or more electrodes to modify a shape of the membrane mirror.
-
The device of embodiment 1, further comprising a fiber scanning projector for outputting light to form images in the eye of the wearer.
-
The device of embodiment 1, further comprising a waveguide stack comprising a plurality of waveguides, wherein different waveguides are configured to project light at different focal planes.
-
The device of embodiment 22, wherein the waveguide stack further comprises one or more lenses.
-
A wearable virtual reality device configured to be used by a wearer, the device comprising: a virtual reality head-mounted ophthalmic system comprising a virtual reality display platform comprising a display for providing images to the eye of the wearer;* and*
a laser configured to selectively administer laser therapy to the eye of the wearer.
-
The device of embodiment 24, wherein the virtual reality head-mounted ophthalmic system is configured to not pass light from the world in front of the head-mounted ophthalmic system into the eye of the wearer wearing the head-mounted ophthalmic system that would form an image of the world in the eye of the wearer.
The additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” are to be repeated, added to, and concatenated to the list of numbered embodiments here as if the list of additional numbered embodiments below in the section titled “ADDITIONAL NUMBERED EMBODIMENTS” immediately followed the list of numbered embodiments here.
