Patent: Viewing device with dust seal integration

Drawings: Click to check drawins

Publication Number: 20210325682

Publication Date: 20211021

Applicants: Magic Leap

Assignee: Magic Leap

Abstract

An open cell foam is used to create a seal between a camera and a shell piece. The shell piece, camera, seal and a transparent window form a closed front cavity. Because the cavity is closed, dust can remain away from a lens of the camera.

Claims

1. A viewing device comprising: a shell piece defining a first window opening; an internal mounting structure secured to the shell piece; a first camera assembly including: a transparent window mounted to the shell piece over the window first opening, the transparent window having a periphery that makes continuous contact with the shell piece; a camera having a lens, the camera being mounted to the internal mounting structure with a gap defined between the lens and the window; and a seal having a first external surface contacting the shell piece and a second external surface contacting the camera so that a closed front cavity is defined jointly by the window, the lens and the seal.

2. The viewing device of claim 1, wherein the window opening is circular and the periphery of the window is circular.

3. The viewing device of claim 2, wherein the first external surface is circular.

4. The viewing device of claim 1, wherein the second external surface is circular.

5. The viewing device of claim 1, wherein the seal includes first and second seal members having first and second engagement surfaces, respectively, that make contact with each other.

6. The viewing device of claim 5, wherein the first and second seal members are attached to the shell piece and the internal mounting structure respectively.

7. The viewing device of claim 6, wherein the internal mounting structure and the shell piece are moved towards each other to cause the first and second engagement surfaces to come into contact with each other.

8. The viewing device of claim 7, wherein the first and second engagement surfaces are deformed when the shell piece and the internal mounting structure are moved towards each other.

9. The viewing device of claim 8, wherein the first and second seal members are made of foam.

10. The viewing device of claim 9, wherein the foam is an open cell foam.

11. The viewing device of claim 9, wherein the second seal member is a cylindrical member with a front face, a rear face, an outer surface and an inner surface, wherein the second engagement surface includes the front face, the second external surface includes the inner surface.

12. The viewing device of claim 9, further comprising: an adhesive between the rear face and the mounting structure.

13. The viewing device of claim 12, wherein the rear face has an outer annulus and an inner annulus, the outer annulus being further from the camera than the inner annulus, and the adhesive is located on the outer annulus and not on the inner annulus.

14. The viewing device of claim 1, wherein the seal is made of foam having an initial dimension that is compressible to a final dimension before hard stacking, wherein the final dimension is less than 10 percent of the initial dimension.

15. The viewing device of claim 1, wherein the seal is made of foam having an initial dimension that is compressible to a final dimension, wherein the compression creates a force and compression setting occurs wherein the force reduces over time.

16. The viewing device of claim 15, wherein the force reduces by 50 percent in less than five minutes.

17. The viewing device of claim 1, wherein the seal is an annular seal that surrounds the camera the second external surface makes continuous contact with the camera around the camera.

18. The viewing device of claim 1, wherein the shell piece defined a second window opening, further comprising: a second camera assembly including: a transparent window mounted to the shell piece over the window first opening, the window having a periphery that makes continuous contact with the shell piece; a camera having a lens, the camera being mounted to the internal mounting structure with a gap defined between the lens and the window; and a seal having a first external surface contacting the shell piece and a second external surface contacting the camera so that a closed front cavity is defined jointly by the window, the lens and the seal.

19. The viewing device of claim 18, wherein the shell piece and the internal mounting structure are moved from a spaced relationship to an assembled relationship relatively towards one another to form the closed cavity of the first camera assembly and the closed cavity of the second camera assembly.

20. The viewing device of claim 19, wherein the seals of the first and second camera assemblies are deformed when the shell piece and the internal mounting structure are moved relatively towards one another.

21. The viewing device of claim 20, further comprising: a fastener that retains the shell piece and the internal mounting structure in the assembled relationship.

22. A method of constructing a viewing device comprising: mounting a transparent window to the shell piece over the window opening defined by the shell piece, the window having a periphery that makes continuous contact with the shell piece; mounting a camera to the internal mounting structure; locating a seal between the shell piece and the internal mounting structure; and securing the internal mounting structure to the shell piece with a gap defined between a lens of the camera and the window and with the seal having a first external surface contacting the shell piece and a second external surface contacting the camera so that a closed front cavity is defined jointly by the window, the lens and the seal.

23. The viewing device of claim 22, wherein the seal includes first and second seal members that are attached to the shell piece and the internal mounting structure, respectively, and having first and second engagement surfaces, respectively, that make contact with each other.

24. The viewing device of claim 23, further comprising: moving the internal mounting structure and the shell piece towards each other to cause the first and second engagement surfaces to come into contact with each other.

25. The viewing device of claim 24, wherein the first and second engagement surfaces are deformed when the shell piece and the internal mounting structure are moved towards each other.

Description

CROSS-REFERENCE TO RELATED APPLICATIONS

[0001] This application claims priority from U.S. Provisional Patent Application No. 62/702,731, filed on Jul. 24, 2018, all of which is incorporated herein by reference in its entirety.

BACKGROUND OF THE INVENTION

1). Field of the Invention

[0002] This invention relates generally to a viewing device and more specifically to a method of forming and assembling a dust seal in a viewing device.

2). Discussion of Related Art

[0003] Modern computing and display technologies have facilitated development of visual perception devices such as "virtual reality" viewing devices. A virtual reality viewing device may be a wearable device that presents the user with two images, one for the left eye and one for the right eye. Objects in the images may differ from one another in a manner that allows the brain to process the objects as a three-dimensional object. When the images constantly change, movement in three-dimensions can be simulated. A virtual reality viewing device typically involves presentation of digital or virtual image information without transparency to other real-world objects.

[0004] Other visual perception devices, so called "augmented reality" viewing devices usually include technology that allows for the presentation of digital and virtual image information as an augmentation to visualization of the actual world around the user. An augmented reality viewing device may, for example, have one or more transparent eyepieces that allow the user to see real world objects behind the eyepieces. Such an eyepiece can serve as a wave guide through which light propagates from a projector towards an eye of the user. A light pattern created by the projector becomes visible on the retina of the eye. The retina of the eye then receives light from the real-world objects behind the eyepiece and light from the projector. Real world objects are thus augmented with image data from the projector, in the perception of the user.

[0005] Augmented reality devices often have technology that permit for an object to remain in a stationary position relative to real world objects, as perceived by the user, even if the user would move their head. If the user would, for example, rotate their head to the right, the rendered object has to rotate to the left within the view of the user together with real world objects. Movement of the augmented reality device may be tracked through a visual system that includes one or more cameras and depth sensors in combination with a measurement device such as an inertial measurement unit (IMU) so that the position of the object can be adjusted via the projector.

SUMMARY OF THE INVENTION

[0006] The invention provides a viewing device including a shell piece defining a first window opening, an internal mounting structure secured to the shell piece, a first camera assembly including, a transparent window mounted to the shell piece over the window first opening, the transparent window having a periphery that makes continuous contact with the shell piece, a camera having a lens, the camera being mounted to the internal mounting structure with a gap defined between the lens and the window and a seal having a first external surface contacting the shell piece and a second external surface contacting the camera so that a closed front cavity is defined jointly by the window, the lens and the seal.

[0007] The invention also provides a method of constructing a viewing device including mounting a transparent window to the shell piece over the window opening defined by the shell piece, the window having a periphery that makes continuous contact with the shell piece, mounting a camera to the internal mounting structure, locating a seal between the shell piece and the internal mounting structure and securing the internal mounting structure to the shell piece with a gap defined between a lens of the camera and the window and with the seal having a first external surface contacting the shell piece and a second external surface contacting the camera so that a closed front cavity is defined jointly by the window, the lens and the seal.

BRIEF DESCRIPTION OF THE DRAWINGS

[0008] The invention is further described by way of example with reference to the accompanying drawings, wherein:

[0009] FIG. 1 is a perspective view of a viewing device, according to an embodiment of the invention with an internal mounting structure and a shell piece shown in a space relationship relative to one another;

[0010] FIG. 2 is perspective view of the viewing device with the internal mounting structure and the shell piece in an assembled relationship;

[0011] FIG. 3 is a cross-sectional side view on 3-3 in FIG. 1;

[0012] FIG. 4 is a cross-sectional side view on 4-4 in FIG. 2;

[0013] FIG. 5 is an enlarged view of detail "5" in FIG. 4;

[0014] FIG. 6 is perspective view of seal member that is used in FIG. 5;

[0015] FIG. 7 is a cross-sectional side view on 7-7 in FIG. 1;

[0016] FIG. 8 is a cross-sectional side view on 8-8 in FIG. 2;

[0017] FIG. 9 is a cross-sectional side view on 9-9 in FIG. 1;

[0018] FIG. 10 is a cross-sectional side view on 10-10 in FIG. 2; and

[0019] FIG. 11 is a graph showing hard stacking of various open cell foam materials.

DETAILED DESCRIPTION OF THE INVENTION

[0020] FIG. 1 of the accompanying drawings illustrates a viewing device 20, according to an embodiment of the invention, including first and second main sub-assemblies 22 and 24 in a spaced relationship relative to one another and before being finally assembled.

[0021] The first main sub-assembly 22 includes a shell piece 26 and first and second shell-side camera sub-assemblies 28 and 30.

[0022] The second main sub-assembly 24 includes an internal mounting structure 32, a camera electronics board 34 and first and second mounting structure-side camera sub-assemblies 36 and 38. The first and second mounting structure-side camera sub-assemblies 36 and 38 are secured to the camera electronics board 34. The camera electronics board 34 is then secured to the internal mounting structure 32.

[0023] FIG. 2 illustrates the viewing device 20 after the first and second main sub-assemblies 22 and 24 are secured to one another. The shell piece 26 and the internal mounting structure 32 are moved from the spaced relationship in FIG. 1 to an assembled relationship in FIG. 2 relatively towards one another. In the assembled relationship of FIG. 2, the first shell-side camera sub-assembly 28 and the first mounting structure-side camera sub-assembly 36 come together to form a first camera assembly 40. In the assembled relationship, the second shell-side camera sub-assembly 30 and the second mounting structure-side camera sub-assembly 38 come together to form a second camera assembly 42.

[0024] FIG. 3 is cross-section on 3-3 in FIG. 1. The first shell-side camera sub-assembly 28 includes a transparent window 43 and first seal member 44. The transparent window 43 and the first seal member 44 are attached to the shell piece 26. The first mounting structure-side camera sub-assembly 36 includes a camera 46 and a second seal member 48. The camera 46 and the second seal member 48 are secured to the camera electronics board 34 and the camera electronics board 34 is secured to the internal mounting structure 32.

[0025] The shell piece 26 and the internal mounting structure 32 are shown in the spaced relationship described with reference to FIG. 1. In the spaced relationship, the first and second seal members 44 and 48 are spaced from one another and therefore do not make contact with one another.

[0026] FIG. 4 is a cross-section on 4-4 in FIG. 2 and FIG. 5 is an enlarged view of a detail marked "5" in FIG. 4. The shell piece 26 defines a first window opening 60. The first window opening 60 is circular in a plane normal to the paper. The transparent window 43 is attached to the shell piece 26 over the first window opening 60. The transparent window 43 has a circular periphery 62 that makes continuous contact with the window opening 60. Continuous contact between the circular periphery 62 and the first window opening 60 ensures that dust particles cannot enter from left to right past the circular periphery 62.

[0027] The first seal member 44 is an annular member that has a first external surface 64 and first engagement surface 66. An adhesive 68 is located between and secures the first external surface 64 to the shell piece 26. The adhesive 68 forms a continuous annular ring that seals continuously with the shell piece 26. A continuous annular seal between the shell piece 26 and the first external surface 64 ensures that dust particles cannot enter through any gap between the shell piece 26 and the first seal member 44.

[0028] The camera 46 has a camera body 70 and a lens 72 on the camera body 70. The camera body 70 is mounted to the camera electronics board 34. A gap 74 is defined between the transparent window 43 and the lens 72.

[0029] The second seal member 48 has an annular shape and has a second external surface 76 and second engagement surface 78. FIG. 6 illustrates the second seal member 48 in more detail. The second seal member 48 has a front face 80, a rear face 82, an outer surface 84 and an inner surface 86. The inner and outer surfaces 86 and 84 are circular cylindrical surfaces. The inner surface 86 forms the second internal surface 76 in FIG. 5. The front face 80 forms the second engagement surface 78 in FIG. 5 The rear face 82 is divided into an inner annulus 90 and an outer annulus 92 with the outer annulus 92 surrounding the inner annulus 90. An adhesive 94 can be located on the outer annulus 92, but not on the inner annulus 90, such that adhesive is only located on areas of the second seal member 48 where it will interface with the camera electronics board 34. The adhesive 94 makes continuous contact with the outer annulus 92 through an entire circular revolution.

[0030] Referring again to FIG. 5, the adhesive is used to secure the second seal member 48 to the camera electronics board 34. The adhesive 94 creates a circumferential seal between the second seal member 48 and the camera electronics board 34. By forming the adhesive only on the outer annulus 92, the adhesive remains distant from the camera body 70 to ensure that the adhesive does not inadvertently pull on the camera body 70.

[0031] The camera body 70 has a circular shape. The second external surface 76 is located around an external surface of the camera body 70. The second external surface 76 forms a seal around the camera body 70. The second external surface 76 is slightly smaller than the external surface of the camera body 70 so that the second external surface 76 is slightly deformed by the shape of the camera body 70. Continuous circumferential contact between the second external surface 76 and the camera body 70 ensures that no dust particles can travel from right to left between the camera body 70 and the second seal member 48.

[0032] When the shell piece 26 and the internal mounting structure 32 are moved from the spaced relationship towards the assembled relationship relatively towards one another, the first engagement surface 66 makes contact with the second engagement surface 78. Further movement of the shell piece 26 and the internal mounting structure 32 into the assembled relationship causes the first and second seal members 44 and 48 to deform each other. The first engagement surface 66 is depressed into the first seal member 44 and the second engagement surface 78 is depressed into the second seal member 48.

[0033] The first and second engagement surfaces 66 and 78 make continuous contact through an entire annulus around the camera body 70. Such continuous contact between the first and second engagement surfaces 66 and 78 completes the formation of a closed front cavity 98. The closed front cavity 98 is defined jointly by the transparent window 43, the shell piece 26, a portion of the camera 46 that includes the camera body 70 and lens 72, and a seal 100 that is formed by the first and second seal members 44 and 48 between the camera 46 and the shell piece 26. The closed front cavity 98 provides a space between the lens 72 and the transparent window 43 that will remain free of dust particles due to the seal 100 that is provided between the shell piece 26 and the camera 46 and because the transparent window 43 has a circular periphery 62 that seals circumferentially with the first window opening 60 in the shell piece 26.

[0034] FIG. 7 is a cross-section on 7-7 in FIG. 1. The shell piece 26 defines a second window opening 102. The second shell-side camera side assembly 30 includes a transparent window 104 and first and second seal members 106 and 108. The transparent window 104 is secured over the window opening 102 in the same manner as the transparent window 43 and the first window opening 60 in FIG. 5. The first seal member 106 is secured to the shell piece 26 using an adhesive and the second seal member 108 is secured to the first seal member 106 in a similar manner using an adhesive.

[0035] The second mounting structure-side camera sub-assembly 38 includes a camera 110 and a third seal member 112. The camera 110 is secured to the camera electronics board 34. The third seal member 112 is secured to the camera electronics board 34 and seals with an outer surface of the camera 110.

[0036] With the shell piece 26 and the internal mounting structure 32 in the spaced relationship as shown, the third seal member 112 is slightly misaligned relative to the second seal member 108. The misalignment is because an axis of the first camera is at an angle relative to the direction that the internal mounting structure 32 is moved relative to the shell piece 26 from the spaced relationship to the assembled relationship. See FIG. 1. The combination of the first and second seal members 106 and 108 effectively creates a thicker seal member. Such a thicker seal member provides more "give" and has edges that have less of a tendency to roll up when the third seal member 112 comes in to contact with second seal member 108 and subsequent off-axis movement into the assembled relationship.

[0037] FIG. 8 is a cross-section on 8-8 in FIG. 2 and illustrates the second camera assembly after the third seal member 112 is engages with the second seal member 108. The third seal member 112 engages with the second seal member 108 at the same time that the first and second seal members 44 and 48 in FIG. 5 engage with one another.

[0038] FIGS. 9 and 10 are cross-sections on 9-9 in FIGS. 1 and 10-10 in FIG. 2, respectively. A fastener 114 is inserted though an opening in the internal mounting structure 32. The fastener 114 has thread on an external surface. A nut 116 is attached to the shell piece 26. The nut 116 has an internal surface that is threaded. In the spaced relationship shown in FIG. 9, the fastener 114 is secured to the internal mounting structure 32, but the fastener 114 is spaced from the nut 116. In the assembled relationship shown in FIG. 10, the fastener 114 is connected to the nut 116 by screwing the external thread of the fastener 114 into the internal thread of the nut 116. By securing the fastener 114 to the nut 116, the shell piece 26 is secured to the internal mounting structure 32. The seals that are formed between surfaces of the first and second seal members 44 and 48 in FIG. 5 and between the second and third seal members 108 and 112 in FIG. 7 remain intact because the shell piece 26 and the internal mounting structure 32 are secured in a fixed relationship relative to one another.

[0039] Manufacturing may require a 1.2 mm gap between components on the first and second main sub-assemblies 22, 24 that a seal has to fill. However, due to manufacturing tolerances such a gap can vary significantly. For example, the designed 1.2 mm gap can vary from a minimum gap of 0.6 mm to a maximum gap of 1.8 mm. It is thus required that the combined seal formed by the seal members be at least 1.8 mm in thickness and be compressible to 0.6 mm. A 200% compression may result in undesirable stresses if certain materials are used. Stresses between the first and second main sub-assemblies 22, 24 can result in deformations of one or more components of the sub-assemblies 22, 24. Deformations can cause changes in relationships between highly sensitive components, such as optical projectors and waveguide structures, and can significantly diminish quality of an image that is delivered to a user. Thus, manufacturing seal components from highly compressible materials can be advantageous in limiting a force applied to the main sub-assemblies 22, 24 during compression of seals disposed in gaps having high tolerance variance between the main sub-assemblies 22, 24. An open cell foam provides a material that has a very low spring constant and, for that reason, is a preferred material for the seal members described herein. Open cell foam may provide advantages over closed cell foam because open cell foam can have a lower spring constant than closed cell foam. Openings in open cell foam are still sufficiently small to prevent dust particles from passing therethrough. Open cell foam is also preferred over parts such as gromets or bellows-type parts because it is much easier to manufacture very tiny parts using open cell foam.

[0040] When an open cell material is compressed to a point where all of the open cells have been collapsed, hard stacking occurs. At the hard stacking point, any additional compression applied to the material is met with a high resistance because the material surrounding the open cells is being pushed into contact against itself rather than displacing under the compression. It is preferable that a seal member be made of a foam having an initial dimension that is compressible to a final dimension before hard stacking wherein the final dimension is less than 10% of the initial dimension. Open cell foam can be compressed more than closed cell foam before hard stacking occurs. FIG. 2 shows changing spring constant curves of three different materials. The first material (SCF100) is preferred over the second and third materials (92-12039 and 92-12049) because the first material can be compressed to less than 20% of its initial size before hard stacking. In particular, when the first material is compressed, its spring constant at 20% compression is only double its spring constant at 50% compression.

[0041] The seal material preferably reduces its resistance to compression force over a short period of time, i.e. compression setting occurs relatively quickly. Compression set of a material can be defined as the amount of permanent deformation that occurs as a result of force applied to the compressible material. The permanent deformation that occurs over exposure to the compressed state results in a decreasing resistance force applied to the components that are causing the compression of the seal. Preferably, the force that is created by the compression of the seal material reduces by 50% in less than 5 minutes. Such a reduction in the force further reduces stresses on other components of the viewing device such as the camera or other electronic or optical components.

[0042] A seal material that has high compressibility can prove difficult to fabricate in certain dimensions. For example, if the annular dimension of the seal is small but the thickness of the seal is large, the seal may be difficult to form using traditional methods, such as die cutting. To improve seal quality and tolerances, two shorter seals having reduced thicknesses can be fabricated and then stacked on each other to total the designed thickness of the seal component. This solution allows for thick seals to be formed from highly compressible materials for use in high-precision devices, such as the visual system described herein, where any additional force imparted to the assemblies carrying precision aligned components can disturb their positional relationships and reduce overall performance of the system.

[0043] A visual system may include the two cameras that have been described as part of a set of four to six cameras that are used together with a depth sensor to capture objects and to determine distances to the objects. A head pose and position and position of a user can be determined by processing imagery from the visual system using a simultaneous localization and mapping (SLAM) and visual odometry procedure. Such continual processing of the images provides data that indicates movement of the viewing device relative to the objects. Because the depth sensor and a gravity sensor determine the locations of the objects relative to gravitation force, the cameras can detect movement of the viewing device relative to gravitation force. The viewing device has a see-through waveguide and a projector projects an image through the waveguide on to a retina of an eye of the user. The user thus sees a rendered object within a real world environment. The objects remain fixed within the real world environment even when the user moves their head. The stationary position of the objects is made possible because the viewing system is used to determine objects in the real world environment relative to the view of the user when the user moves their head.

[0044] While the seals are referred to as circular throughout the description, one of skill in the art will appreciate that the concept of fabricating a highly compressible seal with a high thickness-to-width ratio can apply to many shapes and designs for gaskets or seals. While certain exemplary embodiments have been described and shown in the accompanying drawings, it is to be understood that such embodiments are merely illustrative and not restrictive of the current invention, and that this invention is not restricted to the specific constructions and arrangements shown and described since modifications may occur to those ordinarily skilled in the art.
