Microsoft Patent | Transparent display device

Patent: Transparent display device

Drawings: Click to check drawins

Publication Number: 20140098085

Publication Date: 20140410

Applicants: Microsoft Corporation

Assignee: Microsoft Corporation

Abstract

This document describes techniques and apparatuses for implementing a transparent display device. A transparent display device includes a transparent or translucent screen to render images on the screen, and to render virtual objects that appear to be in a three-dimensional (3D) space behind the screen. The transparent display device also includes a hand tracker to sense movement of a user's hands to interact with one or more of the virtual objects, and to generate 3D-input based on the movement. The transparent or translucent screen enables the user to see the user's hands behind the screen as the user's hands interact with the one or more virtual objects. The transparent display device is controlled to modify the rendering of the images on the screen or the virtual objects behind the screen based on the 3D-input.

Claims

1. A transparent display device comprising: a transparent screen configured to render images on the transparent screen, and to render virtual objects that appear to be in a three-dimensional (3D) space behind the transparent screen; a hand tracker configured to sense movement of a user's hands to interact with one or more of the virtual objects in the 3D space behind the transparent screen, and to generate 3D-input based on the movement; and a controller configured to modify the rendering of the images on the transparent screen or the virtual objects behind the transparent screen based on the 3D-input.

2. The transparent display device of claim 1, wherein the transparent screen enables the user to see the user's hands behind the transparent screen as the user's hands interact with the one or more virtual objects.

3. The transparent display device of claim 1, wherein the transparent screen uses a grid to cause the virtual objects to appear to be in the 3D space.

4. The transparent display device of claim 1, further comprising an input panel positioned behind the transparent screen, the input panel configured to receive two-dimensional (2D) input from the user, and wherein the controller is further configured to modify the rendering of the images on the transparent screen based on the 2D-input from the user.

5. The transparent display device of claim 4, wherein the transparent screen is physically coupled to a near edge of the input panel.

6. The transparent display device of claim 5, wherein the input panel includes at least one of a keyboard, a mouse, a track pad, or a touch pad, and wherein the transparent screen is coupled to the near edge of the input panel using a foldable hinge that enables the user to input the 2D-input behind the transparent screen.

7. The transparent display device of claim 1, further comprising a head tracker that is configured to track a position of the user's head or eyes relative to the transparent screen, and wherein the controller is configured to modify the rendering of the one or more virtual objects that appear to be in the 3D space behind the transparent screen based on the position of the user's head or eyes.

8. The transparent display device of claim 1, wherein the controller is configured to modify the rendering of the images on the transparent screen by causing the rendering of the images to slide to reveal the virtual objects that appear to be in the 3D space behind the transparent screen responsive to the hand tracker sensing movement of the user's hand to reach into the 3D space.

9. The transparent display device of claim 1, wherein the virtual objects comprise windows, and wherein the transparent screen is configured to render the windows as stacked in one or more 3D volumes in the 3D space.

10. A method comprising: rendering an image on a transparent screen of a computing device; receiving two-dimensional (2D) input from a user via an input panel positioned behind the transparent screen; modifying the rendering of the image on the transparent screen based on the 2D-input; sensing movement of one of the user's hands to reach into a three-dimensional (3D) space behind the transparent screen; generating 3D-input based on the movement of the user's hand; and sliding the rendering of the image on the transparent screen to reveal one or more virtual objects that appear to be in the 3D space behind the transparent screen responsive to receiving the 3D-input.

11. The method of claim 10, wherein the one or more virtual objects comprise multiple windows stacked in one or more 3D volumes.

12. The method of claim 10, further comprising: sensing additional movement of the user's hand to reach towards the input panel; generating additional 3D-input based on the additional movement of the user's hand to reach towards the input panel; and sliding the rendering of the image on the transparent screen to cover the one or more virtual objects responsive to receiving the additional 3D-input.

13. A method comprising: rendering multiple windows stacked in one or more three-dimensional (3D) volumes that appear to be in a 3D space behind a transparent screen; sensing movement of a user's hand behind the transparent screen to select one of the 3D volumes; generating 3D-input based on the movement; and rendering the selected 3D volume as open to enable the user to interact with the multiple windows stacked in the selected 3D volume responsive to receiving the 3D-input.

14. The method of claim 13, further comprising: sensing additional movement of the user's hand behind the transparent screen to select one of the multiple windows stacked in the open 3D volume; generating additional 3D-input based on the additional movement; and rendering the selected window as selected on the transparent screen responsive to receiving the 3D-input.

15. The method of claim 14, wherein rendering the selected window as selected comprises causing the selected window to pop out of the open 3D volume.

16. The method of claim 13, further comprising, responsive to sensing movement of the user's hand behind the transparent screen, rendering feedback on the transparent screen based on the location of the user's hand in the 3D space.

17. The method of claim 16, wherein rendering the feedback further comprises causing the transparent screen to glow based on the location of the user's hand in the 3D space.

18. The method of claim 16, wherein rendering the feedback further comprises causing display of a cursor on the transparent screen based on the location of the user's hand in the 3D space.

19. The method of claim 13, wherein the transparent screen enables the user to see the user's hand behind the transparent screen.

20. The method of claim 13, further comprising sensing a position of the user's head or eyes relative to the transparent screen, and wherein the rendering the multiple windows comprises rendering the multiple windows as stacked in the one or more 3D volumes that appear to be in the 3D space behind the transparent screen based on the position of the user's head or eyes relative to the transparent screen.

Description

BACKGROUND

[0001] In typical user interactions with windows management and content retrieval, windows of information (e.g., a web page, a word-processing document, and a picture) are concurrently projected on a two-dimensional (2D) screen. These windows of information can be visualized and navigated via a "multiple layers" view, but even in the multiple layers view some of the windows are hidden by a top layer of windows. Unlike on a physical desk where documents and objects can be scattered around, in a conventional computer desktop user interface there is no fixed position given to inactive windows behind a top active window. Thus, the user cannot cognitively register background windows to a specific position in the physical space, making it difficult and inefficient for the user to choose among different windows.

SUMMARY

[0002] This document describes techniques and apparatuses for implementing a transparent display device. A transparent display device includes a transparent or translucent screen to render images on the screen, and to render virtual objects that appear to be in a three-dimensional (3D) space behind the screen. The transparent display device also includes a hand tracker to sense movement of a user's hands to interact with one or more of the virtual objects, and to generate 3D-input based on the movement. The transparent or translucent screen enables the user to see the user's hands behind the screen as the user's hands interact with the one or more virtual objects. The transparent display device is controlled to modify the rendering of the images on the screen or the virtual objects behind the screen based on the 3D-input.

[0003] This summary is provided to introduce simplified concepts in a simplified form that are further described below in the Detailed Description. This summary is not intended to identify essential features of the claimed subject matter, nor is it intended for use in determining the scope of the claimed subject matter.

BRIEF DESCRIPTION OF THE DRAWINGS

[0004] Embodiments of techniques and apparatuses for implementing a transparent display device are described with reference to the following drawings. The same numbers are used throughout the drawings to reference like features and components:

[0005] FIG. 1 illustrates an example environment in which a transparent display device can be implemented.

[0006] FIG. 2 illustrates a detailed example of a transparent display device.

[0007] FIG. 3 illustrates a detailed example of a side-view of a transparent display device.

[0008] FIG. 4a illustrates a detailed example of a transparent display device rendering a 2D image.

[0009] FIG. 4b illustrates a detailed example of a transparent display device implementing a sliding door technique.

[0010] FIG. 5a illustrates a detailed example of a transparent display device rendering multiple windows stacked in 3D volumes.

[0011] FIG. 5b illustrates another detailed example of a transparent display device rendering multiple windows stacked in 3D volumes.

[0012] FIG. 5c illustrates another detailed example of a transparent display device rendering multiple windows stacked in 3D volumes.

[0013] FIG. 6 illustrates an example method implemented by a transparent display device.

[0014] FIG. 7 illustrates an additional example method implemented by a transparent display device.

[0015] FIG. 8 illustrates an example device in which techniques for a transparent display device can be implemented.

DETAILED DESCRIPTION

[0016] Overview

[0017] This document describes techniques and apparatuses for implementing a transparent display device. A transparent display device includes a transparent or translucent screen to render images on the screen, and to render virtual objects that appear to be in a three-dimensional (3D) space behind the screen. The transparent display device also includes a hand tracker to sense movement of a user's hands to interact with one or more of the virtual objects, and to generate 3D-input based on the movement. The transparent or translucent screen enables the user to see the user's hands behind the screen as the user's hands interact with the one or more virtual objects. The transparent display device is controlled to modify the rendering of the images on the screen or the virtual objects behind the screen based on the 3D-input.

[0018] Example Environment

[0019] FIG. 1 is an illustration of an example environment 100 in which a transparent display device can be implemented. Environment 100 includes a transparent display device 102, which is illustrated, by way of example and not limitation, as one of a smart phone 104, a laptop computer 106, a television device 108, a desktop computer 110, or a tablet computer 112.

[0020] Transparent display device 102 includes processor(s) 114 and computer-readable media 116, which includes memory media 118 and storage media 120. Applications and/or an operating system (not shown) embodied as computer-readable instructions on computer-readable media 116 can be executed by processor(s) 114 to provide some or all of the functionalities described herein. Computer-readable media also includes a controller 122. How controller 122 is implemented and used varies, and is described in further detail below.

[0021] Transparent display device 102 also includes a transparent screen 124 that is configured to render images on the screen, and to render virtual objects that appear to be in a three-dimensional (3D) space behind the screen. While referred to as a transparent screen herein, transparent screen 124 can be implemented as either a transparent screen or as a semi-transparent or translucent screen. Transparent screen 124 can be implemented to render two-dimensional (2D) images and/or 3D images. For example, in some embodiments transparent screen 124 can render 2D images that are typically displayed on a 2D screen, such as a word-processing document, a PDF document, 2D pictures, or 2D video, to name just a few. Alternately or additionally, transparent screen 124 can render 3D images that can be viewed with or without eye glasses. For example, in some cases transparent screen 124 can be implemented to render 3D images using an optic such as a wedge that can be viewed by a user without the use of eye glasses. In other cases, transparent screen 124 can render 3D images that can be viewed by a user wearing eye glasses, such as shutter glasses, polarized glasses, or lenticular glassless displays, to name just a few.

[0022] As described in more detail below, transparent display device 102 can be controlled to transition between rendering the 2D images and/or 3D images on the transparent screen and rendering the virtual objects that appear to be in the 3D space behind the transparent screen. As discussed in more detail below, the images displayed on the transparent screen may be opaque, or partially opaque, to cover the virtual objects, but can be controlled to slide away to reveal the virtual objects displayed behind transparent screen 124.

[0023] In various embodiments, transparent screen 124 may be configured as a 2D or 3D flat-panel electronic display, such as a high-resolution liquid crystal display (LCD). Transparent screen 124 can be physically coupled to transparent display device 102 or implemented separate from transparent display device 102. For example, transparent screen 124 is physically coupled to laptop computer 106 but is implemented separate from desktop computer 110.

[0024] FIG. 2 illustrates a detailed example 200 of transparent display device 102 in accordance with one embodiment. In this example, transparent screen 124 uses a grid 202 to render virtual objects 204 that appear to a user as if the virtual objects are rendered in a 3D space 206 behind transparent screen 124. It is to be appreciated that grid 202 may not be viewable by the user, but is used by transparent display device 102 to render the virtual objects so that they appear to be positioned in the 3D space behind transparent screen 124. In this example, virtual objects 204 are depicted as windows 208 and 210. Windows 208 and 210 can each represent a page associated with an application, such a web browser page, a word-processing document, or a PDF file. It is to be noted, however, that transparent screen 124 can render any type of virtual object in 3D space 206.

[0025] By rendering virtual objects 204 that appear to be in 3D space 206, transparent screen 124 enables the user to manipulate virtual objects 204 using one or both of the user's hands. It is to be noted that transparent screen 124 is transparent and thus enables the user to see the user's actual hands (as opposed to a virtual rendering of the user's hands) as the user manipulates virtual objects 204. Thus, transparent display device 102 leverages the user's spatial understanding and kinesthetic memory to access and manipulate virtual objects 204 in 3D space 206.

[0026] Transparent display device 102 also includes a hand tracker 126, which is configured to sense movement of the user's hands, such as gestures, to interact with one or more of virtual objects 204 in 3D space 206 behind transparent screen 124, and to generate 3D-input based on the movement. In an embodiment, hand tracker 126 is implemented as a depth camera that senses a 3D position, movement, and/or pose of each of the user's hands. As discussed in more detail below, controller 122 is configured to receive the 3D-input from hand tracker 126, and to modify the rendering of the 2D or 3D images on transparent screen 124 (not illustrated in FIG. 2) or virtual objects 204 in 3D space 206, based on the 3D-input.

[0027] In some embodiments, transparent display device 102 also includes an input panel 128 that is positioned behind transparent screen 124 and is configured to receive 2D-input, such as touch-input and/or key-input, from the user. In this example, as opposed to the conventional design of a laptop where the laptop screen is attached to the trailing edge (far from the user) of the keyboard panel, transparent screen 124 is coupled to a near-edge (edge closer to the user) of input panel 128. Input panel 128 may include any combination of a keyboard configured to receive key-input or a mouse, track pad, touch pad, or other 2D sensing device configured to receive touch-input. By being positioned behind transparent screen 124, input panel 128 enables the user to reach behind the transparent screen to use the input panel.

[0028] It is to be noted that because transparent screen 124 is transparent or translucent, the user may be able to see input panel 128 as the key-input or touch-input is entered. For example, when input panel 128 includes a keyboard, the user may be able to see both the keys of the keyboard and the user's fingers through the transparent screen as the user types on the keyboard. Further, the position of input panel 128 behind transparent screen 124 enables the user to easily transition between using input panel 128 (e.g., for typing) to manipulating virtual objects 204 in 3D space 206. For example, if the user is typing on the keyboard of input panel 128, the user can simply raise one or both of the user's hands in order to manipulate or interact with virtual objects 204.

[0029] FIG. 3 illustrates a detailed example 300 of a side view of the transparent display device illustrated in FIG. 2. In this example, transparent screen 124 is coupled to input panel 128 via a foldable hinge 302. Foldable hinge 302 enables transparent screen 124 to fold on top of input panel 128 to close transparent display device 102. Foldable hinge 302, in this example, is attached to the middle of both transparent screen 124 and input panel 128, which enables the user to comfortably place the user's hands behind the transparent screen to use input panel 128.

[0030] While examples 200 and 300 illustrate transparent screen 124 as being physically attached to input panel 128, alternately input panel 128 may be positioned behind transparent screen 124 without being physically connected to the transparent screen. For example, transparent screen 124 may be implemented as a desktop monitor, and input panel 128 may be implemented as a keyboard and/or mouse that can be placed behind the desktop monitor.

[0031] In some embodiments, transparent display device 102 also includes a head tracker 130 that is configured to track a position of the user's head or eyes relative to transparent screen 124. Controller 122 is configured to render, or modify the rendering of, virtual objects 204 based on the position of the user's head or eyes so that the virtual objects appear to be in 3D space 206. Head tracker 130 can be implemented as a 3D camera or as an array of cameras. In various embodiments, both hand tracker 126 and head tracker 130 may be implemented as short-range depth cameras. In example 200, hand tracker 126 and head tracker 130 can be mounted to transparent screen 124, making transparent display device 102 truly a mobile device. Thus, controller 122 controls transparent display device 102 to render virtual objects 204 on transparent screen 124 that are updated in real time based on the user's eye or head position, such that the user perceives that the virtual objects are displayed behind the transparent screen at a programmed set position.

[0032] FIG. 4a illustrates a detailed example 400 of transparent display device 102 in accordance with one embodiment. In this example, transparent display device 102 renders a 2D or 3D image 402 on the surface of transparent screen 124. Image 402 may be any type of 2D image that can be displayed on a conventional 2D screen, or 3D image that can be displayed on a 3D screen. In this example, image 402 is a picture of a pair of dice. Note, however, that transparent screen 124 may display image 402 as a web browser window, a word-processing document, a picture, or a PDF file, to name just a few examples. The user can interact with image 402 using input panel 128. For example, the user can type on the keyboard of input panel 128 to write an email message, or use a track pad or mouse of the input panel to modify the size of image 402. Transparent display device 102 receives the 2D-input from the user via input panel 128, and controller 122 controls the transparent display device to modify the rendering of image 402 on the transparent screen based on the 2D-input.

[0033] In various embodiments, transparent display device 102 employs a "sliding door" technique when the user raises one or both of the user's hands off of input panel 128 to reach into the 3D space behind transparent screen 124. Consider for example that in FIG. 4b the user raises one of the user's hands off of input panel 128 to reach into 3D space 206. Hand tracker 126 senses this movement, and generates 3D-input that is received by controller 122. Controller 122 then controls transparent screen 124 to slide the rendering of image 402 to reveal one or more virtual objects that appear to be in 3D space 206 behind transparent screen 124. In this example, the rendering of image 402 is controlled to slide down transparent screen 124. Alternately, however, the rendering of image 402 can be controlled to slide up transparent screen 124 or to slide across (e.g., slide left across or slide right across) transparent screen 124. In some embodiments, image 402 can also or instead be controlled to fade, dissolve, or transition in any other way to reveal the virtual objects in 3D space 206.

[0034] After the rendering of the image on the screen slides to reveal the virtual objects, the user can interact with the virtual objects using one or both of the user's hands. In an embodiment, when the user lowers the user's hand to go back to entering input using input panel 128, hand tracker 126 senses the movement of the user's hand to reach towards the input panel and generates 3D-input that is received by controller 122. Controller 122 then controls transparent screen 124 to slide the rendering of image 402 to cover the one or more virtual objects (e.g., slide back up, back down, back left, or back right). It is to be appreciated, therefore, that the sliding door technique enables the user to easily transition between entering 2D-input via input panel 128 and entering 3D-input using the user's hands in 3D space 206.

[0035] Transparent display device 102 enables the user to interact with virtual objects that appear to be in the 3D space behind transparent screen 124 in a variety of different ways. In an embodiment, transparent display device 102 employs a "virtual cabinet" technique to cause transparent screen 124 to render multiple windows stacked in one or more 3D volumes that appear to be in 3D space 206. For example, FIG. 5a illustrates another detailed example 500 of transparent display device 102 in accordance with one embodiment. In this example, transparent screen 124 renders multiple windows stacked in 3D volumes 502 and 504 that appear to be in 3D space 206. Each of the windows stacked in 3D volumes 502 and 504 can represent a page associated with an application, such a web browser page, a word-processing document, or a PDF file.

[0036] Transparent display device 102 enables the user to interact with 3D volumes 502 and 504 in 3D space 206 by positioning one or both of the user's hands near the 3D volumes in 3D space 206. Hand tracker 126 is configured to sense movement of the user's hand behind the transparent screen to select one of 3D volumes 502 or 504, and to generate 3D-input based on the movement. Responsive to receiving the 3D-input from hand tracker 126, controller 122 controls transparent display device 102 to render the selected 3D volume as open on transparent screen 124 to enable the user to interact with the multiple windows stacked in the selected 3D volume.

[0037] It is to be noted that rendering the 3D volume as open enables the user to more easily view the multiple windows in the selected 3D volume. For example, in FIG. 5a, 3D volumes 502 and 504 are rendered as closed making it difficult for the user to see, or select, each individual window in 3D volumes 502 and 504. In FIG. 5b, if the user moves the user's hand to select 3D volume 504, the movement of the user's hand is sensed by hand tracker 126 which generates 3D-input that is received by controller 122. Controller 122 then controls transparent screen 124 to modify the rendering of 3D volume 504 to render 3D volume 504 as open. For example, as illustrated in FIG. 5b, the windows in 3D volume 504 are open, or spread out, as compared to the windows in 3D volume 502. Opening the 3D volume enables the user to more easily see, and thus more easily interact with, each of the windows in 3D volume 504.

[0038] Transparent display device 102 enables the user to interact with the multiple windows in open 3D volume 504 by positioning one or both of the user's hands near the multiple windows in 3D space 206. For example, in FIG. 5c if the user moves the user's hand to one of the multiple windows 506 in 3D volume 504, the movement of the user's hand is sensed by hand tracker 126 which generates 3D-input. Controller 122 receives the 3D-input and controls transparent screen 124 to render selected window 506 as selected. For example, in FIG. 5c controller 122 controls transparent display device 102 to render window 506 as selected by causing window 506 to "pop up" out of 3D volume 504. Popping window 506 out of 3D volume 504 enables the user to see more information regarding window 506. The user can then select window 506, such as by pinching the window, to display the window as a 2D image on transparent screen 124.

[0039] In various embodiments, transparent display device 102 is configured to provide feedback on transparent screen 124 based on the location of the user's hands in 3D space 206. In one embodiment, for example, controller 122 alters the color of the transparent screen based on the location of the user's hand. In FIG. 5c, for example, controller 122 can cause an area around window 506 to glow as the user reaches the user's hand towards window 506. This feedback helps the user interact with the windows in 3D space 206. In another embodiment, a 3D cursor can be displayed which is mapped to a position of the user's hand or finger. In another embodiment, controller 122 can cause a part of the screen to not be rendered based on the location of the user's hand to render an illusion of the user's hand being in front of a virtual object.

[0040] Example Methods

[0041] FIG. 6 is a flow diagram depicting an example method 600 implemented by a transparent display device. Block 602 renders an image on a transparent screen of a computing device. For example, transparent display device 102 (FIG. 1) renders a 2D or a 3D image on transparent screen 124 of the transparent display device.

[0042] Block 604 receives 2D-input from a user via an input panel positioned behind the transparent screen. For example, transparent display device 102 receives 2D-input from a user via input panel 128 that is positioned behind transparent screen 124. Input panel 128 may include any combination of a keyboard configured to receive key-input, or a mouse, track pad, or touch pad configured to receive touch-input.

[0043] Block 606 modifies the rendering of the image based on the 2D-input from the user. For example, controller 122 controls transparent display device 102 to modify the rendering of the 2D or 3D image on transparent screen 124 based on the 2D-input received from the user via input panel 128.

[0044] Block 608 senses movement of one of the user's hands to reach into a 3D space behind the transparent screen, and block 610 generates 3D-input based on the movement of the user's hand. For example, hand tracker 126 senses movement of one or both of the user's hand to reach into 3D space 206 (FIG. 2) behind transparent screen 124, and generates 3D-input based on the movement.

[0045] Block 612 slides the rendering of the image on the screen to reveal one or more virtual objects that appear to be in the 3D-space behind the transparent screen responsive to receiving the 3D-input. For example, controller 122 controls transparent display device 102 to slide the rendering of the 2D or 3D image displayed on transparent screen 124 to reveal one or more virtual objects that appear to be in 3D space 206 behind the transparent screen responsive to receiving the 3D-input from hand tracker 126.

[0046] FIG. 7 is a flow diagram depicting an additional example method 700 implemented by a transparent display device. Block 702 renders multiple windows stacked in one or more 3D volumes that appear to be in a 3D space behind a transparent screen. For example, transparent display device 102 (FIG. 1) renders multiple windows stacked in one or more 3D volumes, such as 3D volumes 502 and 504 (FIG. 5a), that appear to be in 3D space 206 behind transparent screen 124.

[0047] Block 704 senses movement of a user's hand behind the transparent screen to select one of the 3D volumes, and block 706 generates 3D-input based on the movement. For example, hand tracker 126 senses movement of the user's hand behind transparent screen 124 to select 3D volume 504, and generates 3D-input based on the movement.

[0048] Block 708 renders the selected 3D volume as open to enable the user to interact with the multiple windows stacked in the selected 3D volume. For example, controller 122 controls transparent display device 102 to render selected 3D volume 504 (FIG. 5b) as open on transparent screen 124 to enable the user to interact with the multiple windows stacked in selected 3D volume 504.

[0049] Block 710 senses additional movement of the user's hand behind the transparent screen to select one of the multiple windows stacked in the open 3D volume, and block 712 generates additional 3D-input based on the additional movement. For example, hand tracker 126 senses additional movement of the user's hand behind transparent screen 124 to select window 506 (FIG. 5c) stacked in open 3D volume 504, and generates additional 3D-input based on the additional movement.

[0050] Block 714 renders the selected window as selected on the transparent screen. For example, controller 122 controls transparent display device 102 to render selected window 506 as selected on transparent screen 124, such as by causing window 506 to pop out of 3D volume 504.

[0051] Example Device

[0052] FIG. 8 illustrates various components of example device 800 that can be implemented as any type of client, server, and/or display device as described with reference to the previous FIGS. 1-7 to implement techniques enabling a transparent display device. In embodiments, device 800 can be implemented as one or a combination of a wired and/or wireless device, as a form of flat panel display, television, television client device (e.g., television set-top box, digital video recorder (DVR), etc.), consumer device, computer device, server device, portable computer device, user device, communication device, video processing and/or rendering device, appliance device, gaming device, electronic device, and/or as another type of device. Device 800 may also be associated with a viewer (e.g., a person or user) and/or an entity that operates the device such that a device describes logical devices that include users, software, firmware, and/or a combination of devices.

[0053] Device 800 includes communication devices 802 that enable wired and/or wireless communication of device data 804 (e.g., received data, data that is being received, data scheduled for broadcast, data packets of the data, etc.). The device data 804 or other device content can include configuration settings of the device, media content stored on the device, and/or information associated with a user of the device. Media content stored on device 800 can include any type of audio, video, and/or image data. Device 800 includes one or more data inputs 806 via which any type of data, media content, and/or inputs can be received, such as user-selectable inputs, messages, music, television media content, recorded video content, and any other type of audio, video, and/or image data received from any content and/or data source.

[0054] Device 800 also includes communication interfaces 808, which can be implemented as any one or more of a serial and/or parallel interface, a wireless interface, any type of network interface, a modem, and as any other type of communication interface. The communication interfaces 808 provide a connection and/or communication links between device 800 and a communication network by which other electronic, computing, and communication devices communicate data with device 800.

[0055] Device 800 includes one or more processors 810 (e.g., any of microprocessors, controllers, and the like), which process various computer-executable instructions to control the operation of device 800 and to enable techniques for implementing a transparent display device. Alternatively or in addition, device 800 can be implemented with any one or combination of hardware, firmware, a system-on-chip (SoC), or fixed logic circuitry that is implemented in connection with processing and control circuits which are generally identified at 812. Although not shown, device 800 can include a system bus or data transfer system that couples the various components within the device. A system bus can include any one or combination of different bus structures, such as a memory bus or memory controller, a peripheral bus, a universal serial bus, and/or a processor or local bus that utilizes any of a variety of bus architectures.

[0056] Device 800 also includes computer-readable storage media 814, such as one or more memory devices that enable persistent and/or non-transitory data storage (i.e., in contrast to mere signal transmission), examples of which include random access memory (RAM), non-volatile memory (e.g., any one or more of a read-only memory (ROM), non-volatile RAM (NVRAM), flash memory, EPROM, EEPROM, etc.), and a disk storage device. A disk storage device may be implemented as any type of magnetic or optical storage device, such as a hard disk drive, a recordable and/or rewriteable compact disc (CD), any type of a digital versatile disc (DVD), and the like. Device 800 can also include a mass storage media device 816.

[0057] Computer-readable storage media 814 provides data storage mechanisms to store the device data 804, as well as various device applications 818 and any other types of information and/or data related to operational aspects of device 800. For example, an operating system 820 can be maintained as a computer application with the computer-readable storage media 814 and executed on processors 810. The device applications 818 may include a device manager, such as any form of a control application, software application, signal-processing and control module, code that is native to a particular device, a hardware abstraction layer for a particular device, and so on.

[0058] The device applications 818 also include any system components or modules to implement techniques using or enabling a transparent display device. In this example, the device applications 818 can include controller 122 for controlling a transparent display device.

CONCLUSION

[0059] This document describes various apparatuses and techniques for implementing a transparent display device. Although the invention has been described in language specific to structural features and/or methodological acts, it is to be understood that the invention defined in the appended claims is not necessarily limited to the specific features or acts described. Rather, the specific features and acts are disclosed as example forms of implementing the claimed invention.
