Meta Patent | Systems and methods of buffer status reporting for transmission streams

Patent: Systems and methods of buffer status reporting for transmission streams

Patent PDF: 加入映维网会员获取

Publication Number: 20230022424

Publication Date: 2023-01-26

Assignee: Meta Platforms Technologies

Abstract

A first device may include one or more processors. The one or more processors may be configured to wirelessly receive, via a transceiver from a second device, a first frame. The one or more processors may be configured to identify one or more traffic identifiers from a first field of the first frame. The one or more processors may be configured to generate a second frame including buffer status data of one or more wireless traffic streams corresponding to the one or more traffic identifiers. The one or more processors may be configured to wirelessly transmit, via the transceiver, the generated second frame to the second device.

Claims

What is claimed is:

1.A first device comprising: one or more processors configured to: wirelessly receive, via a transceiver from a second device, a first frame; identify one or more traffic identifiers from a first field of the first frame; generate a second frame including buffer status data of one or more wireless traffic streams corresponding to the one or more traffic identifiers; and wirelessly transmit, via the transceiver, the generated second frame to the second device.

2.The first device according to claim 1, wherein the second device is an access point, a soft access point or a peer device.

3.The first device according to claim 1, wherein in generating the second frame, the one or more processors are configured to: set one or more bits of a traffic identifier bitmap field of the second frame to indicate the one or more traffic identifiers.

4.The first device according to claim 3, wherein the traffic identifier bitmap field of the second frame comprises a plurality of bits each corresponding to a traffic identifier associated with one of a plurality of traffic categories.

5.The first device according to claim 1, wherein in generating the second frame, the one or more processors are configured to: set a first queue size field of the second frame to a highest queue size among one or more queue sizes of at least one wireless traffic streams associated with the one or more traffic identifiers.

6.The first device according to claim 5, wherein in generating the second frame, the one or more processors are configured to: set a first traffic identifier field of the second frame to a traffic identifier corresponding to the highest queue size.

7.The first device according to claim 1, wherein in generating the second frame, the one or more processors are configured to: set a second queue size field of the second frame to a total queue size of traffic associated with the one or more traffic identifiers.

8.The first device according to claim 1, wherein in identifying the one or more traffic identifiers from the first field of the first frame, the one or more processors are configured to: determine whether a frame type field of the first frame is a first type indicating a buffer status trigger frame; identify the first field as a traffic identifier bitmap field; and identify the one or more traffic identifiers from one or more bits of the traffic identifier bitmap field set to a defined value.

9.The first device according to claim 8, wherein the frame type field of the first frame is a subfield of a common information field that is shared among a plurality of users or devices.

10.The first device according to claim 8, wherein the frame type field of the first frame indicates a type associated with a trigger frame.

11.A method comprising: wirelessly receiving, by a first device from a second device, a first frame; identifying, by the first device, one or more traffic identifiers from a first field of the first frame; generating, by the first device, a second frame including buffer status data of one or more wireless traffic streams corresponding to the one or more traffic identifiers; and wirelessly transmitting, by the first device, the generated second frame to the second device.

12.The method according to claim 11, wherein the second device is an access point, a soft access point or a peer device.

13.The method according to claim 11, wherein generating the second frame comprises: setting one or more bits of a traffic identifier bitmap field of the second frame to indicate the one or more traffic identifiers.

14.The method according to claim 13, wherein the traffic identifier bitmap field of the second frame comprises a plurality of bits each corresponding to a traffic identifier associated with one of a plurality of traffic categories.

15.The method according to claim 11, wherein generating the second frame comprises: setting a first queue size field of the second frame to a highest queue size among one or more queue sizes of at least one wireless traffic streams associated with the one or more traffic identifiers.

16.The method according to claim 15, wherein generating the second frame comprises: setting a first traffic identifier field of the second frame to a traffic identifier corresponding to the highest queue size.

17.The method according to claim 11, wherein generating the second frame comprises: setting a second queue size field of the second frame to a total queue size of traffic associated with the one or more traffic identifiers.

18.The method according to claim 11, wherein identifying the one or more traffic identifiers from the first field of the first frame comprises: determining whether a frame type field of the first frame is a first type indicating a buffer status trigger frame; identifying the first field as a traffic identifier bitmap field; and identifying the one or more traffic identifiers from one or more bits of the traffic identifier bitmap field set to a defined value.

19.The method according to claim 18, wherein the frame type field of the first frame is a subfield of a common information field that is shared among a plurality of users or devices.

20.The method according to claim 18, wherein the frame type field of the first frame indicates a type associated with a trigger frame.

Description

CROSS-REFERENCE TO RELATED APPLICATION

This application claims priority to U.S. Provisional Patent Application No. 63/222,602 filed on Jul. 16, 2021, which is incorporated by reference herein in its entirety for all purposes.

FIELD OF DISCLOSURE

The present disclosure is generally related to communications, including but not limited systems and methods of triggering buffer status reporting and/or sending buffer status reporting for transmission streams.

BACKGROUND

Artificial reality such as a virtual reality (VR), an augmented reality (AR), or a mixed reality (MR) provides immersive experience to a user. In one example, a user wearing a head wearable display (HWD) can turn the user's head, and an image of a virtual object corresponding to a location of the HWD and a gaze direction of the user can be displayed on the HWD to allow the user to feel as if the user is moving within a space of artificial reality (e.g., a VR space, an AR space, or a MR space). An image of a virtual object may be generated by a console communicatively coupled to the HWD. In some embodiments, the console may have access to a network.

SUMMARY

Various embodiments disclosed herein are related to a device including one or more processors. In some embodiments, the one or more processors may be configured to determine a first traffic identifier of a first wireless traffic stream, from a plurality of traffic identifiers. The one or more processors may be configured to generate a first frame including the first traffic identifier. The first frame may be configured to trigger a receiver device to send a response frame that includes buffer status data corresponding to the first wireless traffic stream. The one or more processors may be configured to wirelessly transmit, via a transmitter, the generated first frame to the receiver device.

In some embodiments, the device may be an access point, a soft access point or a peer device.

In some embodiments, in generating the first frame, the one or more processors may be configured to set a frame type field of the first frame to a first type indicating a buffer status trigger frame including one or more traffic identifiers, and set a first bit of a traffic identifier bitmap field of the first frame to indicate the first traffic identifier. The traffic identifier bitmap field of the first frame may include a plurality of bits each corresponding to a traffic identifier associated with one of a plurality of traffic categories. The frame type field of the first frame may be a subfield of a common information field that is shared among a plurality of users or receiver devices.

In some embodiments, the response frame may include a traffic identifier bitmap field indicating one or more traffic identifiers. The traffic identifier bitmap field of the response frame may include a plurality of bits each corresponding to a traffic identifier associated with one of a plurality of traffic categories. The response frame may include a first queue size field indicating a highest queue size among one or more queue sizes of at least one wireless traffic stream associated with the one or more traffic identifiers. The response frame may include a first traffic identifier field indicating a traffic identifier corresponding to the highest queue size. The response frame may include a second queue size field indicating a total queue size of traffic associated with the one or more traffic identifiers.

Various embodiments disclosed herein are related to a method including determining, by a device, a first traffic identifier of a first wireless traffic stream, from a plurality of traffic identifiers. In some embodiments, the method may include generating a first frame including the first traffic identifier. The first frame may be to trigger a receiver device to send a response frame that includes buffer status data corresponding to the first wireless traffic stream. The method may include wirelessly transmitting, by the device, the generated first frame to the receiver device.

In some embodiments, the device may be an access point, a soft access point or a peer device.

In some embodiments, in generating the first frame, the device may set a frame type field of the first frame to a first type indicating a buffer status trigger frame including one or more traffic identifiers, and set a first bit of a traffic identifier bitmap field of the first frame to indicate the first traffic identifier. The traffic identifier bitmap field of the first frame may include a plurality of bits each corresponding to a traffic identifier associated with one of a plurality of traffic categories. The frame type field of the first frame may be a subfield of a common information field that is shared among a plurality of users or receiver devices.

In some embodiments, the response frame may include a traffic identifier bitmap field indicating one or more traffic identifiers. The traffic identifier bitmap field of the response frame may include a plurality of bits each corresponding to a traffic identifier associated with one of a plurality of traffic categories. The response frame may include a first queue size field indicating a highest queue size among one or more queue sizes of at least one wireless traffic stream associated with the one or more traffic identifiers. The response frame may include a first traffic identifier field indicating a traffic identifier corresponding to the highest queue size. The response frame includes a second queue size field indicating a total queue size of traffic associated with the one or more traffic identifiers.

Various embodiments disclosed herein are related to a first device including one or more processors. In some embodiments, the one or more processors may be configured to wirelessly receive, via a transceiver from a second device, a first frame. The one or more processors may be configured to identify one or more traffic identifiers from a first field of the first frame. The one or more processors may be configured to generate a second frame including buffer status data of one or more wireless traffic streams corresponding to the one or more traffic identifiers. The one or more processors may be configured to wirelessly transmit, via the transceiver, the generated second frame to the second device.

In some embodiments, the second device may be an access point, a soft access point or a peer device.

In some embodiments, in generating the second frame, the one or more processors may be configured to set one or more bits of a traffic identifier bitmap field of the second frame to indicate the one or more traffic identifiers. The traffic identifier bitmap field of the second frame may include a plurality of bits each corresponding to a traffic identifier associated with one of a plurality of traffic categories.

In some embodiments, in generating the second frame, the one or more processors may be configured to set a first queue size field of the second frame to a highest queue size among one or more queue sizes of at least one wireless traffic streams associated with the one or more traffic identifiers. In generating the second frame, the one or more processors may be configured to set a first traffic identifier field of the second frame to a traffic identifier corresponding to the highest queue size. In some embodiments, in generating the second frame, the one or more processors may be configured to set a second queue size field of the second frame to a total queue size of traffic associated with the one or more traffic identifiers.

In some embodiments, in identifying the one or more traffic identifiers from the first field of the first frame, the one or more processors may be configured to determine whether a frame type field of the first frame is a first type indicating a buffer status trigger frame, identify the first field as a traffic identifier bitmap field, and identify the one or more traffic identifiers from one or more bits of the traffic identifier bitmap field set to a defined value. The frame type field of the first frame may be a subfield of a common information field that is shared among a plurality of users or devices. The frame type field of the first frame may indicate a type associated with a trigger frame.

Various embodiments disclosed herein are related to a method including wirelessly receiving, by a first device from a second device, a first frame. In some embodiments, the method may include identifying, by the first device, one or more traffic identifiers from a first field of the first frame. The method may include generating, by the first device, a second frame including buffer status data of one or more wireless traffic streams corresponding to the one or more traffic identifiers. The method may include wirelessly transmitting, by the first device, the generated second frame to the second device.

In some embodiments, the second device may be an access point, a soft access point or a peer device.

In some embodiments, in generating the second frame, the first device may set one or more bits of a traffic identifier bitmap field of the second frame to indicate the one or more traffic identifiers. The traffic identifier bitmap field of the second frame may include a plurality of bits each corresponding to a traffic identifier associated with one of a plurality of traffic categories.

In some embodiments, in generating the second frame, the first device may set a first queue size field of the second frame to a highest queue size among one or more queue sizes of at least one wireless traffic streams associated with the one or more traffic identifiers. In generating the second frame, the first device may set a first traffic identifier field of the second frame to a traffic identifier corresponding to the highest queue size. In some embodiments, in generating the second frame, the first device may setting a second queue size field of the second frame to a total queue size of traffic associated with the one or more traffic identifiers.

In some embodiments, in identifying the one or more traffic identifiers from the first field of the first frame, the first device may determine whether a frame type field of the first frame is a first type indicating a buffer status trigger frame, identify the first field as a traffic identifier bitmap field, and identify the one or more traffic identifiers from one or more bits of the traffic identifier bitmap field set to a defined value. The frame type field of the first frame may be a subfield of a common information field that is shared among a plurality of users or devices. The frame type field of the first frame may indicate a type associated with a trigger frame.

BRIEF DESCRIPTION OF THE DRAWINGS

The accompanying drawings are not intended to be drawn to scale. Like reference numbers and designations in the various drawings indicate like elements. For purposes of clarity, not every component can be labeled in every drawing.

FIG. 1 is a diagram of a system environment including an artificial reality system, according to an example implementation of the present disclosure.

FIG. 2 is a diagram of a head wearable display, according to an example implementation of the present disclosure.

FIG. 3 is a block diagram of a computing environment according to an example implementation of the present disclosure.

FIG. 4A illustrates an example trigger frame format and an example common information field format, according to an example implementation of the present disclosure.

FIG. 4B illustrates an example trigger frame format and example user information field formats, according to example implementations of the present disclosure.

FIG. 5 is a table of trigger frame types/variants (e.g., encoding trigger frame formats), according to an example implementation of the present disclosure.

FIG. 6 is an example of a Control Information subfield in a BSR Control Field, according to an example implementation of the present disclosure.

FIG. 7 is a flowchart showing a process of triggering buffer status reporting for transmission streams, according to an example implementation of the present disclosure.

FIG. 8 is a flowchart showing a process of sending buffer status reporting for transmission streams, according to an example implementation of the present disclosure.

DETAILED DESCRIPTION

Before turning to the figures, which illustrate certain embodiments in detail, it should be understood that the present disclosure is not limited to the details or methodology set forth in the description or illustrated in the figures. It should also be understood that the terminology used herein is for the purpose of description only and should not be regarded as limiting.

Disclosed herein are systems and methods related to triggering (e.g., requesting, activating and/or initiating) buffer status reporting for transmission streams. In some embodiments, a device (e.g., an access point (AP), a soft-AP, a peer device) may include one or more processors. The one or more processors may determine a first traffic identifier of a first wireless traffic stream, from a plurality of traffic identifiers. The one or more processors may generate a first frame (e.g., trigger frame) including the first traffic identifier (e.g., a traffic stream identifier (TID)). The first frame may be configured to trigger a receiver device (e.g., an AP, a soft-AP, a peer device) to send a response frame that includes buffer status data corresponding to the first wireless traffic stream. The one or more processors may wirelessly transmit, via a transmitter, the generated first frame to the receiver device.

Streams of traffic may be characterized by different types of traffic (e.g., traffic types of video (VI), voice (VO), best effort (BE), background (BK)). For instance, an application may be characterized by latency sensitive traffic or regular traffic. Latency sensitive traffic may be identifiable, in part, based on its periodicity or periodic nature (e.g., periodic bursts of traffic) and low latency requirement, in some embodiments. For instance, video display traffic may be driven by a refresh rate of 60 Hz, 72 Hz, 90 Hz, or 120 Hz. An application and/or device may have combinations of traffic types (e.g., latency sensitive traffic and non-latency sensitive traffic). Further, each stream of traffic for the application and/or device may be more or less spontaneous and/or periodic as compared to other streams of traffic for the application and/or device. Accordingly, traffic may vary according to applications and/or channel rate dynamics.

In some implementations, devices may provide different quality of services (QoS) using different links, frames, time slots, and the like. For example, a device (such as an AP) may prioritize some slots, frames, or packets over other slots, frames, or packets. In some applications, latency sensitive traffic that is not prioritized (e.g., to be processed or handled in a defined manner) may degrade a user experience. For example, in an AR context, latency between a movement of a user wearing an AR device and an image corresponding to the user movement and displayed to the user using the AR device may cause judder, resulting in motion sickness.

In some implementations, a basic trigger frame may include a Preferred Access Categories (AC) subfield in a trigger dependent user info subfield of a per user info field. The Preferred AC subfield may indicate a lowest AC that may be recommended for aggregation of Medium Access Control (MAC) Protocol Data Unit (MPDU) in an Aggregated-MPDU (A-MPDU) contained in a high efficiency (HE) or extremely high throughput (EHT) trigger based (TB) physical layer protocol data unit (PPDU) sent as a response to the trigger frame. The Preferred AC subfield may be encoded according to access category index (ACI)-to-AC encoding. Using this trigger frame format, uplink (UL) QoS-data frames may be triggered by a basic trigger frame.

In some implementations, trigger frames may be modified (or repurposed/reconfigured/added), to include prioritized TID information. For example, an AP may solicit a STA(s) traffic information (e.g., buffer status) by transmitting a Buffer Status Report Poll (BSRP) (or other trigger frames). In some implementations, the BSRP Trigger frame may trigger one STA or multiple client devices (STAs) to communicate the buffer status to the AP. For example, when an AP sends a BSRP trigger to multiple STAs, after a predetermined time (e.g., short interface space (SIFS)) elapses, each STA may transmit a HE TB UL A-MPDU carrying QoS-Data or QoS-Null frames. Buffer status information (e.g., total bytes of data or queue size) can be contained in either QoS-control or BSR HE control field or any other such field in the QoS-Data or QoS-Null frames. Optionally, a STA may or may not request an acknowledgement (ACK). If requested, after a SIFS elapses, the AP may send one or more ACKs or a Multi-STA block acknowledgement (M-BA).

In some implementations, however, the BSRP Trigger frame may not indicate TID information (e.g., there may not be a Trigger Dependent Common Information subfield and/or a Trigger Dependent User Information subfield). Accordingly, the AP may not be able to specify/request the buffer status of particular (e.g., prioritized) TIDs and the STA may not (be able to) transmit/indicate the buffer status of certain particular TIDs. For example, in sending Buffer Status Report using BSRP Trigger frame, the responding frame may carry the buffer status for a TID that is not chosen by the AP but chosen by the responding station (STA).

Moreover, an AP may enhance medium access protection and resource reservation by supporting restricted target wake time (R-TWT or rTWT) with respect to particular traffic streams. The rTWT SPs may deliver latency sensitive traffic and/or any additional frame that supports latency sensitive traffic. Some implementations, however, do not provide a mechanism for an AP to specify which TID(s) the AP wants to learn about its buffer status. For example, the rTWT agreement may be established between two extremely high throughput (EHT) STAs with one or more TIDs to be associated with traffic of each direction. When an AP triggers non-AP STA during rTWT service periods (SPs), the AP may need to learn/know the buffer status for specific TID(s) that are associated with this rTWT agreement. There is a benefit for a BSRP Trigger frame to allow an AP to request/learn specified TID(s)'s buffer status.

To solve these problems, according to certain aspects, embodiments in the present disclosure relate to techniques for providing a mechanism for a device (e.g., AP) to trigger buffer status reporting based on one or more TIDs directly. In some embodiments, a trigger frame may allow the AP to trigger buffer status reporting based on one or more TIDs. In some embodiments, in response to a buffer status reporting trigger frame based on (or specifying/including) one or more particular TIDs, a device (e.g., STA) may send buffer status corresponding to the one or more particular TIDs.

In one approach, a new trigger frame type (e.g., BSRP-TID Trigger frame) may be added or defined for an AP to trigger buffer status reporting based on one or more TIDs using a BSRP-TID Trigger frame. In some embodiments, the BSRP-TID Trigger frame may include a Trigger Type subfield which may be set to 8 or any value not used by other trigger frame types. The format of the BSRP-TID Trigger frame may be the same as a BSRP Trigger frame except, for example, a type dependent per user info subfield may be present and may have a TID bitmap subfield, which specifies TID(s) whose buffer status is requested by the transmitting AP. The TID bitmap subfield may be a one octet field. In some embodiments, if bit k of the TID bitmap subfield is set, then the responding STA may include a buffer status of the k-th TID in a responding HE/EHT TB PPDU frame.

In some embodiments, a BSRP-TID Trigger frame may be defined to include a TID bitmap subfield which has a size of 8 bits. In some embodiments, each bit of the TID bitmap subfield may indicate (if set to 1 for instance) a corresponding one of 8 TIDs belonging to AC_BK (background), AC_BE (best effort), AC_VI (video), and AC_VO (voice). An example of encoding of the TID bitmap subfield is shown in Table 1.

TABLE 1 Example Encoding of TID bit map subfield Bit Index of TID bitmap subfield Corresponding TID 0 0 (AC_BK) 1 1 (AC_BK) 2 2 (AC_BE) 3 3 (AC_BE) 4 4 (AC_VI) 5 5 (AC_VI) 6 6 (AC_VO) 7 7 (AC_VO)

In some embodiments, the bitmap subfield may have a size of six or more bits such that each bit in the TID bitmap subfield may correspond to an ordered set of TIDs from 2-7 (excluding TIDs 0,1 from AC_BK (background)).

In one approach, a device may include one or more processors. The one or more processors may be configured to determine a first traffic identifier of a first wireless traffic stream, from a plurality of traffic identifiers. The one or more processors may be configured to generate a first frame including the first traffic identifier. The first frame may be configured to trigger a receiver device to send a response frame that includes buffer status data corresponding to the first wireless traffic stream. The one or more processors may be configured to wirelessly transmit, via a transmitter, the generated first frame to the receiver device. In some embodiments, the device may be an access point, a soft access point or a peer device.

In one approach, in generating the first frame, the one or more processors may be configured to set a frame type field of the first frame (e.g., a type value not used for other trigger frame type values) to a first type indicating a buffer status trigger frame including one or more traffic identifiers, and set a first bit of a traffic identifier bitmap field of the first frame (e.g., bit k of TID bitmap subfield) to indicate the first traffic identifier. The traffic identifier bitmap field of the first frame may include a plurality of bits each corresponding to a traffic identifier associated with one of a plurality of traffic categories. The frame type field of the first frame may be a subfield of a common information field that is shared among a plurality of users or receiver devices.

In one approach, the response frame may include a traffic identifier bitmap field (e.g., TID bitmap subfield) indicating one or more traffic identifiers. The traffic identifier bitmap field of the response frame may include a plurality of bits each corresponding to a traffic identifier associated with one of a plurality of traffic categories. The response frame may include a first queue size field (e.g., Queue Size High subfield) indicating a highest queue size among one or more queue sizes of at least one wireless traffic stream associated with the one or more traffic identifiers. The response frame may include a first traffic identifier field (e.g., TID High subfield) indicating a traffic identifier corresponding to the highest queue size. The response frame may include a second queue size field (e.g., Queue Size All) indicating a total queue size of traffic associated with the one or more traffic identifiers.

Also disclosed herein are systems and methods related to sending (e.g., generating, and/or transmitting) buffer status reporting for transmission streams. A first device may include one or more processors. The one or more processors may wirelessly receive, via a transceiver from a second device, a first frame. The one or more processors may identify one or more traffic identifiers from a first field of the first frame (e.g., TID bitmap subfield). The one or more processors may generate a second frame including buffer status data of one or more wireless traffic streams corresponding to the one or more traffic identifiers. The one or more processors may wirelessly transmit, via the transceiver, the generated second frame to the second device.

In some implementations, an AP may solicit a buffer status report by sending a BSRP Trigger frame (could be solicited by newly defined Trigger frames, e.g., BSRP-TID Trigger frames). In response to a BSRP-TID Trigger frame, the STA may indicate/report the buffer status (in bytes, for example) using one or more QoS Control Fields or BSR Control Fields in a buffer status reporting frame (e.g., QoS-Data or QoS Null frames). A BSR Control field may include Control Information subfield which includes an access category index (ACI) Bitmap indicating one or more ACs, a Delta TID, ACI High, Queue Size High, and/or Queue Size All. The Delta TID may indicate the number of TIDs associated with an AC (e.g., one TID or two TIDs), but not a particular TID associated with the AC. The ACI High may be used to indicate a prioritized AC (but not particular TIDs associated with the ACI). The Queue Size High and Queue Size All may be used to indicate the queue size of the prioritized AC and the queue size of all ACs specified in the ACI Bitmap (but not the queue size of particular TIDs associated with the ACI). In some configurations, eight TIDs may map to four ACs. Accordingly, with the above-described configuration of the BSR Control Field, the responding STA may not be specifically indicate the buffer status of particular TIDs which may carry latency sensitive traffic. Using the ACI Bitmap, the responding STA may not communicate to the AP the status of the particular TIDS. Using the ACI Bitmap, the responding STA may communicate to the AP, at best, a buffer status of all TID in an ACI, or other TIDs in an AC determined by the STA. Therefore, it may be beneficial to provide a mechanism to specify one or more particular TIDs in the BSR Control field in a buffer status reporting frame.

To solve this problem, according to certain aspects, embodiments in the present disclosure relate to techniques for providing a mechanism for a device (e.g., STA) to send, in response to a buffer status reporting trigger frame based on one or more particular TIDs, a buffer status corresponding to the one or more particular TIDs.

In one approach, a new BSR control field (e.g., BSR-TID Control field) may be defined in a buffer status reporting frame (e.g., QoS-Data or QoS Null frames) to specify a buffer status corresponding to one or more particular TIDs. In some embodiments, the BSR-TID Control field may be added to a subfield of a HE variant HT Control field (e.g., Aggregate control (A-Control) subfield). For example, the A-Control subfield may include Control ID subfield which is set to a new Control ID (e.g., type 9 or other available type values that are not used for other types of control).

In some embodiments, the BSR-TID Control field may include a TID bitmap subfield, a TID High subfield, a Scaling Factor subfield, a Queue Size High subfield, and/or a Queue Size All subfield. The TID bitmap may have the size of 8 bits. The TID High subfield may have the size of 3 bits. Compared to the BSR Control field, (1) 4 bit ACI Bitmap subfield may be replaced with an 8 bit TID bitmap subfield, (2) the Delta TID subfield may not be needed anymore and hence removed, (3) a 2 bit ACI High subfield may be replaced with a 3 bit TID High subfield, (4) the Queue Size High subfield may indicate a buffer status of a TID indicated in the TID High subfield, and/or (5) The Queue Size All subfield may indicate a combined buffer status (or a combined queue size) of all TIDs indicated in the TID bitmap subfield. In some embodiments, other than the features (1)-(5), the format of the BSR-TID Control field may be the same as the format of the BSR Control field.

In one approach, a first device may include one or more processors. The one or more processors may wirelessly receive, via a transceiver from a second device, a first frame. The one or more processors may identify one or more traffic identifiers from a first field of the first frame (e.g., TID bitmap subfield). The one or more processors may generate a second frame including buffer status data of one or more wireless traffic streams corresponding to the one or more traffic identifiers. The one or more processors may wirelessly transmit, via the transceiver, the generated second frame to the second device. In some embodiments, the second device may be an access point, a soft access point or a peer device.

In one approach, in generating the second frame, the one or more processors may be configured to set one or more bits of a traffic identifier bitmap field of the second frame (e.g., TID bitmap subfield) to indicate the one or more traffic identifiers. The traffic identifier bitmap field of the second frame may include a plurality of bits each corresponding to a traffic identifier associated with one of a plurality of traffic categories.

In one approach, in generating the second frame, the one or more processors may be configured to set a first queue size field of the second frame (e.g., Queue Size High subfield) to a highest queue size among one or more queue sizes of at least one wireless traffic streams associated with the one or more traffic identifiers. In generating the second frame, the one or more processors may be configured to set a first traffic identifier field of the second frame (e.g., TID High subfield) to a traffic identifier corresponding to the highest queue size. In some embodiments, in generating the second frame, the one or more processors may be configured to set a second queue size field of the second frame (e.g., Queue Size All subfield) to a total queue size of traffic associated with the one or more traffic identifiers.

In one approach, in identifying the one or more traffic identifiers from the first field of the first frame, the one or more processors may be configured to determine whether a frame type field of the first frame is a first type indicating a buffer status trigger frame, identify the first field as a traffic identifier bitmap field (e.g., TID bitmap subfield), and identify the one or more traffic identifiers from one or more bits of the traffic identifier bitmap field set to a defined value. The frame type field of the first frame may be a subfield of a common information field (e.g., Trigger Type field) that is shared among a plurality of users or devices. The frame type field of the first frame may indicate a type associated with a trigger frame (e.g., BSRP-TID Trigger frame).

Embodiments in the present disclosure have at least the following advantages and benefits.

First, embodiments in the present disclosure can provide useful techniques for providing a mechanism for a device (e.g., an AP) to trigger buffer status reporting based on one or more specific TIDs directly, thereby differentiating traffic streams with TIDs at a resolution higher than a resolution of differentiating traffic streams with ACs. With this higher resolution traffic differentiation mechanism, particular traffic streams can be identified, resulting in higher resolution frame/link/slot prioritization, increasing/improving QoS.

Second, embodiments in the present disclosure can provide useful techniques for allowing an AP to specify which TID(s) the AP wants to learn about its buffer status. For example, the rTWT agreement may be established between two extremely high throughput (EHT) STAs with one or more TIDs to be associated with traffic of each direction. When an AP triggers non-AP STAs during rTWT service periods (SPs), the AP can specify particular TIDs in a subfield of a BSRP-TID Trigger frame so that the STAs receiving the BSRP-TID Trigger frame can be notified of the particular TIDs.

Third, embodiments in the present disclosure can provide useful techniques for providing a mechanism for a device (e.g., STA) to send, in response to a buffer status reporting trigger frame based on one or more particular TIDs, a buffer status corresponding to the one or more particular TIDs. For example, in response to a BSRP-TID Trigger frame in which one or more particular TIDs are indicated, the STA can indicate a buffer status corresponding to the one or more particular TIDs in a newly defined BSR-TID Control field of a buffer status reporting frame (e.g., QoS-Data or QoS Null frames), so that the STA can report a buffer status of traffic streams that are requested by the AP (e.g., buffer status indicated in subfields of Queue Size High and/or a Queue Size All in the BSR-TID Control field).

FIG. 1 is a block diagram of an example artificial reality system environment 100 in which a console 110 operates. FIG. 1 provides an example environment in which devices may communicate traffic streams with different latency sensitivities/requirements. In some embodiments, the artificial reality system environment 100 includes a HWD 150 worn by a user, and a console 110 providing content of artificial reality to the HWD 150. A head wearable display (HWD) may be referred to as, include, or be part of a head mounted display (HIVID), head mounted device (HMD), head wearable device (HWD), head worn display (HWD) or head worn device (HWD). In one aspect, the HWD 150 may include various sensors to detect a location, an orientation, and/or a gaze direction of the user wearing the HWD 150, and provide the detected location, orientation and/or gaze direction to the console 110 through a wired or wireless connection. The HWD 150 may also identify objects (e.g., body, hand face).

The console 110 may determine a view within the space of the artificial reality corresponding to the detected location, orientation and/or the gaze direction, and generate an image depicting the determined view. The console 110 may also receive one or more user inputs and modify the image according to the user inputs. The console 110 may provide the image to the HWD 150 for rendering. The image of the space of the artificial reality corresponding to the user's view can be presented to the user. In some embodiments, the artificial reality system environment 100 includes more, fewer, or different components than shown in FIG. 1. In some embodiments, functionality of one or more components of the artificial reality system environment 100 can be distributed among the components in a different manner than is described here. For example, some of the functionality of the console 110 may be performed by the HWD 150, and/or some of the functionality of the HWD 150 may be performed by the console 110.

In some embodiments, the HWD 150 is an electronic component that can be worn by a user and can present or provide an artificial reality experience to the user. The HWD 150 may render one or more images, video, audio, or some combination thereof to provide the artificial reality experience to the user. In some embodiments, audio is presented via an external device (e.g., speakers and/or headphones) that receives audio information from the HWD 150, the console 110, or both, and presents audio based on the audio information. In some embodiments, the HWD 150 includes sensors 155, eye trackers 160, a communication interface 165, an image renderer 170, an electronic display 175, a lens 180, and a compensator 185. These components may operate together to detect a location of the HWD 150 and/or a gaze direction of the user wearing the HWD 150, and render an image of a view within the artificial reality corresponding to the detected location of the HWD 150 and/or the gaze direction of the user. In other embodiments, the HWD 150 includes more, fewer, or different components than shown in FIG. 1.

In some embodiments, the sensors 155 include electronic components or a combination of electronic components and software components that detect a location and/or an orientation of the HWD 150. Examples of sensors 155 can include: one or more imaging sensors, one or more accelerometers, one or more gyroscopes, one or more magnetometers, or another suitable type of sensor that detects motion and/or location. For example, one or more accelerometers can measure translational movement (e.g., forward/back, up/down, left/right) and one or more gyroscopes can measure rotational movement (e.g., pitch, yaw, roll). In some embodiments, the sensors 155 detect the translational movement and/or the rotational movement, and determine an orientation and location of the HWD 150. In one aspect, the sensors 155 can detect the translational movement and/or the rotational movement with respect to a previous orientation and location of the HWD 150, and determine a new orientation and/or location of the HWD 150 by accumulating or integrating the detected translational movement and/or the rotational movement. Assuming for an example that the HWD 150 is oriented in a direction 25 degrees from a reference direction, in response to detecting that the HWD 150 has rotated 20 degrees, the sensors 155 may determine that the HWD 150 now faces or is oriented in a direction 45 degrees from the reference direction. Assuming for another example that the HWD 150 was located two feet away from a reference point in a first direction, in response to detecting that the HWD 150 has moved three feet in a second direction, the sensors 155 may determine that the HWD 150 is now located at a vector multiplication of the two feet in the first direction and the three feet in the second direction.

In some embodiments, the eye trackers 160 include electronic components or a combination of electronic components and software components that determine a gaze direction of the user of the HWD 150. In some embodiments, the HWD 150, the console 110 or a combination may incorporate the gaze direction of the user of the HWD 150 to generate image data for artificial reality. In some embodiments, the eye trackers 160 include two eye trackers, where each eye tracker 160 captures an image of a corresponding eye and determines a gaze direction of the eye. In one example, the eye tracker 160 determines an angular rotation of the eye, a translation of the eye, a change in the torsion of the eye, and/or a change in shape of the eye, according to the captured image of the eye, and determines the relative gaze direction with respect to the HWD 150, according to the determined angular rotation, translation and the change in the torsion of the eye. In one approach, the eye tracker 160 may shine or project a predetermined reference or structured pattern on a portion of the eye, and capture an image of the eye to analyze the pattern projected on the portion of the eye to determine a relative gaze direction of the eye with respect to the HWD 150. In some embodiments, the eye trackers 160 incorporate the orientation of the HWD 150 and the relative gaze direction with respect to the HWD 150 to determine a gaze direction of the user. Assuming for an example that the HWD 150 is oriented at a direction 30 degrees from a reference direction, and the relative gaze direction of the HWD 150 is −10 degrees (or 350 degrees) with respect to the HWD 150, the eye trackers 160 may determine that the gaze direction of the user is 20 degrees from the reference direction. In some embodiments, a user of the HWD 150 can configure the HWD 150 (e.g., via user settings) to enable or disable the eye trackers 160. In some embodiments, a user of the HWD 150 is prompted to enable or disable the eye trackers 160.

In some embodiments, the hand tracker 162 includes an electronic component or a combination of an electronic component and a software component that tracks a hand of the user. In some embodiments, the hand tracker 162 includes or is coupled to an imaging sensor (e.g., camera) and an image processor that can detect a shape, a location and/or an orientation of the hand. The hand tracker 162 may generate hand tracking measurements indicating the detected shape, location and/or orientation of the hand.

In some embodiments, the communication interface 165 includes an electronic component or a combination of an electronic component and a software component that communicates with the console 110. The communication interface 165 may communicate with a communication interface 115 of the console 110 through a communication link. The communication link may be a wireless link, a wired link, or both. Examples of the wireless link can include a cellular communication link, a near field communication link, Wi-Fi, Bluetooth, or any communication wireless communication link. Examples of the wired link can include a USB, Ethernet, Firewire, HDMI, or any wired communication link. In embodiments in which the console 110 and the head wearable display 150 are implemented on a single system, the communication interface 165 may communicate with the console 110 through a bus connection or a conductive trace. Through the communication link, the communication interface 165 may transmit to the console 110 sensor measurements indicating the determined location of the HWD 150, orientation of the HWD 150, the determined gaze direction of the user, and/or hand tracking measurements. Moreover, through the communication link, the communication interface 165 may receive from the console 110 sensor measurements indicating or corresponding to an image to be rendered.

Using the communication interface, the console 110 (or HWD 150) may coordinate operations on link 101 to reduce collisions or interferences. For example, the console 110 may coordinate communication between the console 110 and the HWD 150. In some implementations, the console 110 may transmit a beacon frame periodically to announce/advertise a presence of a wireless link between the console 110 and the HWD 150 (or between two HWDs). In an implementation, the HWD 150 may monitor for or receive the beacon frame from the console 110, and can schedule communication with the HWD 150 (e.g., using the information in the beacon frame, such as an offset value) to avoid collision or interference with communication between the console 110 and/or HWD 150 and other devices.

The console 110 and HWD 150 may communicate using link 101 (e.g., intralink). Data (e.g., a traffic stream) may flow in a direction on link 101. For example, the console 110 may communicate using a downlink (DL) communication to the HWD 150 and the HWD 150 may communicate using an uplink (UL) communication to the console 110.

In some embodiments, the image renderer 170 includes an electronic component or a combination of an electronic component and a software component that generates one or more images for display, for example, according to a change in view of the space of the artificial reality. In some embodiments, the image renderer 170 is implemented as a processor (or a graphical processing unit (GPU)) that executes instructions to perform various functions described herein. The image renderer 170 may receive, through the communication interface 165, data describing an image to be rendered, and render the image through the electronic display 175. In some embodiments, the data from the console 110 may be encoded, and the image renderer 170 may decode the data to generate and render the image. In one aspect, the image renderer 170 receives the encoded image from the console 110, and decodes the encoded image, such that a communication bandwidth between the console 110 and the HWD 150 can be reduced.

In some embodiments, the image renderer 170 receives, from the console, 110 additional data including object information indicating virtual objects in the artificial reality space and depth information indicating depth (or distances from the HWD 150) of the virtual objects. Accordingly, the image renderer 170 may receive from the console 110 object information and/or depth information. The image renderer 170 may also receive updated sensor measurements from the sensors 155. The process of detecting, by the HWD 150, the location and the orientation of the HWD 150 and/or the gaze direction of the user wearing the HWD 150, and generating and transmitting, by the console 110, a high resolution image (e.g., 1920 by 1080 pixels, or 2048 by 1152 pixels) corresponding to the detected location and the gaze direction to the HWD 150 may be computationally exhaustive and may not be performed within a frame time (e.g., less than 11 ms or 8 ms).

In some implementations, the image renderer 170 may perform shading, reprojection, and/or blending to update the image of the artificial reality to correspond to the updated location and/or orientation of the HWD 150. Assuming that a user rotated their head after the initial sensor measurements, rather than recreating the entire image responsive to the updated sensor measurements, the image renderer 170 may generate a small portion (e.g., 10%) of an image corresponding to an updated view within the artificial reality according to the updated sensor measurements, and append the portion to the image in the image data from the console 110 through reprojection. The image renderer 170 may perform shading and/or blending on the appended edges. Hence, without recreating the image of the artificial reality according to the updated sensor measurements, the image renderer 170 can generate the image of the artificial reality.

In other implementations, the image renderer 170 generates one or more images through a shading process and a reprojection process when an image from the console 110 is not received within the frame time. For example, the shading process and the reprojection process may be performed adaptively, according to a change in view of the space of the artificial reality.

In some embodiments, the electronic display 175 is an electronic component that displays an image. The electronic display 175 may, for example, be a liquid crystal display or an organic light emitting diode display. The electronic display 175 may be a transparent display that allows the user to see through. In some embodiments, when the HWD 150 is worn by a user, the electronic display 175 is located proximate (e.g., less than 3 inches) to the user's eyes. In one aspect, the electronic display 175 emits or projects light towards the user's eyes according to image generated by the image renderer 170.

In some embodiments, the lens 180 is a mechanical component that alters received light from the electronic display 175. The lens 180 may magnify the light from the electronic display 175, and correct for optical error associated with the light. The lens 180 may be a Fresnel lens, a convex lens, a concave lens, a filter, or any suitable optical component that alters the light from the electronic display 175. Through the lens 180, light from the electronic display 175 can reach the pupils, such that the user can see the image displayed by the electronic display 175, despite the close proximity of the electronic display 175 to the eyes.

In some embodiments, the compensator 185 includes an electronic component or a combination of an electronic component and a software component that performs compensation to compensate for any distortions or aberrations. In one aspect, the lens 180 introduces optical aberrations such as a chromatic aberration, a pin-cushion distortion, barrel distortion, etc. The compensator 185 may determine a compensation (e.g., predistortion) to apply to the image to be rendered from the image renderer 170 to compensate for the distortions caused by the lens 180, and apply the determined compensation to the image from the image renderer 170. The compensator 185 may provide the predistorted image to the electronic display 175.

In some embodiments, the console 110 is an electronic component or a combination of an electronic component and a software component that provides content to be rendered to the HWD 150. In one aspect, the console 110 includes a communication interface 115 and a content provider 130. These components may operate together to determine a view (e.g., a field of view (FOV) of the user) of the artificial reality corresponding to the location of the HWD 150 and/or the gaze direction of the user of the HWD 150, and can generate an image of the artificial reality corresponding to the determined view. In other embodiments, the console 110 includes more, fewer, or different components than shown in FIG. 1. In some embodiments, the console 110 is integrated as part of the HWD 150. In some embodiments, the communication interface 115 is an electronic component or a combination of an electronic component and a software component that communicates with the HWD 150. The communication interface 115 may be a counterpart component to the communication interface 165 to communicate with a communication interface 115 of the console 110 through a communication link (e.g., USB cable, a wireless link). Through the communication link, the communication interface 115 may receive from the HWD 150 sensor measurements indicating the determined location and/or orientation of the HWD 150, the determined gaze direction of the user, and/or hand tracking measurements. Moreover, through the communication link, the communication interface 115 may transmit to the HWD 150 data describing an image to be rendered.

The content provider 130 can include or correspond to a component that generates content to be rendered according to the location and/or orientation of the HWD 150, the gaze direction of the user and/or hand tracking measurements. In one aspect, the content provider 130 determines a view of the artificial reality according to the location and orientation of the HWD 150 and/or the gaze direction of the user of the HWD 150. For example, the content provider 130 maps the location of the HWD 150 in a physical space to a location within an artificial reality space, and determines a view of the artificial reality space along a direction corresponding to an orientation of the HWD 150 and/or the gaze direction of the user from the mapped location in the artificial reality space.

The content provider 130 may generate image data describing an image of the determined view of the artificial reality space, and transmit the image data to the HWD 150 through the communication interface 115. The content provider may also generate a hand model (or other virtual object) corresponding to a hand of the user according to the hand tracking measurement, and generate hand model data indicating a shape, a location, and an orientation of the hand model in the artificial reality space.

In some embodiments, the content provider 130 generates metadata including motion vector information, depth information, edge information, object information, etc., associated with the image, and transmits the metadata with the image data to the HWD 150 through the communication interface 115. The content provider 130 may encode and/or encode the data describing the image, and can transmit the encoded and/or encoded data to the HWD 150. In some embodiments, the content provider 130 generates and provides the image to the HWD 150 periodically (e.g., every one second).

The scheduler 190A of the console 110 may configure a trigger frame. The trigger frame may be dependent on the trigger type. Example trigger frame types include a basic trigger frame, a beamforming report poll (BFRP) trigger frame, a multi-user (MU)—block acknowledge request (BAR) trigger frame, a MU—request to send (RTS) trigger frame, a buffer status report poll (BSRP) trigger frame, a group cast with retries (GCR) MU-BAR trigger frame, a bandwidth query report poll (BQRP) trigger frame, a null data packet feedback report poll (NFRP) trigger frame, and the like. The scheduler 190A may encode the trigger frame types (in a trigger type subfield) in the common information field of a trigger frame. The scheduler 190A may configure the trigger frame to be transmitted to multiple devices (e.g., HWD 150). When each device receives the trigger frame, the devices may decode the trigger frame to determine whether the frame is directed to the particular device. Details of a trigger frame format shall be described below with reference to FIGS. 4A-5.

Referring back to FIG. 1, if the trigger frame transmitted via the scheduler 190A of the console 110 is transmitted to a particular device (e.g., HWD 150), then the scheduler 190B of the device (e.g., HWD 150) may configure a response. The device may respond to the trigger frame with QoS data or buffer status data following the recommended format received from the console 110, for instance. In some implementations, the device may respond to the trigger frame to report on traffic differentiated via access categories (ACs). That is, the scheduler 190B of the HWD 150 may transmit an uplink (UL) frame in a format identified by the trigger frame, as discussed further herein with reference to FIGS. 4A-4B and 6. In some embodiments, the scheduler 190A of the console 110 may acknowledge the response to the trigger frame (e.g., acknowledge, block acknowledge, MU block acknowledge).

FIG. 2 is a diagram of a HWD 150, in accordance with an example embodiment. In some embodiments, the HWD 150 includes a front rigid body 205 and a band 210. The front rigid body 205 includes the electronic display 175 (not shown in FIG. 2), the lens 180 (not shown in FIG. 2), the sensors 155, the eye trackers 160A, 160B, the communication interface 165, and the image renderer 170. In the embodiment shown by FIG. 2, the sensors 155 are located within the front rigid body 205, and may not visible to the user. In other embodiments, the HWD 150 has a different configuration than shown in FIG. 2. For example, the image renderer 170, the eye trackers 160A, 160B, and/or the sensors 155 may be in different locations than shown in FIG. 2.

Various operations described herein can be implemented on computer systems. FIG. 3 shows a block diagram of a representative computing system 314 usable to implement the present disclosure. In some embodiments, the console 110, the HWD 150 or both of FIG. 1 are implemented by the computing system 314. Computing system 314 can be implemented, for example, as a consumer device such as a smartphone, other mobile phone, tablet computer, wearable computing device (e.g., smart watch, eyeglasses, head wearable display), desktop computer, laptop computer, or implemented with distributed computing devices. The computing system 314 can be implemented to provide VR, AR, MR experience. In some embodiments, the computing system 314 can include conventional computer components such as processors 316, storage device 318, network interface 320, user input device 322, and user output device 324.

Network interface 320 can provide a connection to a wide area network (e.g., the Internet) to which WAN interface of a remote server system is also connected. Network interface 320 can include a wired interface (e.g., Ethernet) and/or a wireless interface implementing various RF data communication standards such as Wi-Fi, Bluetooth, or cellular data network standards (e.g., 3G, 4G, 5G, 60 GHz, LTE, etc.).

The network interface 320 may include a transceiver to allow the computing system 314 to transmit and receive data from a remote device (e.g., an AP, a STA) using a transmitter and receiver. The transceiver may be configured to support transmission/reception supporting industry standards that enables bi-directional communication. An antenna may be attached to transceiver housing and electrically coupled to the transceiver. Additionally or alternatively, a multi-antenna array may be electrically coupled to the transceiver such that a plurality of beams pointing in distinct directions may facilitate in transmitting and/or receiving data.

A transmitter may be configured to wirelessly transmit frames, slots, or symbols generated by the processor unit 316. Similarly, a receiver may be configured to receive frames, slots or symbols and the processor unit 316 may be configured to process the frames. For example, the processor unit 316 can be configured to determine a type of frame and to process the frame and/or fields of the frame accordingly.

User input device 322 can include any device (or devices) via which a user can provide signals to computing system 314; computing system 314 can interpret the signals as indicative of particular user requests or information. User input device 322 can include any or all of a keyboard, touch pad, touch screen, mouse or other pointing device, scroll wheel, click wheel, dial, button, switch, keypad, microphone, sensors (e.g., a motion sensor, an eye tracking sensor, etc.), and so on.

User output device 324 can include any device via which computing system 314 can provide information to a user. For example, user output device 324 can include a display to display images generated by or delivered to computing system 314. The display can incorporate various image generation technologies, e.g., a liquid crystal display (LCD), light-emitting diode (LED) including organic light-emitting diodes (OLED), projection system, cathode ray tube (CRT), or the like, together with supporting electronics (e.g., digital-to-analog or analog-to-digital converters, signal processors, or the like). A device such as a touchscreen that function as both input and output device can be used. Output devices 324 can be provided in addition to or instead of a display. Examples include indicator lights, speakers, tactile “display” devices, printers, and so on.

Some implementations include electronic components, such as microprocessors, storage and memory that store computer program instructions in a computer readable storage medium (e.g., non-transitory computer readable medium). Many of the features described in this specification can be implemented as processes that are specified as a set of program instructions encoded on a computer readable storage medium. When these program instructions are executed by one or more processors, they cause the processors to perform various operation indicated in the program instructions. Examples of program instructions or computer code include machine code, such as is produced by a compiler, and files including higher-level code that are executed by a computer, an electronic component, or a microprocessor using an interpreter. Through suitable programming, processor 316 can provide various functionality for computing system 314, including any of the functionality described herein as being performed by a server or client, or other functionality associated with message management services.

It will be appreciated that computing system 314 is illustrative and that variations and modifications are possible. Computer systems used in connection with the present disclosure can have other capabilities not specifically described here. Further, while computing system 314 is described with reference to particular blocks, it is to be understood that these blocks are defined for convenience of description and are not intended to imply a particular physical arrangement of component parts. For instance, different blocks can be located in the same facility, in the same server rack, or on the same motherboard. Further, the blocks need not correspond to physically distinct components. Blocks can be configured to perform various operations, e.g., by programming a processor or providing appropriate control circuitry, and various blocks might or might not be reconfigurable depending on how the initial configuration is obtained. Implementations of the present disclosure can be realized in a variety of apparatus including electronic devices implemented using any combination of circuitry and software.

FIGS. 1-2 illustrate devices that communicate traffic streams, some of which may be latency sensitive (e.g., those carrying AR/VR information/content). In some embodiments, devices (e.g., STAs, HWD 150, consoles 110, APs) may differentiate traffic streams using ACs. However, QoS data frames may contain traffic stream identifiers (TIDs) in a QoS subfield (e.g., a QoS control subfield). TIDs (one or multiple) may be mapped to one AC. Accordingly, differentiating traffic streams using ACs is a low resolution mechanism of differentiating traffic streams. In contrast, differentiating traffic streams using TIDs may be higher resolution (e.g., particular traffic streams are identified, resulting in higher resolution frame/link/slot prioritization, increasing/improving QoS). Various embodiments of providing a mechanism for a device (e.g., AP) to trigger based on TID will be described below with reference to FIGS. 4A to 8.

FIG. 4A illustrates an example trigger frame format and an example common information field format, according to an example implementation of the present disclosure. FIG. 4B illustrates an example trigger frame format and example user information field formats, according to example implementations of the present disclosure. FIG. 5 is a table of trigger frame types/variants (e.g., encoding trigger frame formats), according to an example implementation of the present disclosure.

Referring to FIG. 4A, illustrated is a trigger frame format 400 (e.g., newly defined BSRP-TID Trigger frame) and a common information field format 402. The common information field format 402 includes a trigger frame type field 404. Referring to FIG. 5, illustrated is an example table 500 of trigger type subfield encoding. That is, the encoding values in table 500 may be set in the trigger type subfield 404 of FIG. 4.

In other implementations, other frames may be modified (or repurposed/reconfigured/added), to include prioritized TID information. For example, an AP may solicit/request a STA(s) traffic information (e.g., buffer status) by transmitting a Buffer

Status Report Poll (BSRP) (or other trigger frames). In some implementations, the BSRP Trigger frame may trigger one STA or multiple STAs to communicate/report the buffer status to the AP. In some implementations however, the BSRP Trigger Frame may not indicate TID information (e.g., there may not be a Trigger Dependent Common Information subfield and/or a Trigger Dependent User Information subfield). Accordingly, the AP may not be able to specify/request the buffer status of particular (e.g., prioritized) TIDs and the STA may not (be able to) transmit/report the buffer status of certain particular TIDs.

In some embodiments, trigger frames may be modified/adapted/configured to include TID information. In one embodiment, a new Trigger frame type format (e.g., a new BSRP-TID Trigger frame) may be encoded in table 500 of FIG. 5. For example, one or more reserved bits (e.g., bits 8-15) may be associated with the new trigger frame type. Referring to FIG. 4B, illustrated is an example BSRP-TID Trigger frame including Trigger Dependent User Information field 418. As shown, the BSRP-Trigger frame may include a TID bitmap subfield 432. The TID bitmap subfield 432 may be eight bits (or other number of bits/bytes). The TID bitmap subfield 432 may specify (e.g., prioritized) TIDs whose buffer status is requested by the transmitting AP. For example, if bit k is set, then the responding STA may include the kth TID's buffer status in the responding frame. It should be appreciated that BSRP-TID Trigger frame including Trigger Dependent User Information field 418may include other subfields (e.g., portions of the TID bitmap 432 may be repurposed, reconfigured, and/or subfields may be added to the Trigger Dependent User Information field 418)

Referring to FIG. 4B, illustrated is a trigger frame format 400 (e.g., newly defined BSRP-TID Trigger frame) and a user information field 412. A frame may be directed to a particular device if the device's association ID (AID) is indicated in the AID field 414 of the user information field 412. That is, each AID may represent a STA. In some embodiments, one or more reserved (or other) bits of the user information field 412 may be repurposed (e.g., re-used, reconfigured, or modified) to indicate a Trigger TID subfield 416. In some embodiments, if the Trigger TID subfield 416 is set to ‘1’ (or ‘0’) and the trigger type 404 in the common information field 402 (in FIG. 4A) is configured for a basic trigger type, then the Trigger Dependent User Information field 418 (or Trigger Type Dependent User Information Field) of the User Information Field 412 may be defined as shown in Trigger Dependent User Information field 418. Trigger Dependent User Information field 418 illustrates one variant of a Trigger Dependent User Information field 418. It should be appreciated that each of the subfields in the Trigger Dependent User Information field 418 variants may be rearranged or renamed, or fields may be replaced, added, renamed, inserted, or deleted.

For example, one or more bits in Trigger Dependent User Information field 418 may indicate a TID bitmap 432. If bit k of the TID bitmap 424 is set, then TID k may be recommended for TID aggregation (e.g., TID aggregation of MAC Protocol Data Unit (MPDU) in the aggregated MPDU to be included in the high efficiency (HE) or extremely high throughput (EHT) TB-PPDU). For example, six bits (e.g., bits 2-7) of the TID bitmap 432 may identify six TIDs belonging to AC_BE, AC_VI, and/or AC_VO. Accordingly, each bit of the TID bitmap 424 may correspond to an ordered set of TIDs from bits 2-7 (excluding TIDs 0,1 from AC BK, for instance). In some implementations, each bit of a TID bitmap subfield (e.g., TID bitmap 432) may indicate (if set to 1 for instance) a corresponding one of 8 TIDs belonging to AC_BK, AC_BE, AC_VI, and AC_VO as shown in Table 1.

In one implementation, a new trigger frame type (e.g., BSRP-TID Trigger frame) may be added or defined for an AP to trigger buffer status reporting based on one or more TIDs using a BSRP-TID Trigger frame. In some embodiments, the BSRP-TID Trigger frame (e.g., BSRP-TID Trigger frame 400) may include a Trigger Type subfield (e.g., Trigger Type 404 in FIG. 4A) which may be set to 8 or any value not used by other trigger frame types (e.g., type values 8 or more that are not used in Table 500). The format of the BSRP-TID Trigger frame may be the same as a BSRP Trigger frame except, for example, a type dependent per user info subfield (e.g., Trigger Dependent User Info 418) may be present and may have a TID bitmap subfield (e.g., TID bitmap 432), which specifies TID(s) whose buffer status is requested by the transmitting AP. The TID bitmap subfield may be a one octet field (e.g., B0-B7 as shown in FIG. 4B). In some embodiments, if bit k of the TID bitmap subfield is set, then the responding STA may include a buffer status of the k-th TID in a responding HE/EHT TB PPDU frame (e.g., Control Information subfield 620 in a BSR-TID Control Field of QoS-Data or QoS Null frames in FIG. 6).

FIG. 6 is an example of a Control Information subfield in a BSR Control Field, according to an example implementation of the present disclosure.

In response to the BSRP-TID Trigger frame 400 (see FIG. 4B), the STA may indicate/report the buffer status using one or more QoS Control Fields or BSR Control Fields. FIG. 6 illustrates examples of Control Information subfield in a BSR Control Field. As shown, an AC Bitmap 604 may be included in Control Information subfield 602. However, in some configurations, eight TIDs may map to four ACs. Accordingly, the responding STA may not be specifically indicate the buffer status of particular TIDs. In an example, TIDs 6 and 7 may carry latency sensitive traffic. Using the AC Bitmap 604, the responding STA may not communicate to the AP the status of the particular TIDs. In contrast, using the ACI Bitmap 604, a buffer status of all TIDs in an ACI, or other TIDs in an AC determined by the STA, may be communicated to the AP. The Delta TID 606 may indicate the number of TIDs associated with the AC (e.g., one TID or two TIDs), but not a particular TID associated with the AC. ACI High 608 may be used to indicate a prioritized AC (but not particular TIDs associated with the ACI).

In contrast, Control Information subfield 620 in a BSR-TID Control Field may replace (or modify, reconfigure, repurpose, insert) ACI Bitmap 604 with TID bitmap 614 for instance. In some embodiments, TID bitmap 614 may have eight bits (or other number of bits/bytes). Similarly, TID High 616 may replace (or modify, reconfigure, repurpose) ACI High 608 such that a particular (e.g., prioritized) TID may be identified. The queue size of the identified TID in TID High 616 may be indicated in Queue Size High 618. For example, if TID 7 has a highest queue size among all queue sizes of TIDs indicated in TID bitmap 614, TID High 616 may be set to 7 (e.g., binary number 111 is set in B8-B10 of TID High 616). Further, Queue Size All 619 may indicate the cumulative/combined/total queue size for all of the TIDs. It should be appreciated that each of the subfields in the Control Information subfield 620 in a BSR-TID Control Field may be rearranged, or fields may be replaced, added, inserted, or deleted. For example, TID High 616 may be indicated by bits 0-2, and TID bitmap 614 may be indicated by bits 3-10.

In one example implementation, the TID High 616 may indicate the TID requested by the AP (using, for instance, the BSRP-TID Trigger frame 400 in FIG. 4B). If the AP does not specify particular TIDs, then the Control Information subfield 620 in the BSR-TID Control Field may not specify a TID in TID High 616.

In a different example, the AP may request the buffer status of TID 0 and TID 1 in the TID bitmap 432 of the BSRP-TID Trigger frame 400 in FIG. 4B (e.g., bits 0 and 1 may be set to ‘1’, for instance). Then the STA may respond with the buffer status of TID 0 and TID 1 by setting the TID bitmap 614 in the Control Information subfield 620 in the BSR-TID Control Field (e.g., bits 0 and 1 may be set to ‘1’, for instance). In the example, the buffer status (e.g., queue size) for TID 0 may be 100 bytes and for TID 1 may be 150 bytes. The STA may indicate TID 0 in TID High 616. Accordingly, the buffer status associated with TID 0 may be indicated in Queue Size High 618 (e.g., 100 bytes). The Queue size all 619 may indicate at least 250 bytes (e.g., the sum of the bytes of all (or a portion) of the TIDs).

In response to the AP receiving the buffer status from the STA(s) (e.g., Control Information subfield 620 in the BSR-TID Control Field), the AP may manage resources (e.g., schedule appropriate resources/channel time/durations of frames).

In one embodiment, a new BSR control field (e.g., Control Information subfield 620 in a BSR-TID Control field) may be defined in a buffer status reporting frame (e.g., QoS-Data or QoS Null frames) to specify a buffer status corresponding to one or more particular TIDs. In some embodiments, the Control Information subfield 620 in the BSR-TID Control field may be added to a subfield of a HE variant HT Control field (e.g., Aggregate control (A-Control) subfield). For example, the A-Control subfield may include Control ID subfield which is set to a new Control ID (e.g., type 9 or other available type values that are not used for other types of control).

In one embodiment, the Control Information subfield 620 in the BSR-TID Control field may include a TID bitmap subfield (e.g., TID bitmap 614), a TID High subfield (e.g., TID High 616), a Scaling Factor subfield (Scaling Factor 617), a Queue Size High subfield (e.g., Queue Size High 618), and/or a Queue Size All subfield (e.g., Queue Size All 619). The TID bitmap subfield may have the size of 8 bit. The TID High subfield may have the size of 3 bits. The Scaling Factor subfield may represent one of a plurality of scaling factors (e.g., 0, 1, 2, 3) which respectively correspond to a plurality of units (e.g., 16 octets, 256 octets, 2048 octets, 32768 octets) used to represent a queue size in Queue Size High 618 and Queue Size All 619.

Compared to the BSR Control field (e.g., BSR Control field 602), (1) 4 bit ACI Bitmap subfield (e.g., ACI Bitmap 604) may be replaced with an 8 bit TID bitmap 614, (2) the Delta TID subfield (e.g., Delta TID 606) may not be needed anymore and hence removed, (3) a 2 bit ACI High subfield (e.g., ACI High 608) may be replaced with 3 bit TID High 616, (4) the Queue Size High 618 may indicate a buffer status of a TID indicated in the TID High 616, and/or (5) The Queue Size All 619 may indicate a combined buffer status (or a combined queue size) of all TIDs indicated in the TID bitmap 614. In some embodiments, other than the features (1)-(5), the format of the BSR-TID Control field (e.g., Control Information subfield 620 in the BSR-TID Control field) may be the same as the format of the BSR Control field (e.g., BSR Control field 602).

FIG. 7 is a flowchart showing a process 700 of triggering buffer status reporting for transmission streams, according to an example implementation of the present disclosure. In some embodiments, the process 700 is performed by a device (e.g., Console 110, HWD 150, AP or STA). In some embodiments, the process 700 is performed by other entities. In some embodiments, the process 700 includes more, fewer, or different steps than shown in FIG. 7.

In one approach, the device may determine 702 a first traffic identifier of a first wireless traffic stream (e.g., one or more particular TIDs associated with one or more traffic categories; see Table 1), from a plurality of traffic identifiers (e.g., a plurality TIDs shown in the right column of Table 1). In some embodiments, the device may be an AP, a soft access point (e.g., soft-AP) or a peer device (e.g., STAs communicating peer-to-peer traffic between themselves).

In one approach, the device may generate 704 a first frame including the first traffic identifier (e.g., BSRP-TID Trigger frame 400 including one or more particular TIDs set in TID bitmap subfield 432). The first frame may be to trigger/request/cause a receiver device (e.g., Console 110, HWD 150, AP or STA) to send a response frame that includes buffer status data corresponding to the first wireless traffic stream (e.g., QoS Data or QoS Null frame in which Control Information subfield 620 is included in BSR-TID Control Field).

In some embodiments, in generating the first frame (e.g., BSRP-TID Trigger frame 400), the device may set a frame type field of the first frame (e.g., Trigger Type 403) to a first type (e.g., trigger type 8 which is not used in Table 500 in FIG. 5) indicating a buffer status trigger frame including one or more traffic identifiers, and set a first bit of a traffic identifier bitmap field of the first frame (e.g., kth bit of TID Bitmap 432) to indicate the first traffic identifier (e.g., kth TID). The traffic identifier bitmap field of the first frame may include a plurality of bits (e.g., B0-B7 of TID Bitmap 432) each corresponding to a traffic identifier associated with one of a plurality of traffic categories (e.g., one of AC_BE, AC_VI, AC_VO). The frame type field of the first frame (e.g., Trigger Type 403) may be a subfield of a common information field (e.g., common information field format 402) that is shared among a plurality of users or receiver devices.

In some embodiments, the response frame (e.g., QoS Data or QoS Null frame in which Control Information subfield 620 is included in BSR-TID Control Field) may include a traffic identifier bitmap field (e.g., TID bitmap 614) indicating one or more traffic identifiers. The traffic identifier bitmap field of the response frame may include a plurality of bits (e.g., B0-B7 of TID bitmap 614) each corresponding to a traffic identifier associated with one of a plurality of traffic categories (e.g., one of AC_BE, AC_VI, AC_VO). The response frame may include a first queue size field (e.g., Queue Size High 618) indicating a highest queue size among one or more queue sizes of at least one wireless traffic stream associated with the one or more traffic identifiers (e.g., TIDs indicated in TID bitmap 614). The response frame may include a first traffic identifier field (e.g., TID High 616) indicating a traffic identifier corresponding to the highest queue size (e.g., Queue Size High 618). The response frame includes a second queue size field (e.g., Queue Size All 619) indicating a total queue size of traffic associated with the one or more traffic identifiers.

In one approach, the device (e.g., AP) may wirelessly transmit 706, via a transmitter (e.g., network interface 320), the generated first frame (e.g., BSRP-TID Trigger frame 400) to the receiver device (e.g., STA).

FIG. 8 is a flowchart showing a process 800 of sending buffer status reporting for transmission streams, according to an example implementation of the present disclosure. In some embodiments, the process 800 is performed by a first device (e.g., Console 110 or HWD 150 or STA). In some embodiments, the process 800 is performed by other entities. In some embodiments, the process 800 includes more, fewer, or different steps than shown in FIG. 8.

In one approach, the first device may wirelessly receive 802, from a second device (e.g., Console 110 or HWD 150 or AP), a first frame (e.g., BSRP-TID Trigger frame 400). In some embodiments, the second device may be an AP, a soft access point (e.g., soft-AP) or a peer device (e.g., STAs communicating peer-to-peer traffic between themselves).

In one approach, the first device may identify 804 one or more traffic identifier (e.g., one or more particular TIDs associated with one or more traffic categories; see Table 1) from a first field of the first frame (e.g., TID bitmap 432).

In some embodiments, in identifying the one or more traffic identifiers from the first field of the first frame (e.g., TID bitmap 432), the first device may determine whether a frame type field of the first frame (e.g., Trigger Type 404) is a first type indicating a buffer status trigger frame (e.g., type indicating a newly defined BSRP-TID Trigger frame 400, which is not used in the table 500 in FIG. 5), identify the first field as a traffic identifier bitmap field, and identify the one or more traffic identifiers from one or more bits of the traffic identifier bitmap field set to a defined value (e.g., one or more bits of TID bitmap 432 set to 1). The frame type field of the first frame may be a subfield of a common information field (e.g., common information field 402) that is shared among a plurality of users or devices (e.g., a plurality of STAs). The frame type field of the first frame (e.g., Trigger Type 404) may indicate/specify/identify a type associated with a trigger frame (e.g., newly defined BSRP-TID Trigger frame).

In one approach, the first device may generate 806 a second frame (e.g., QoS Data or QoS Null frame) including buffer status data of one or more wireless traffic streams corresponding to the one or more traffic identifier (e.g., one or more TIDs identified from TID bitmap 432).

In some embodiments, in generating the second frame, the first device may set/configure one or more bits of a traffic identifier bitmap field of the second frame (e.g., TID bitmap 614 of Control Information subfield 620 in BSR-TID Control Field) to indicate the one or more traffic identifiers. The traffic identifier bitmap field of the second frame may include a plurality of bits (e.g., B0-B7 of TID bitmap 614) each corresponding to a traffic identifier associated with one of a plurality of traffic categories.

In some embodiments, in generating the second frame, the first device may set a first queue size field of the second frame (e.g., Queue Size High 618) to a highest queue size among one or more queue sizes of at least one wireless traffic streams associated with the one or more traffic identifiers. In generating the second frame, the first device may set a first traffic identifier field of the second frame (e.g., TID High 616) to a traffic identifier corresponding to the highest queue size. In some embodiments, in generating the second frame, the first device may set a second queue size field of the second frame (e.g., Queue Size All 619) to a total queue size of traffic associated with the one or more traffic identifiers.

In one approach, the first device (e.g., STA) may wirelessly transmit 808, via a transmitter (e.g., network interface 320), the generated second frame (e.g., QoS Data or QoS Null frame) to the second device (e.g., AP).

Having now described some illustrative implementations, it is apparent that the foregoing is illustrative and not limiting, having been presented by way of example. In particular, although many of the examples presented herein involve specific combinations of method acts or system elements, those acts and those elements can be combined in other ways to accomplish the same objectives. Acts, elements and features discussed in connection with one implementation are not intended to be excluded from a similar role in other implementations or implementations.

The hardware and data processing components used to implement the various processes, operations, illustrative logics, logical blocks, modules and circuits described in connection with the embodiments disclosed herein may be implemented or performed with a general purpose single- or multi-chip processor, a digital signal processor (DSP), an application specific integrated circuit (ASIC), a field programmable gate array (FPGA), or other programmable logic device, discrete gate or transistor logic, discrete hardware components, or any combination thereof designed to perform the functions described herein. A general purpose processor may be a microprocessor, or, any conventional processor, controller, microcontroller, or state machine. A processor also may be implemented as a combination of computing devices, such as a combination of a DSP and a microprocessor, a plurality of microprocessors, one or more microprocessors in conjunction with a DSP core, or any other such configuration. In some embodiments, particular processes and methods may be performed by circuitry that is specific to a given function. The memory (e.g., memory, memory unit, storage device, etc.) may include one or more devices (e.g., RAM, ROM, Flash memory, hard disk storage, etc.) for storing data and/or computer code for completing or facilitating the various processes, layers and modules described in the present disclosure. The memory may be or include volatile memory or non-volatile memory, and may include database components, object code components, script components, or any other type of information structure for supporting the various activities and information structures described in the present disclosure. According to an exemplary embodiment, the memory is communicably connected to the processor via a processing circuit and includes computer code for executing (e.g., by the processing circuit and/or the processor) the one or more processes described herein.

The present disclosure contemplates methods, systems and program products on any machine-readable media for accomplishing various operations. The embodiments of the present disclosure may be implemented using existing computer processors, or by a special purpose computer processor for an appropriate system, incorporated for this or another purpose, or by a hardwired system. Embodiments within the scope of the present disclosure include program products comprising machine-readable media for carrying or having machine-executable instructions or data structures stored thereon. Such machine-readable media can be any available media that can be accessed by a general purpose or special purpose computer or other machine with a processor. By way of example, such machine-readable media can comprise RAM, ROM, EPROM, EEPROM, or other optical disk storage, magnetic disk storage or other magnetic storage devices, or any other medium which can be used to carry or store desired program code in the form of machine-executable instructions or data structures and which can be accessed by a general purpose or special purpose computer or other machine with a processor. Combinations of the above are also included within the scope of machine-readable media. Machine-executable instructions include, for example, instructions and data which cause a general purpose computer, special purpose computer, or special purpose processing machines to perform a certain function or group of functions.

The phraseology and terminology used herein is for the purpose of description and should not be regarded as limiting. The use of “including” “comprising” “having” “containing” “involving” “characterized by” “characterized in that” and variations thereof herein, is meant to encompass the items listed thereafter, equivalents thereof, and additional items, as well as alternate implementations consisting of the items listed thereafter exclusively. In one implementation, the systems and methods described herein consist of one, each combination of more than one, or all of the described elements, acts, or components.

Any references to implementations or elements or acts of the systems and methods herein referred to in the singular can also embrace implementations including a plurality of these elements, and any references in plural to any implementation or element or act herein can also embrace implementations including only a single element. References in the singular or plural form are not intended to limit the presently disclosed systems or methods, their components, acts, or elements to single or plural configurations. References to any act or element being based on any information, act or element can include implementations where the act or element is based at least in part on any information, act, or element.

Any implementation disclosed herein can be combined with any other implementation or embodiment, and references to “an implementation,” “some implementations,” “one implementation” or the like are not necessarily mutually exclusive and are intended to indicate that a particular feature, structure, or characteristic described in connection with the implementation can be included in at least one implementation or embodiment. Such terms as used herein are not necessarily all referring to the same implementation. Any implementation can be combined with any other implementation, inclusively or exclusively, in any manner consistent with the aspects and implementations disclosed herein.

Where technical features in the drawings, detailed description or any claim are followed by reference signs, the reference signs have been included to increase the intelligibility of the drawings, detailed description, and claims. Accordingly, neither the reference signs nor their absence have any limiting effect on the scope of any claim elements.

Systems and methods described herein may be embodied in other specific forms without departing from the characteristics thereof. References to “approximately,” “about” “substantially” or other terms of degree include variations of +/−10% from the given measurement, unit, or range unless explicitly indicated otherwise. Coupled elements can be electrically, mechanically, or physically coupled with one another directly or with intervening elements. Scope of the systems and methods described herein is thus indicated by the appended claims, rather than the foregoing description, and changes that come within the meaning and range of equivalency of the claims are embraced therein.

The term “coupled” and variations thereof includes the joining of two members directly or indirectly to one another. Such joining may be stationary (e.g., permanent or fixed) or moveable (e.g., removable or releasable). Such joining may be achieved with the two members coupled directly with or to each other, with the two members coupled with each other using a separate intervening member and any additional intermediate members coupled with one another, or with the two members coupled with each other using an intervening member that is integrally formed as a single unitary body with one of the two members. If “coupled” or variations thereof are modified by an additional term (e.g., directly coupled), the generic definition of “coupled” provided above is modified by the plain language meaning of the additional term (e.g., “directly coupled” means the joining of two members without any separate intervening member), resulting in a narrower definition than the generic definition of “coupled” provided above. Such coupling may be mechanical, electrical, or fluidic.

References to “or” can be construed as inclusive so that any terms described using “or” can indicate any of a single, more than one, and all of the described terms. A reference to “at least one of ‘A’ and ‘B’” can include only ‘A’, only ‘B’, as well as both ‘A’ and ‘B’. Such references used in conjunction with “comprising” or other open terminology can include additional items.

Modifications of described elements and acts such as variations in sizes, dimensions, structures, shapes and proportions of the various elements, values of parameters, mounting arrangements, use of materials, colors, orientations can occur without materially departing from the teachings and advantages of the subject matter disclosed herein. For example, elements shown as integrally formed can be constructed of multiple parts or elements, the position of elements can be reversed or otherwise varied, and the nature or number of discrete elements or positions can be altered or varied. Other substitutions, modifications, changes and omissions can also be made in the design, operating conditions and arrangement of the disclosed elements and operations without departing from the scope of the present disclosure.

References herein to the positions of elements (e.g., “top,” “bottom,” “above,” “below”) are merely used to describe the orientation of various elements in the FIGURES. The orientation of various elements may differ according to other exemplary embodiments, and that such variations are intended to be encompassed by the present disclosure.
