[0021] As mentioned above many different sets of parameters can be utilized to determine user intent. Table 1 listed below provides an example of just one set of parameters. In this case, the parameters include time (e.g. indicating order and duration the finger is in an individual volume), candidate key character, volume, and whether the user stopped his finger in the volume.

TABLE-US-00001 TABLE 1 Key Finger Time Candidates Volume Stop? 00:00 F 0.5 Yes 00:00 F 1.0 No 00:01 D 1.0 No 00:02 S 1.0 No 00:03 A 2.0 No 00:03 A 0.75 Yes 00:04 Z 0.1 No 00:05 X 1.0 No 00:06 C 0.75 No 00:07 C 0.5 Yes 00:07 V 0.5 Yes 00:08 V 1.0 No 00:09 F 1.0 No 00:10 R 0.8 No 00:11 R 0.5 Yes 00:12 E 0.5 Yes 00:13 E 1.5 No 00:14 S 0.5 No 00:15 S 1.0 Yes

[0022] In this case, the finger stop parameter can be associated with a higher probability of user intent to engage. Thus, the finger stop parameter can weight those candidate key characters higher than alternative candidate key characters.

[0023] The weighted characters from the path and their relative probabilities can be compared to a listing of known words, phrases, commands, etc. to identify potential matches. Assume that in this example, the listing is manifest as a dictionary and the potential matches for the characters of the path are faces and faves with faces having a higher probability and faves a lower probability. Note that the comparison can result in characters from the path being dropped (e.g., inadvertently passing through the key’s volume). The comparison could also add characters that were missed, such as where the user slightly missed the intended keys. For instance, a path including Q A S could produce a predicted word of WAS because W and Q are adjacent and QAS does not match any listings and WAS does.

[0024] Note also that in the illustrated implementation, the path 126 is not visualized for the user. However, in other implementations, the path can be visualized for the user in real-time. This can provide a feedback mechanism that allows the user to adjust his/her engagement technique if the path does not reflect the keys the user intended to engage/address. Similarly, an appearance of individual keys that are determined to be selected by the user can be changed as a form of visual feedback to the user. This visual feedback can allow the user to adjust his/her input technique if the key was not intended or speed up his/her input if the key was intended.

[0025] FIG. 1L shows user input that is associated with the user intent automatically generated on behalf of the user. In this case, the user input is manifest as the higher-ranking match (e.g., the predicted match) faces automatically populated into the dialog box 111 at 130, while the lower-ranking match faves is provided as an auto-suggestion option at 132. In this case, thresholds can be employed to determine a strategy. For instance, if the highest-ranking match exceeds a threshold then the highest-ranking match can be auto-populated into the dialog box.

[0026] Note that various forms of machine learning can be applied to the process described above of analyzing path parameters to determine which keys the user intended to engage and/or what the user intent was for the engagement (e.g., what word the user was attempting to spell). The machine learning solutions can provide improved accuracy for the user through actual use and/or training. For instance, machine learning may indicate that a particular user tends to dwell on an intended key for a long period and then overshoot intended keys and make rounded curves to the next intended key. As such, a parameter relating to keys on a curve of the path may be decreased in weight for determining user intent (e.g., less indicative of user intent) while a parameter relating to dwell time may be increased in weight (more indicative of user intent).

[0027] As mentioned above many different parameters can be utilized to determine user intent to engage individual keys (e.g., what keys did the user want to activate) and to predict overall user intent (e.g., what word or command was the user trying to enter). These parameters can be utilized in various ways to make the determinations and the predictions. One such example technique is pasted below as Table 2. Other example techniques are contemplated.

TABLE-US-00002 TABLE 2 struct key_hit { int_timestamp; // Time finger hit key wchar_t _c; // Character of the key double_weight; // Weight of finger hitting key (determined by speed, intersection of finger and key volume) bool_stop; // Did the finger stop on the key? }; vector generate_candidates(vector hits, unordered_set dictionary) { vector reduced_hits; // Remove hits which occur before or after a finger stop of the same key reduced_hits = reduce_finger_stops(hits); // Remove hits where a finger only glanced a key (say weight is 20% or less) reduced_hits = remove_hits_below_weight_threshold(reduced_hits); vector character_propabilities; // Create a directed graph of characters. Characters must appear in this order in the word. // _stop with _weight >= 1 is 100% probable letter, indicated by . Remainder between these are probable characters to evaluate // Ex: // {F}, {D,S}, {A*}, {X,C,V}, {F,R}, {E*}, {S*} character_propabilities = build_probable_character_order(reduced_hits); vector combination_words; // Build the words from the probabilities. // Character sets are expanded into possible combinations. // Letters must appear in the order they came in because finger moved through candidate keys in a given order. Must consider that none of the characters are in the word // {F*} - must be in word // {D,S} - candidates { }, {D}, {S} and {D,S} // {A*} - must in in word // {X,C,V} - candidates { }, {X}, {C}, {V}, {X,C}, {C,V}, {X,C,V} // {F, R} - candidates { }, {F}, {R}, {F,R} // {E*} - must be in word // {S*} - must be in word // // Total of 4*7*4 = 112 possible words // Output starts with FAES, FDAES, FSAES, FDSAES, FAXES, FACES, FAVES, FAXCES … combination_words = create_combination_words(combination_words); vector candidate_words; // Reduce to real words in user’s language // Output includes FACES, FAVES, etc. candidate_words = lookup_language_dictionary(word_combinations); return candidate_words; }

[0028] In this example technique, the structured key_hit section identifies keys engaged by the user utilizing multiple parameters (see Table 1) (e.g., time finger hit key, character of the key, weight of finger hitting key (this parameter is based off of multiple other listed parameters), and whether the finger stopped on the key).

[0029] The generate candidates section utilizes additional parameters to remove likely inadvertent key hits. The character_probabilities section creates a directed graph of character probabilities. The combination_words section builds potential words from the directed graph. The candidate_words section filters the combination words against references, such as a dictionary. Finally, the technique returns the candidate words (e.g., see FIG. 1L).

[0030] FIGS. 2A-2H relate to a scenario 100A that is similar to the scenario of FIGS. 1A-1L. As such, elements are not reintroduced for sake of brevity. Scenario 100A includes a parameter that relates to finger movement parallel to the virtual keyboard through the volumes 122 (e.g. relative to the xz-reference plane). This scenario also includes another parameter that relates to finger movement perpendicular to the virtual keyboard through the volumes 122 (e.g., parallel to the y-reference axis). Movement in the volumes that is toward and/or away from virtual keyboard 114 can be indicative of user intent to address a key 116. This correlation can be strong whether the movement is in the volume in front of the key (e.g. on the user’s side of the key, through the key, and/or behind the key (e.g., on an opposite side of the key from the user).

[0031] FIG. 2A shows the user’s finger 120 in volume 122(3) associated with the F key. Further, the user is simulating engaging the key by moving his finger toward the virtual keyboard 114 in the volume. This motion can be highly predictive of user intent to address the F key. FIG. 2B shows the user having moved his finger laterally to the A key (e.g., through the intervening D and S keys) with the finger remaining the same distance from the user in the y-reference direction as FIG. 2A. FIG. 2C shows the user withdrawing his finger (in the -y direction) within the volume of the A key. This motion can be indicative of the user intending to address the A key. Thus, the user’s finger has so far moved through the volumes for the F,D,S, and A keys in the x-reference direction. This aspect can be represented by a first parameter.

[0032] This first parameter can be indicative of user intent to select these keys. Further, the user moved in the y-reference direction relative to the F and A keys, which can be represented by the second parameter. Keys that are included in both sets (e.g., associated with the first parameter and the second parameter) can have a higher probability of user intent to address the key than those associated with only the first parameter. This aspect can allow the present virtual keyboard engagement techniques to be much more fluid and faster than existing techniques. For instance, in traditional techniques the user would have to attempt to engage the F key, then withdraw his/her finger and await confirmation that the F key was activated and then attempt to engage the A key. In the present implementations, the user can simply slide across the intervening D and S keys to the A key with confidence that the techniques will accurately determine which keys the user intended to activate. Stated another way, the path of the user’s finger can be curved in one, two, or all three of the reference directions. A curved path relating to multiple keys can be much faster for the user than discrete movements directed at single keys. Deriving parameters relating to the curved path can allow highly accurate predictions to be made regarding user intent while increasing user speed of entry.

[0033] FIG. 2D shows the user moved his finger 120 laterally to the volume 122(5) associated with the C key. FIG. 2E shows the user moving his finger 120 perpendicular to the C key while in the volume 122(5). In this case, the movement is away from the user. FIG. 2F shows the user moving the finger back out (e.g., toward the user) while still in the volume 122(5) associated with the C key.

[0034] FIG. 2G shows the user moved the finger up to the volume 122(6) associated with the E key and is moving the finger perpendicular to the virtual keyboard (e.g., toward the virtual keyboard in this case). FIG. 2H shows the user moved the finger to the volume 122(7) associated with the S key and then moving perpendicular to the virtual keyboard (e.g., toward the user in the -y reference direction in this case). The prediction of user intent based upon this set of parameters may be the same as discussed relative to scenario 100 above, but the confidence levels (e.g., probabilities) of the prediction may be higher than obtained with the set of parameters employed above. Further, other parameters can be included in the set of parameters. For instance, where the user is looking (e.g., what key the user is looking at) may be treated as another parameter. Similarly, the user’s hand pose may be treated as another parameter. For instance, the user may tend to hold his/her palms parallel to the major surface of the keyboard when intending to type. If in contrast, the user’s hand is shaped like a first with a finger extending from the fist, the user may be pointing at something in the scene rather than typing.

[0035] The multiple parameters relating to the path can provide disambiguation of potential user key selections. This can be especially pronounced in machine learning scenarios. For instance, as mentioned above, some keys can include two characters. For instance, the 2 character and the @ character can occur on a single key. Machine learning techniques could indicate that when this key is engaged by the user and the previously activated character was a letter then the user intended to select the @ character and if the previously activated character was a number then the user intended to select the 2 character. Thus, user intent can be accurately determined (e.g., with high probability) despite the user tracing a pathway over multiple closely spaced keys using disambiguation involving multiple parameters.

[0036] FIG. 3 shows an alternative key volume shape. In this case, the key volumes 122B are cuboids that extend toward and away from the user relative to the virtual keyboard 114B as 3D keys. In this implementation, the volumes 122B are visualized for the user as the 3D keys. The user can see whether his/her finger (or other input device) is within the volume of an individual key that he/she is trying to select. This configuration can provide visual feedback to the user whether the user action will be interpreted as an attempt to engage that individual key. As mentioned, the path can be visually traced behind the user’s finger in real-time as another feedback mechanism to the user.

[0037] Note, the frustrum shaped key volumes and the cuboid shaped key volumes are illustrated examples of key volumes that can be sensed for user engagement. Other volume shapes can satisfy this functionality.

[0038] FIG. 4 shows a system 400 that can accomplish virtual keyboard engagement concepts. For purposes of explanation, system 400 can include several smart devices 402(1), 402(2), 402(3), 402(4), and 402(5). Device 402(1) is manifest as a headset that is similar to headset 106 of FIG. 1A. Device 402(2) is manifest as depth sensor and projection device, device 402(3) is manifest as a car, and device 402(4) is manifest as a tablet-type device. Any of devices 402(1)-402(4) can operated in a free-standing manner and/or can communicate with other devices, such as device 402(5). This device 402(5) may be local to or remote from the other devices and may contribute resources, such as processing and/or storage resource to shared operating scenarios with any of devices 402(1)-402(4). Individual devices 402 can include optics 404, emitters 406, sensors 408, controller 410, a display component 412, a virtual keyboard engagement module 413, a processor 414, and/or storage/memory 416.

[0039] FIG. 4 shows two device configurations 418 that can be employed by devices 402. Individual devices 402 can employ either of configurations 418(1) or 418(2), or an alternate configuration. (Due to space constraints on the drawing page, one instance of each device configuration is illustrated rather than illustrating the device configurations relative to each device 402). Briefly, device configuration 418(1) represents an operating system (OS) centric configuration. Device configuration 418(2) represents a system on a chip (SOC) configuration. Device configuration 418(1) is organized into one or more applications 420, operating system 422, and hardware 424. Device configuration 418(2) is organized into shared resources 426, dedicated resources 428, and an interface 430 therebetween.

[0040] In some implementations, the optics 404 can include lenses that can focus emitted (outgoing light) and/or light from the scene (incoming light). The emitters 406 can emit light for generating virtual content and/or for reflecting off of the scene, such as for depth sensing. The sensors 408 can sense light received from the scene, the user’s eye position, etc. Stated another way, the sensors can include inwardly looking sensors and/or outwardly looking sensors. Note that while the optics 404, emitters 406, and sensors 408 can be discrete components, they can also be integrated. For instance, the emitters may emit light that creates images (e.g., the virtual content) in the optics, such as via a waveguide.

[0041] Further, the emitters 406, optics 404, and/or sensors 408 can work cooperatively to achieve the depth sensing functionality. For instance, the emitters 406 and optics 404 can project patterned light, such as patterned infrared (IR) light. Some of the patterned IR light can be reflected from the scene and sensed by the sensors 408. Depth information can be derived from the sensed patterned IR light. In other cases, dual sets of sensors can be used to generate stereoscopic images of the scene. Depth information can be derived from the stereoscopic images. As technology evolves depth information can be derived from various types of sensed data, such pairs of images sensed by the sensors.

[0042] The controller 410 can coordinate the function of the emitters 406 and/or the sensors 408. For instance, the display component 412 can generate virtual content that can be emitted by the emitters 406 so that the virtual content including the virtual keyboard appears to be projected at a set of 3D coordinates in front of the user (in front of the user’s eyes). Thus, the 3D location of individual virtual keys is determined by 3D coordinates. As mentioned above, users can have difficulty determining how far away the virtual keyboard is in front of them (in the y-reference direction) and providing feedback to the user to indicate they are engaging the keyboard has proven elusive. To address this deficiency, the virtual keyboard engagement module 413 can monitor various parameters associated with user movement to determine whether the user is attempting to activate the keyboard generally and individual keys specifically. Toward this end, the virtual keyboard engagement module can monitor key volumes rather than simple 2D planar key surfaces for user engagement.

[0043] Stated another way, the virtual keyboard engagement module 413 can utilize 3D depth information (from the sensors 408) about user movements relative to key volumes defined relative to the virtual keys and the user as a parameter relating to user intent to select individual virtual keys. Stated another way, the virtual keyboard engagement module 413 can correlate the 3D location of the key volumes with the 3D location of user movements. The virtual keyboard engagement module 413 can derive various parameters from the correlation. The virtual keyboard engagement module 413 can utilize these parameters to attempt to predict an intended user action from the user engagement. The virtual keyboard engagement module 413 can use the predicted intended user action in an attempt to facilitate the user experience (e.g., populate a word or phrase the user intended to type or enter a command the user intended to convey).

[0044] In some configurations, each of devices 402 can have an instance of the virtual keyboard engagement module 413. However, the functionalities that can be performed by the virtual keyboard engagement module 413 may be the same or they may be different from one another. For instance, in some cases, each device’s virtual keyboard engagement module 413 can be robust and provide all of the functionality described above and below (e.g., a device-centric implementation).

[0045] In other cases, some devices 402 can employ a less robust instance of the virtual keyboard engagement module 413 that relies on some functionality to be performed by another device. For instance, device 402(5) may have more processing resources than device 402(1). In such a configuration, some virtual keyboard engagement functions may be performed on device 402(5) rather than device 402(1). For instance, parameter tracking could be performed locally on device 402(1). The parameters could be conveyed to device 402(5), which can perform the prediction functionality based upon the parameters and return the prediction to device 402(1). In another case, device 402(1) could generate virtual content, while device 402(2) provided depth sensing that captured the user. Device 402(2) could communicate the depth information to device 402(1), which could identify user interactions with the virtual content from the depth information.

[0046] The term “device,” “computer,” or “computing device” as used herein can mean any type of device that has some amount of processing capability and/or storage capability. Processing capability can be provided by one or more processors that can execute data in the form of computer-readable instructions to provide a functionality. Data, such as computer-readable instructions and/or user-related data, can be stored on storage, such as storage that can be internal or external to the device. The storage can include any one or more of volatile or non-volatile memory, hard drives, flash storage devices, and/or optical storage devices (e.g., CDs, DVDs etc.), remote storage (e.g., cloud-based storage), among others. As used herein, the term “computer-readable media” can include signals. In contrast, the term “computer-readable storage media” excludes signals. Computer-readable storage media includes “computer-readable storage devices.” Examples of computer-readable storage devices include volatile storage media, such as RAM, and non-volatile storage media, such as hard drives, optical discs, and flash memory, among others.

[0047] Examples of devices 402 can include traditional computing devices, such as personal computers, desktop computers, servers, notebook computers, vehicles, smart cameras, surveillance devices/systems, safety devices/systems, smart glasses, wearable smart devices, appliances, and other developing and/or yet to be developed device types, etc.

[0048] As mentioned above, device configuration 418(2) can be thought of as a system on a chip (SOC) type design. In such a case, functionality provided by the device can be integrated on a single SOC or multiple coupled SOCs. One or more processors 414 can be configured to coordinate with shared resources 426, such as storage/memory 416, etc., and/or one or more dedicated resources 428, such as hardware blocks configured to perform certain specific functionality. Thus, the term “processor” as used herein can also refer to central processing units (CPUs), graphical processing units (GPUs), field programable gate arrays (FPGAs), controllers, microcontrollers, processor cores, or other types of processing devices.

[0049] Generally, any of the functions described herein can be implemented using software, firmware, hardware (e.g., fixed-logic circuitry), or a combination of these implementations. The term “component” as used herein generally represents software, firmware, hardware, whole devices or networks, or a combination thereof. In the case of a software implementation, for instance, these may represent program code that performs specified tasks when executed on a processor (e.g., CPU or CPUs). The program code can be stored in one or more computer-readable memory devices, such as computer-readable storage media. The features and techniques of the component are platform-independent, meaning that they may be implemented on a variety of commercial computing platforms having a variety of processing configurations.

[0050] FIG. 5 shows a flowchart of a virtual keyboard engagement technique or method 500.

[0051] At block 502, the method can track a path of a user action in 3D space.

[0052] At block 504, the method can correlate the path to volumes assigned to individual keys of a virtual keyboard display in the 3D space.

[0053] At block 506, the method can determine user intent to select individual keys based at least in part on multiple parameters associated with the path.

[0054] At block 508, the method can generate user input associated with the user intent. For instance, the method can automatically enter user input in the form of a word, phrase, and/or command on behalf of the user.

[0055] FIG. 6 shows a flowchart of another virtual keyboard engagement technique or method 600.

[0056] At block 602, the method can detect a path of a user extremity relative to a virtual keyboard displayed in 3D space. The path can be a curved 3D path relating to multiple keys. In some cases, detecting a path of a user extremity can entail detecting the path of a finger, multiple fingers, a hand, and/or an object held in the hand, among others.

[0057] At block 604, the method can assign probabilities to individual keys of the virtual keyboard when the path passes through a volume defined at least in part by the individual keys. In some cases, assigning probabilities to individual keys of the virtual keyboard can entail assigning a first probability to an individual key of the keyboard when the path passes through a volume defined at least in part by the individual key. In other cases, assigning probabilities to individual keys of the virtual keyboard can entail assigning a first probability to an individual key of the keyboard when the path passes relative to the individual key under first parameters and assigning a second higher probability to another individual key when the path passes relative to the another individual key under second parameters.

[0058] At block 606, the method can predict an intended user action based at least in part on the probabilities.

[0059] At block 608, the method can automatically take an action on behalf of the user based at least in part upon the predicted intended user action. In some implementations, taking an action can entail populating a dialog box with a word selected based at least in part upon the assigned probabilities.

[0060] FIG. 7 illustrates another virtual keyboard engagement technique or method 700.

[0061] At block 702, the method can define key volumes relating to keys of a virtual keyboard. In some cases, defining key volumes can entail defining cuboids that include the keys, or defining frustrums extending between eyes of the user and the keys.

[0062] At block 704, the method can detect finger movement of a user through individual key volumes.

[0063] At block 706, the method can detect parameter changes associated with detected finger movement through individual key volumes. In some cases, detecting parameter changes can entail detecting changes in direction and/or changes in velocity. In some cases, the direction changes can entail direction changes parallel to a key surface and/or perpendicular to the key surface. In some cases, detecting parameter changes can further entail assigning higher probabilities to individual keys in the potential key sequences associated with parameter changes.

[0064] At block 708, the method can build potential key sequences from detected parameter changes. The potential key sequences can be compared to known words and/or known user commands.

[0065] The described methods can be performed by the systems and/or elements described above and/or below, and/or by other devices and/or systems.

[0066] The order in which the methods are described is not intended to be construed as a limitation, and any number of the described acts can be combined in any order to implement the method, or an alternate method. Furthermore, the method can be implemented in any suitable hardware, software, firmware, or combination thereof, such that a device can implement the method. In one case, the method is stored on one or more computer-readable storage medium/media as a set of instructions (e.g., computer-readable instructions or computer-executable instructions) such that execution by a processor of a computing device causes the computing device to perform the method.

[0067] Various examples are described above. Additional examples are described below. One example includes a device comprising a display component configured to display virtual content relative to a scene, sensors configured to monitor volumes of the scene associated with the virtual content, and a controller configured to assign probabilities to movement relative to the volumes and to predict an intended user action based at least in part on the probabilities.

[0068] Another example can include any of the above and/or below examples where the virtual content comprises a keyboard or wherein the virtual content comprises multiple user selectable elements.

[0069] Another example can include any of the above and/or below examples where the sensors are configured to detect parameters associated with the movement of a user extremity through the volumes.

[0070] Another example can include any of the above and/or below examples where the parameters relate to velocity and direction relative to individual volumes.

[0071] Another example can include any of the above and/or below examples where the virtual content is associated with keys associated with characters, and wherein the controller is configured to compare a sequence of characters associated with the movement to a dictionary of known words to predict the intended user action as spelling an individual word from the dictionary.

[0072] Another example can include any of the above and/or below examples where the controller is configured to perform the intended user action.

[0073] Another example can include any of the above and/or below examples where the controller is configured to perform the intended user action by auto-populating the individual word into a dialog box or providing the individual word as an auto-suggestion for the dialog box.

[0074] Another example can include any of the above and/or below examples where the controller is configured to perform the auto-populating when a confidence associated with the individual word exceeds a threshold.

[0075] Another example includes a device-implemented method comprising detecting a path of a user extremity relative to a virtual keyboard displayed in 3D space, assigning probabilities to individual keys of the virtual keyboard when the path passes through a volume defined at least in part by the individual keys, predicting an intended user action based at least in part on the probabilities, and automatically taking an action on behalf of the user based at least in part upon the predicted intended user action.

[0076] Another example can include any of the above and/or below examples where detecting a path of a user extremity comprises detecting the path of a finger, multiple fingers, a hand, fingers of both a left and right hand, and/or an object held in the hand.

[0077] Another example can include any of the above and/or below examples where assigning probabilities to individual keys of the virtual keyboard comprises assigning a first probability to an individual key of the virtual keyboard when the path passes through a volume defined at least in part by the individual key.

[0078] Another example can include any of the above and/or below examples where assigning probabilities to individual keys of the virtual keyboard comprises assigning a first probability to an individual key of the keyboard when the path passes relative to the individual key under first parameters and assigning a second higher probability to another individual key when the path passes relative to the another individual key under second parameters.

[0079] Another example can include any of the above and/or below examples where taking an action comprises populating a dialog box with a word selected based at least in part upon the assigned probabilities.

[0080] Another example includes a device-implemented method comprising defining key volumes relating to keys of a virtual keyboard, detecting finger movement of a user through individual key volumes, detecting parameter changes associated with detected finger movement through individual key volumes, and building potential key sequences from detected parameter changes.

[0081] Another example can include any of the above and/or below examples where the defining key volumes comprises defining cuboids that include the keys, or wherein the defining key volumes comprises defining frustrums that include the keys.

[0082] Another example can include any of the above and/or below examples where detecting parameter changes comprises detecting changes in direction and/or changes in velocity.

[0083] Another example can include any of the above and/or below examples where detecting parameter changes in direction comprises detecting changes in direction parallel to a key surface and/or perpendicular to the key surface.

[0084] Another example can include any of the above and/or below examples where the detecting parameter changes further comprises assigning higher probabilities to individual keys in the potential key sequences associated with parameter changes.

[0085] Another example can include any of the above and/or below examples where the device-implemented method further comprises comparing the potential key sequences to known words.

[0086] Another example can include any of the above and/or below examples where the device-implemented method further comprises comparing the potential key sequences to known user commands.

[0087] Another example includes a device-implemented method comprising tracking a path of a user action in 3D space, correlating the path to volumes assigned to individual keys of a virtual keyboard display in the 3D space, determining user intent to select individual keys based at least in part on multiple parameters associated with the path, and generating user input associated with the user intent.

CONCLUSION

[0088] Although the subject matter relating to virtual keyboard engagement has been described in language specific to structural features and/or methodological acts, it is to be understood that the subject matter defined in the appended claims is not necessarily limited to the specific features or acts described above. Rather, the specific features and acts described above are disclosed as example forms of implementing the claims.
